Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots/?cursor=cj0xJnA9MjAyNS0wOS0wOCswNiUzQTE0JTNBMjguMDI3MDE4JTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plotly.com/v2/plots/?cursor=cD0yMDI1LTA5LTA4KzA3JTNBMzAlM0ExMi44NjgzMjUlMkIwMCUzQTAw&format=api", "previous": "https://api.plotly.com/v2/plots/?cursor=cj0xJnA9MjAyNS0wOS0wOCswOCUzQTIxJTNBNTMuNDI1OTI3JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2025-09-08T08:21:53.425927Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~singhtinka970/35.embed", "fid": "singhtinka970:35", "filename": "Plot pm 10", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/singhtinka970:35/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/singhtinka970:35/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/35/8_7BCKA85GKZ1Q2OCXKWUAXSL0LHJ27M.png", "list-thumb": "https://api.plotly.com/v2/files/singhtinka970:35/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/singhtinka970:35", "plots": "https://api.plotly.com/v2/plots/singhtinka970:35", "parent": "https://api.plotly.com/v2/folders/home?user=singhtinka970" }, "owner": "singhtinka970", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~singhtinka970/35/", "world_readable": true, "date_modified": "2025-09-08T08:30:47.883Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~singhtinka970/35/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Year", "y": "Vehicular Emissions" } }, "mode": "markers", "name": "<b>Road Dust Resuspension</b>", "type": "bar", "xsrc": "singhtinka970:34:3f149f", "ysrc": "singhtinka970:34:af0d02", "marker": { "line": { "color": "rgb(19, 1, 1)", "width": 2 }, "color": "rgb(148, 113, 6)" }, "error_x": { "type": "percent", "value": 10, "visible": false, "symmetric": true, "copy_ystyle": true }, "error_y": { "color": "rgb(0, 0, 0)", "visible": true, "symmetric": true }, "orientation": "v" }, { "meta": { "columnNames": { "x": "Year", "y": "Road Dust Resuspension" } }, "mode": "markers", "name": "<b>Vehicular Emissions</b>", "type": "bar", "xsrc": "singhtinka970:34:3f149f", "ysrc": "singhtinka970:34:ecb51d", "marker": { "line": { "color": "rgb(14, 0, 0)", "width": 2 }, "color": "rgb(229, 193, 149)" }, "error_y": { "visible": true, "symmetric": true }, "orientation": "v" }, { "meta": { "columnNames": { "x": "Year", "y": "Biomass Burning &amp; Household Activities" } }, "mode": "markers", "name": "<b>Biomass Burning & Household Activities</b>", "type": "bar", "xsrc": "singhtinka970:34:3f149f", "ysrc": "singhtinka970:34:af40c0", "marker": { "line": { "color": "rgb(15, 1, 1)", "width": 2 }, "color": "rgb(220, 228, 38)" }, "error_y": { "visible": true, "symmetric": true }, "orientation": "v" }, { "meta": { "columnNames": { "x": "Year", "y": "Construction Activities" } }, "mode": "markers", "name": "<b>Construction Activities</b>", "type": "bar", "xsrc": "singhtinka970:34:3f149f", "ysrc": "singhtinka970:34:9b45ce", "marker": { "line": { "color": "rgb(17, 1, 1)", "width": 2 }, "color": "rgb(32, 22, 176)" }, "error_y": { "visible": true, "symmetric": true }, "orientation": "v" }, { "meta": { "columnNames": { "x": "Year", "y": "Power Generation", "text": "" } }, "mode": "markers", "name": "<b>Power Generation</b>", "type": "bar", "xsrc": "singhtinka970:34:3f149f", "ysrc": "singhtinka970:34:8b0570", "marker": { "line": { "color": "rgb(17, 1, 1)", "width": 2 }, "color": "rgb(252, 8, 65)" }, "error_y": { "visible": true, "symmetric": true }, "textfont": { "size": 32, "color": "rgb(145, 142, 142)", "family": "Droid Serif" }, "orientation": "v", "textposition": "none" }, { "meta": { "columnNames": { "x": "Year", "y": "Avg", "text": "Avg" } }, "name": "<b>Average</b>", "type": "bar", "xsrc": "singhtinka970:34:3f149f", "ysrc": "singhtinka970:34:27828f", "marker": { "line": { "color": "rgb(17, 0, 0)", "width": 2 }, "color": "rgb(222, 133, 32)" }, "textsrc": "singhtinka970:34:27828f", "textfont": { "size": 14, "color": "rgb(16, 0, 0)", "family": "Overpass" }, "orientation": "v", "textposition": "outside" } ], "frames": [], "layout": { "title": { "font": { "size": 18, "color": "rgb(1, 0, 0)", "family": "Overpass" }, "text": "<b>PM 10 Emission