Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDI1LTA2LTA1KzIxJTNBMjglM0E1MS45ODcwMDElMkIwMCUzQTAw&format=api
{ "next": "https://api.plotly.com/v2/plots?cursor=cD0yMDI1LTA2LTA1KzIxJTNBMTYlM0E0NS4wOTIxOTIlMkIwMCUzQTAw&format=api", "previous": "https://api.plotly.com/v2/plots?cursor=cj0xJnA9MjAyNS0wNi0wNSsyMSUzQTIxJTNBMDguMTM2NzQ5JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2025-06-05T21:21:08.136749Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38610.embed", "fid": "cpsievert:38610", "filename": "Plot 38610", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38610/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38610/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38610/8_U5EAZYER9A7XB7KPEF7PAHHYLDB2ZQ.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38610/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38610", "plots": "https://api.plotly.com/v2/plots/cpsievert:38610", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38610/", "world_readable": true, "date_modified": "2025-06-05T21:21:08.178Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38610/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "bar", "xsrc": "cpsievert:38609:1dbbcf", "ysrc": "cpsievert:38609:79525a", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "transparent", "width": 1.8897637795275593 }, "color": "rgba(89,89,89,1)", "autocolorscale": false }, "basesrc": "cpsievert:38609:2d09fd", "textsrc": "cpsievert:38609:81b0db", "widthsrc": "cpsievert:38609:a24e84", "hoverinfo": "text", "showlegend": false, "orientation": "v", "textposition": "none" } ], "layout": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "xaxis": { "type": "linear", "range": [ 0.055000000000000104, 10.944999999999999 ], "ticks": "outside", "title": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "text": "1:10" }, "anchor": "y", "domain": [ 0, 1 ], "nticks": null, "ticklen": 3.652968036529681, "showgrid": true, "showline": false, "tickfont": { "size": 11.68949771689498, "color": "rgba(77,77,77,1)", "family": "" }, "tickmode": "array", "ticktext": [ "2.5", "5.0", "7.5", "10.0" ], "tickvals": [ 2.5, 5, 7.500000000000001, 10 ], "zeroline": false, "autorange": false, "gridcolor": "rgba(255,255,255,1)", "gridwidth": 0.66417600664176, "linecolor": null, "linewidth": 0, "tickangle": 0, "tickcolor": "rgba(51,51,51,1)", "tickwidth": 0.66417600664176, "automargin": true, "hoverformat": ".2f", "categoryarray": [ "2.5", "5.0", "7.5", "10.0" ], "categoryorder": "array", "showticklabels": true }, "yaxis": { "type": "linear", "range": [ -0.05, 1.05 ], "ticks": "outside", "title": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "text": "count" }, "anchor": "x", "domain": [ 0, 1 ], "nticks": null, "ticklen": 3.652968036529681, "showgrid": true, "showline": false, "tickfont": { "size": 11.68949771689498, "color": "rgba(77,77,77,1)", "family": "" }, "tickmode": "array", "ticktext": [ "0.00", "0.25", "0.50", "0.75", "1.00" ], "tickvals": [ 0, 0.25, 0.5, 0.75, 1 ], "zeroline": false, "autorange": false, "gridcolor": "rgba(255,255,255,1)", "gridwidth": 0.66417600664176, "linecolor": null, "linewidth": 0, "tickangle": 0, "tickcolor": "rgba(51,51,51,1)", "tickwidth": 0.66417600664176, "automargin": true, "hoverformat": ".2f", "categoryarray": [ "0.00", "0.25", "0.50", "0.75", "1.00" ], "categoryorder": "array", "showticklabels": true }, "legend": { "font": { "size": 11.68949771689498, "color": "rgba(0,0,0,1)", "family": "" }, "bgcolor": "rgba(255,255,255,1)", "bordercolor": "transparent", "borderwidth": 1.8897637795275593 }, "margin": { "b": 39.69558599695587, "l": 48.94977168949772, "r": 7.305936073059362, "t": 25.74124809741248 }, "shapes": [ { "x0": 0, "x1": 1, "y0": 0, "y1": 1, "line": { "color": null, "width": 0, "linetype": [] }, "type": "rect", "xref": "paper", "yref": "paper", "layer": "below", "fillcolor": null } ], "barmode": "relative", "hovermode": "closest", "showlegend": false, "plot_bgcolor": "rgba(235,235,235,1)", "paper_bgcolor": "rgba(255,255,255,1)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T21:21:05.878278Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38608.embed", "fid": "cpsievert:38608", "filename": "Plot 38608", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38608/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38608/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38608/8_Q3XB4MAZDSE53D7I4Z6TSMNNHJ8T6A.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38608/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38608", "plots": "https://api.plotly.com/v2/plots/cpsievert:38608", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38608/", "world_readable": true, "date_modified": "2025-06-05T21:21:05.911Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38608/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38607:88e3a9", "ysrc": "cpsievert:38607:8b93da", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38607:97ce49", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38607:60dc7b", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true }, { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38607:fbed83", "ysrc": "cpsievert:38607:a17527", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "color": "rgba(255,127,14,1)" }, "colorbar": { "y": 1, "len": 0.5, "title": "", "lenmode": "fraction", "ticklen": 2, "yanchor": "top" }, "colorsrc": "cpsievert:38607:2b8198", "showscale": true, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "opacity": 0, "hoverinfo": "none", "showlegend": false } ], "frames": [ { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38607:58a388", "ysrc": "cpsievert:38607:77e6e3", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38607:11d254", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38607:087b1d", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true } ], "name": "1", "traces": [ 0 ] }, { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38607:2f0cd0", "ysrc": "cpsievert:38607:41ae29", "frame": "2", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38607:dc666e", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38607:1d9825", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true } ], "name": "2", "traces": [ 0 ] } ], "layout": { "xaxis": { "range": [ 0.55, 10.45 ], "title": [], "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "range": [ 0.55, 10.45 ], "title": [], "domain": [ 0, 1 ], "