Sources</b>" }, "xaxis": { "type": "linear", "range": [ 2018.5, 2024.5 ], "ticks": "outside", "title": { "font": { "size": 16, "color": "rgb(13, 0, 0)", "family": "Overpass" }, "text": "<b>Year</b>" }, "tickfont": { "size": 14, "color": "rgb(13, 1, 1)", "family": "Overpass" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 23.157894736842106 ], "ticks": "outside", "title": { "font": { "size": 16, "color": "rgb(13, 0, 0)", "family": "Overpass" }, "text": "<b>Concentration (0-100) µg/m³</b>" }, "tickfont": { "size": 14, "color": "rgb(13, 1, 1)", "family": "Overpass" }, "autorange": true }, "legend": { "x": 0.06774441878367975, "y": 1.077248122519668, "font": { "size": 12, "family": "Overpass" }, "orientation": "h" }, "barmode": "group", "barnorm": "", "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~singhtinka970", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-05 08:50:37", "mapbox_access_tokens": null, "has_password": null, "username": "singhtinka970", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-08T07:50:03.883943Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Virasat10/1.embed", "fid": "Virasat10:1", "filename": "Shiv 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Virasat10:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/Virasat10:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Virasat10/1/8_ES50666MUZY3O87JP2NWYGENZ8SULE.png", "list-thumb": "https://api.plotly.com/v2/files/Virasat10:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Virasat10:1", "plots": "https://api.plotly.com/v2/plots/Virasat10:1", "parent": "https://api.plotly.com/v2/folders/home?user=Virasat10" }, "owner": "Virasat10", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~Virasat10/1/", "world_readable": true, "date_modified": "2025-09-08T07:50:03.895Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Virasat10/1/", "current_user_permission": "read", "is_theme": null, "is_template": true, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "solid" }, "meta": { "columnNames": { "x": "Year", "y": "Plastic_obs" } }, "mode": "lines", "name": "Plastics (observed)", "type": "scatter", "xsrc": "Virasat10:0:f8eb81", "ysrc": "Virasat10:0:a3c171", "xaxis": "x", "yaxis": "y", "opacity": 1, "hoverlabel": { "align": "left" }, "connectgaps": false, "legendgroup": "" }, { "line": { "dash": "dot", "color": "rgb(80, 138, 210)", "width": 2 }, "meta": { "columnNames": { "x": "Year", "y": "Plastic_proj" } }, "mode": "lines", "name": "Plastics (projected)", "type": "scatter", "xsrc": "Virasat10:0:f8eb81", "ysrc": "Virasat10:0:c21d12", "yaxis": "y", "error_x": { "type": "percent", "color": "#EF553B", "value": 10, "width": 4, "visible": false, "symmetric": true, "thickness": 2 }, "visible": true, "hoverlabel": { "align": "left" }, "connectgaps": true, "legendgroup": "" }, { "meta": { "columnNames": { "x": "Year", "y": "Fertility_obs" } }, "mode": "lines", "name": "Fertility (observed)", "type": "scatter", "xsrc": "Virasat10:0:f8eb81", "ysrc": "Virasat10:0:1ee5f9", "xaxis": "x", "yaxis": "y2", "visible": true, "stackgroup": null, "legendgroup": "" }, { "line": { "dash": "dot", "color": "rgb(75, 204, 120)" }, "meta": { "columnNames": { "x": "Year", "y": "Fertility_proj" } }, "mode": "lines", "name": "Fertility (projected)", "type": "scatter", "xsrc": "Virasat10:0:f8eb81", "ysrc": "Virasat10:0:37aa31", "yaxis": "y2", "stackgroup": null, "legendgroup": "" } ], "frames": [], "layout": { "font": { "family": "Arial" }, "title": { "x": 0.22, "font": { "size": 16 }, "text": "Plastics vs Fertility Rate (2000–2050)" }, "xaxis": { "side": "bottom", "type": "linear", "range": [ 2000, 2050 ], "title": { "font": { "size": 12, "color": "rgb(14, 14, 14)" }, "text": "Year (2000–2050)" }, "anchor": "y", "domain": [ 0, 0.94 ], "showgrid": true, "showline": true, "autorange": false, "linecolor": "rgb(28, 31, 35)", "fixedrange": false, "showspikes": true, "rangeslider": { "range": [ 2000, 2050 ], "yaxis": {}, "yaxis2": {}, "visible": false, "autorange": true }, "zerolinewidth": 1, "spikethickness": 2 }, "yaxis": { "side": "left", "type": "linear", "range": [ 147.22222222222217, 1202.7777777777778 ], "tick0": 3, "ticks": "inside", "title": { "font": { "size": 12, "color": "rgb(107, 151, 218)" }, "text": "Plastic production (million tonnes)" }, "anchor": "x", "domain": [ 0, 1 ], "nticks": 7, "showline": true, "tickmode": "auto", "autorange": false, "gridwidth": 1, "linecolor": "rgb(30, 31, 31)", "showspikes": true }, "legend": { "x": 1.3, "y": 0.5, "title": { "text": "<br>" }, "valign": "middle", "bgcolor": "rgb(255, 255, 255)", "xanchor": "auto", "yanchor": "auto", "itemsizing": "trace", "traceorder": "normal", "borderwidth": 0, "orientation": "v", "tracegroupgap": 4 }, "margin": { "b": 78, "l": 67, "r": 75, "t": 80, "pad": 4 }, "shapes": [ { "x0": 2020, "x1": 2020, "y0": 0, "y1": 1, "line": { "dash": "dot", "color": "#444444", "width": 2 }, "type": "line", "opacity": 0.93, "visible": true, "fillcolor": "#7f7f7f" } ], "yaxis2": { "side": "right", "type": "linear", "range": [ 1.755555555555556, 2.6444444444444453 ], "tick0": 0, "ticks": "inside", "title": { "font": { "size": 12, "color": "rgb(87, 190, 122)" }, "text": "Fertility rate (births per woman)" }, "nticks": 0, "tickmode": "auto", "autorange": false, "overlaying": "y" }, "autosize": true, "dragmode": "select", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "hoverlabel": { "font": { "size": 12 } }, "annotations": [ { "text": "", "arrowhead": 0 } ], "selectdirection": "h" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Virasat10", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/84.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-08 04:20:45", "mapbox_access_tokens": null, "has_password": null, "username": "Virasat10", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-08T07:40:18.958593Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~singhtinka970/33.embed", "fid": "singhtinka970:33", "filename": "Plot 33", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/singhtinka970:33/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/singhtinka970:33/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/33/8_MOQBPMM3AX4S07J7R7OU5J8YNBFAU4.png", "list-thumb": "https://api.plotly.com/v2/files/singhtinka970:33/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/singhtinka970:33", "plots": "https://api.plotly.com/v2/plots/singhtinka970:33", "parent": "https://api.plotly.com/v2/folders/home?user=singhtinka970" }, "owner": "singhtinka970", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~singhtinka970/33/", "world_readable": true, "date_modified": "2025-09-09T08:58:43.640Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~singhtinka970/33/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Year", "y": "Vehicular Emissions" } }, "mode": "markers", "name": "<b>Industrial Emissions</b>", "type": "bar", "xsrc": "singhtinka970:32:3f149f", "ysrc": "singhtinka970:32:af0d02", "marker": { "line": { "color": "rgb(19, 1, 1)", "width": 2 }, "color": "rgb(148, 113, 6)" }, "error_x": { "type": "percent", "value": 10, "visible": false, "symmetric": true, "copy_ystyle": true }, "error_y": { "color": "rgb(0, 0, 0)", "visible": true, "symmetric": true }, "orientation": "v" }, { "meta": { "columnNames": { "x": "Year", "y": "Industrial Emissions" } }, "mode": "markers", "name": "<b>Vehicular Emissions</b>", "type": "bar", "xsrc": "singhtinka970:32:3f149f", "ysrc": "singhtinka970:32:ecb51d", "marker": { "line": { "color": "rgb(14, 0, 0)", "width": 2 }, "color": "rgb(229, 193, 149)" }, "error_y": { "visible": true, "symmetric": true }, "orientation": "v" }, { "meta": { "columnNames": { "x": "Year", "y": "Biomass Burning &amp; Household Activities" } }, "mode": "markers", "name": "<b>Biomass Burning & Household Activities</b>", "type": "bar", "xsrc": "singhtinka970:32:3f149f", "ysrc": "singhtinka970:32:af40c0", "marker": { "line": { "color": "rgb(15, 1, 1)", "width": 2 }, "color": "rgb(220, 228, 38)" }, "error_y": { "visible": true, "symmetric": true }, "orientation": "v" }, { "meta": { "columnNames": { "x": "Year", "y": "Construction Activities" } }, "mode": "markers", "name": "<b>Construction Activities</b>", "type": "bar", "xsrc": "singhtinka970:32:3f149f", "ysrc": "singhtinka970:32:9b45ce", "marker": { "line": { "color": "rgb(17, 1, 1)", "width": 2 }, "color": "rgb(32, 22, 176)" }, "error_y": { "visible": true, "symmetric": true }, "orientation": "v" }, { "meta": { "columnNames": { "x": "Year", "y": "Power Generation", "text": "" } }, "mode": "markers", "name": "<b>Power Generation</b>", "type": "bar", "xsrc": "singhtinka970:32:3f149f", "ysrc": "singhtinka970:32:8b0570", "marker": { "line": { "color": "rgb(17, 1, 1)", "width": 2 }, "color": "rgb(252, 8, 65)" }, "error_y": { "visible": true, "symmetric": true }, "textfont": { "size": 32, "color": "rgb(145, 142, 142)", "family": "Droid Serif" }, "orientation": "v", "textposition": "none" }, { "meta": { "columnNames": { "x": "Year", "y": "Avg", "text": "Avg" } }, "name": "<b>Average</b>", "type": "bar", "xsrc": "singhtinka970:32:3f149f", "ysrc": "singhtinka970:32:27828f", "marker": { "line": { "color": "rgb(17, 0, 0)", "width": 2 }, "color": "rgb(222, 133, 32)" }, "textsrc": "singhtinka970:32:27828f", "textfont": { "size": 14, "color": "rgb(16, 0, 0)", "family": "Overpass" }, "orientation": "v", "textposition": "outside" } ], "frames": [], "layout": { "title": { "font": { "size": 18, "color": "rgb(1, 0, 0)", "family": "Overpass" }, "text": "<b>PM 2.5 Emission Sources</b>" }, "xaxis": { "type": "linear", "range": [ 2018.5, 2024.5 ], "ticks": "outside", "title": { "font": { "size": 16, "color": "rgb(13, 0, 0)", "family": "Overpass" }, "text": "<b>Year</b>" }, "tickfont": { "size": 14, "color": "rgb(13, 1, 1)", "family": "Overpass" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 21.073684210526316 ], "ticks": "outside", "title": { "font": { "size": 16, "color": "rgb(13, 0, 0)", "family": "Overpass" }, "text": "<b>Concentration (0-100) µg/m³</b>" }, "tickfont": { "size": 14, "color": "rgb(13, 1, 1)", "family": "Overpass" }, "autorange": true }, "legend": { "x": 0.07929176289453425, "y": 1.077248122519668, "font": { "size": 12, "family": "Overpass" }, "orientation": "h" }, "barmode": "group", "barnorm": "", "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~singhtinka970", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-05 08:50:37", "mapbox_access_tokens": null, "has_password": null, "username": "singhtinka970", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-08T07:34:13.200377Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~singhtinka970/31.embed", "fid": "singhtinka970:31", "filename": "Plot 31", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/31/9_CDHBNQEF5A0TCG7536HVQH6ZX6MIJP.png", "image_urls": { "default": "https://api.plotly.com/v2/files/singhtinka970:31/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/31/8_CKHUUMAR75VSKWFHANSMHDD6P6SEB6.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/31/9_CDHBNQEF5A0TCG7536HVQH6ZX6MIJP.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/singhtinka970:31", "plots": "https://api.plotly.com/v2/plots/singhtinka970:31", "parent": "https://api.plotly.com/v2/folders/home?user=singhtinka970" }, "owner": "singhtinka970", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~singhtinka970/31/", "world_readable": true, "date_modified": "2025-09-08T07:34:13.212Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~singhtinka970/31/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "lat": "lat", "lon": "lon", "text": "text" } }, "mode": "markers", "type": "scattergeo", "latsrc": "singhtinka970:30:593f40", "lonsrc": "singhtinka970:30:9b501f", "marker": { "cmax": 345, "cmin": 0, "meta": { "columnNames": { "color": "color" } }, "size": 20, "symbol": "circle", "opacity": 0.8, "colorbar": { "size": 20, "title": { "text": "PM2.5 as pollutant" } }, "colorsrc": "singhtinka970:30:8f8dbd", "reversescale": false, "autocolorscale": true }, "textsrc": "singhtinka970:30:f787fa", "locationmode": "India" } ], "frames": [], "layout": { "geo": { "scope": "asia", "center": { "lat": 23.61097367916291, "lon": 80.3555029509925 }, "margin": { "b": 55, "l": 55, "p": 0, "r": 55, "t": 55, "autoexpand": true }, "showland": true, "landcolor": "rgb(250, 250, 250)", "projection": { "type": "delhi india" }, "countrycolor": "rgb(217, 217, 217)", "countrywidth": 0.8, "subunitcolor": "rgb(217, 217, 217)", "subunitwidth": 0.8 }, "title": { "text": "Pollution in India" }, "autosize": true, "colorbar": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~singhtinka970", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-05 08:50:37", "mapbox_access_tokens": null, "has_password": null, "username": "singhtinka970", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-08T07:34:03.758590Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~singhtinka970/29.embed", "fid": "singhtinka970:29", "filename": "Plot 29", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/singhtinka970:29/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/singhtinka970:29/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/29/8_92B0FZX75UFCCMHFQE2JX4KFO9WRRT.png", "list-thumb": "https://api.plotly.com/v2/files/singhtinka970:29/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/singhtinka970:29", "plots": "https://api.plotly.com/v2/plots/singhtinka970:29", "parent": "https://api.plotly.com/v2/folders/home?user=singhtinka970" }, "owner": "singhtinka970", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~singhtinka970/29/", "world_readable": true, "date_modified": "2025-09-08T07:34:03.770Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~singhtinka970/29/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "lat": "lat", "lon": "lon", "text": "text" } }, "mode": "markers", "type": "scattergeo", "latsrc": "singhtinka970:28:430582", "lonsrc": "singhtinka970:28:84a859", "marker": { "cmax": 285, "cmin": 0, "meta": { "columnNames": { "color": "color" } }, "size": 20, "symbol": "circle", "opacity": 0.8, "colorbar": { "size": 20, "title": { "text": "PM10 as pollutant" } }, "colorsrc": "singhtinka970:28:225a41", "reversescale": false, "autocolorscale": true }, "textsrc": "singhtinka970:28:6925b2", "locationmode": "India" } ], "frames": [], "layout": { "geo": { "scope": "asia", "center": { "lat": 23.61097367916291, "lon": 80.3555029509925 }, "margin": { "b": 55, "l": 55, "p": 0, "r": 55, "t": 55, "autoexpand": true }, "showland": true, "landcolor": "rgb(250, 250, 250)", "projection": { "type": "delhi india" }, "countrycolor": "rgb(217, 217, 217)", "countrywidth": 0.8, "subunitcolor": "rgb(217, 217, 217)", "subunitwidth": 0.8 }, "title": { "text": "Pollution in India" }, "autosize": true, "colorbar": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~singhtinka970", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-05 08:50:37", "mapbox_access_tokens": null, "has_password": null, "username": "singhtinka970", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-08T07:33:36.549360Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~singhtinka970/27.embed", "fid": "singhtinka970:27", "filename": "Plot 27", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/singhtinka970:27/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/singhtinka970:27/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/27/8_NU874FR9T9E6OYPJX2T8AS5CRSBZ7J.png", "list-thumb": "https://api.plotly.com/v2/files/singhtinka970:27/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/singhtinka970:27", "plots": "https://api.plotly.com/v2/plots/singhtinka970:27", "parent": "https://api.plotly.com/v2/folders/home?user=singhtinka970" }, "owner": "singhtinka970", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~singhtinka970/27/", "world_readable": true, "date_modified": "2025-09-08T07:34:24.399Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~singhtinka970/27/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "lat": "lat", "lon": "lon", "text": "text" } }, "mode": "markers", "type": "scattergeo", "latsrc": "singhtinka970:26:e46863", "lonsrc": "singhtinka970:26:8d73c9", "marker": { "cmax": 105, "cmin": 0, "meta": { "columnNames": { "color": "color" } }, "size": 20, "symbol": "circle", "opacity": 0.8, "colorbar": { "size": 20, "title": { "text": "SO2 as pollutant" } }, "colorsrc": "singhtinka970:26:c2c55b", "reversescale": false, "autocolorscale": true }, "textsrc": "singhtinka970:26:4939cd", "locationmode": "India" } ], "frames": [], "layout": { "geo": { "scope": "asia", "center": { "lat": 23.61097367916291, "lon": 80.3555029509925 }, "margin": { "b": 55, "l": 55, "p": 0, "r": 55, "t": 55, "autoexpand": true }, "showland": true, "landcolor": "rgb(250, 250, 250)", "projection": { "type": "delhi india" }, "countrycolor": "rgb(217, 217, 217)", "countrywidth": 0.8, "subunitcolor": "rgb(217, 217, 217)", "subunitwidth": 0.8 }, "title": { "text": "Pollution in India" }, "autosize": true, "colorbar": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~singhtinka970", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-05 08:50:37", "mapbox_access_tokens": null, "has_password": null, "username": "singhtinka970", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-08T07:33:17.449510Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~singhtinka970/25.embed", "fid": "singhtinka970:25", "filename": "Plot 25", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/singhtinka970:25/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/singhtinka970:25/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/25/8_0YHALSRCIM1003ABZLRRGMVGESFOAO.png", "list-thumb": "https://api.plotly.com/v2/files/singhtinka970:25/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/singhtinka970:25", "plots": "https://api.plotly.com/v2/plots/singhtinka970:25", "parent": "https://api.plotly.com/v2/folders/home?user=singhtinka970" }, "owner": "singhtinka970", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~singhtinka970/25/", "world_readable": true, "date_modified": "2025-09-08T11:41:33.796Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~singhtinka970/25/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(139,26,26,1)", "fillcolor": "rgba(139,26,26,0.5)" }, "meta": { "columnNames": { "x": "autumn, x", "y": "autumn, y" } }, "name": "<b>Autumn</b>", "type": "box", "xsrc": "singhtinka970:24:c6ba59", "ysrc": "singhtinka970:24:765d21", "xaxis": "x", "yaxis": "y" }, { "line": { "color": "rgba(238,44,44,1)", "fillcolor": "rgba(238,44,44,0.5)" }, "meta": { "columnNames": { "x": "winter, x", "y": "winter, y" } }, "name": "<b>Winter</b>", "type": "box", "xsrc": "singhtinka970:24:51f176", "ysrc": "singhtinka970:24:f74cca", "xaxis": "x", "yaxis": "y" }, { "line": { "color": "rgba(255,69,0,1)", "fillcolor": "rgba(255,69,0,0.5)" }, "meta": { "columnNames": { "x": "spring, x", "y": "spring, y" } }, "name": "<b>Spring</b>", "type": "box", "xsrc": "singhtinka970:24:f33bce", "ysrc": "singhtinka970:24:db55bc", "xaxis": "x", "yaxis": "y" }, { "line": { "color": "rgba(255,165,0,1)", "fillcolor": "rgba(255,165,0,0.5)" }, "meta": { "columnNames": { "x": "summer, x", "y": "summer, y" } }, "name": "<b>Summer</b>", "type": "box", "xsrc": "singhtinka970:24:c5fa9d", "ysrc": "singhtinka970:24:e38754", "xaxis": "x", "yaxis": "y" } ], "frames": [], "layout": { "font": { "size": 14, "color": "black", "family": "Overpass" }, "title": { "font": { "size": 18 }, "text": "Seasonal Trends" }, "xaxis": { "type": "category", "range": [ 2.4934924078091107, 5.506507592190889 ], "title": { "font": { "size": 17 }, "text": "" }, "domain": [ 0, 1 ], "autorange": true, "categoryarray": [ "canteras", "famara", "lambra" ], "categoryorder": "array" }, "yaxis": { "type": "linear", "range": [ -5.042777777777777, 95.81277777777777 ], "title": { "font": { "size": 17, "color": "rgb(28, 2, 2)", "family": "Overpass" }, "text": "<b>PM</b><sub><b>2.5</b></sub><b> Concentration</b> <b>µg/m³</b>" }, "domain": [ 0, 1 ], "autorange": true }, "legend": { "x": 0.04895608351331893, "y": 1.0230228471001757, "orientation": "h" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "boxmode": "group", "autosize": true, "showlegend": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~singhtinka970", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-05 08:50:37", "mapbox_access_tokens": null, "has_password": null, "username": "singhtinka970", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-08T07:32:45.961084Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~singhtinka970/23.embed", "fid": "singhtinka970:23", "filename": "Plot 23", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/23/9_WY5QR4X650K52GO5V552JU9GEFVEUJ.png", "image_urls": { "default": "https://api.plotly.com/v2/files/singhtinka970:23/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/23/8_WKO8JFYSMD3XGLBI7A71F9478FJLRW.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/23/9_WY5QR4X650K52GO5V552JU9GEFVEUJ.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/singhtinka970:23", "plots": "https://api.plotly.com/v2/plots/singhtinka970:23", "parent": "https://api.plotly.com/v2/folders/home?user=singhtinka970" }, "owner": "singhtinka970", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~singhtinka970/23/", "world_readable": true, "date_modified": "2025-09-08T07:32:45.973Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~singhtinka970/23/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "lat": "lat", "lon": "lon", "text": "text" } }, "mode": "markers", "type": "scattergeo", "latsrc": "singhtinka970:22:5819d1", "lonsrc": "singhtinka970:22:59c568", "marker": { "cmax": 121, "cmin": 0, "meta": { "columnNames": { "color": "color" } }, "size": 20, "symbol": "circle", "opacity": 0.8, "colorbar": { "size": 20, "title": { "text": "CO as pollutant" } }, "colorsrc": "singhtinka970:22:59c6fc", "reversescale": false, "autocolorscale": true }, "textsrc": "singhtinka970:22:b28732", "locationmode": "India" } ], "frames": [], "layout": { "geo": { "scope": "asia", "center": { "lat": 23.61097367916291, "lon": 80.3555029509925 }, "margin": { "b": 55, "l": 55, "p": 0, "r": 55, "t": 55, "autoexpand": true }, "showland": true, "landcolor": "rgb(250, 250, 250)", "projection": { "type": "delhi india" }, "countrycolor": "rgb(217, 217, 217)", "countrywidth": 0.8, "subunitcolor": "rgb(217, 217, 217)", "subunitwidth": 0.8 }, "title": { "text": "Pollution in India" }, "colorbar": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~singhtinka970", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-05 08:50:37", "mapbox_access_tokens": null, "has_password": null, "username": "singhtinka970", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-08T07:31:21.700827Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~singhtinka970/21.embed", "fid": "singhtinka970:21", "filename": "Plot 21", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/singhtinka970:21/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/21/2_5XDPBVTUEYSK7DWPRFKWARGPYN0SNX.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/21/8_T91MP4HRROC7UYJSN91ZC1AJG5SJCQ.png", "list-thumb": "https://api.plotly.com/v2/files/singhtinka970:21/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/singhtinka970:21", "plots": "https://api.plotly.com/v2/plots/singhtinka970:21", "parent": "https://api.plotly.com/v2/folders/home?user=singhtinka970" }, "owner": "singhtinka970", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~singhtinka970/21/", "world_readable": true, "date_modified": "2025-09-08T07:31:21.713Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~singhtinka970/21/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Good (0-30), y; Satisfactory (31-60), y; Moderately Polluted (61-90), y" } }, "name": "Good (0-30)", "type": "bar", "xsrc": "singhtinka970:20:d77b51", "ysrc": "singhtinka970:20:7aca56", "marker": { "color": "#508735" } }, { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Good (0-30), y; Satisfactory (31-60), y; Moderately Polluted (61-90), y" } }, "name": "Satisfactory (31-60)", "type": "bar", "xsrc": "singhtinka970:20:d77b51", "ysrc": "singhtinka970:20:7aca56", "marker": { "color": "#51D411" } }, { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Good (0-30), y; Satisfactory (31-60), y; Moderately Polluted (61-90), y" } }, "name": "Moderately Polluted (61-90)", "type": "bar", "xsrc": "singhtinka970:20:d77b51", "ysrc": "singhtinka970:20:7aca56", "marker": { "color": "#D4D111" } }, { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Poor (91-120), y" } }, "name": "Poor (91-120)", "type": "bar", "xsrc": "singhtinka970:20:d77b51", "ysrc": "singhtinka970:20:371d4e", "marker": { "color": "#F39C12" } }, { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Very Poor (121-250), y" } }, "name": "Very Poor (121-250)", "type": "bar", "xsrc": "singhtinka970:20:d77b51", "ysrc": "singhtinka970:20:a19e5d", "marker": { "color": "#E74C3C" } }, { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Severe (250+), y" } }, "name": "Severe (250+)", "type": "bar", "xsrc": "singhtinka970:20:d77b51", "ysrc": "singhtinka970:20:1e6a2f", "marker": { "color": "#922B21" } } ], "frames": [], "layout": { "title": { "text": "Pollution peaks at different timimgs AnandVihar" }, "xaxis": { "type": "category", "range": [ -0.5, 23.5 ], "title": { "text": "Time" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 51.578947368421055 ], "title": { "text": "No of Peaks" }, "autorange": true }, "barmode": "relative" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~singhtinka970", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-05 08:50:37", "mapbox_access_tokens": null, "has_password": null, "username": "singhtinka970", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-08T07:30:12.868325Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~singhtinka970/19.embed", "fid": "singhtinka970:19", "filename": "Plot 19", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/singhtinka970:19/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/singhtinka970:19/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/singhtinka970/19/8_HQ4NZFVTN3SDFKD8ZK2MHXCY67RO4X.png", "list-thumb": "https://api.plotly.com/v2/files/singhtinka970:19/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/singhtinka970:19", "plots": "https://api.plotly.com/v2/plots/singhtinka970:19", "parent": "https://api.plotly.com/v2/folders/home?user=singhtinka970" }, "owner": "singhtinka970", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~singhtinka970/19/", "world_readable": true, "date_modified": "2025-09-08T07:30:12.879Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~singhtinka970/19/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Good (0-30), y; Satisfactory (31-60), y; Moderately Polluted (61-90), y" } }, "name": "Good (0-30)", "type": "bar", "xsrc": "singhtinka970:18:a5d390", "ysrc": "singhtinka970:18:9af31c", "marker": { "color": "#508735" } }, { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Good (0-30), y; Satisfactory (31-60), y; Moderately Polluted (61-90), y" } }, "name": "Satisfactory (31-60)", "type": "bar", "xsrc": "singhtinka970:18:a5d390", "ysrc": "singhtinka970:18:9af31c", "marker": { "color": "#51D411" } }, { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Good (0-30), y; Satisfactory (31-60), y; Moderately Polluted (61-90), y" } }, "name": "Moderately Polluted (61-90)", "type": "bar", "xsrc": "singhtinka970:18:a5d390", "ysrc": "singhtinka970:18:9af31c", "marker": { "color": "#D4D111" } }, { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Poor (91-120), y" } }, "name": "Poor (91-120)", "type": "bar", "xsrc": "singhtinka970:18:a5d390", "ysrc": "singhtinka970:18:48631e", "marker": { "color": "#F39C12" } }, { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Very Poor (121-250), y" } }, "name": "Very Poor (121-250)", "type": "bar", "xsrc": "singhtinka970:18:a5d390", "ysrc": "singhtinka970:18:98f6b1", "marker": { "color": "#E74C3C" } }, { "meta": { "columnNames": { "x": "Good (0-30), x; Satisfactory (31-60), x; Moderately Polluted (61-90), x; Poor (91-120), x; Very Poor (121-250), x; Severe (250+), x", "y": "Severe (250+), y" } }, "name": "Severe (250+)", "type": "bar", "xsrc": "singhtinka970:18:a5d390", "ysrc": "singhtinka970:18:14dc83", "marker": { "color": "#922B21" } } ], "frames": [], "layout": { "title": { "text": "Pollution peaks at different locations AnandVihar" }, "xaxis": { "type": "category", "range": [ -0.5, 23.5 ], "title": { "text": "Station Name" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0, 51.578947368421055 ], "title": { "text": "No of Peaks" }, "autorange": true }, "barmode": "relative", "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~singhtinka970", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/62.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-05 08:50:37", "mapbox_access_tokens": null, "has_password": null, "username": "singhtinka970", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
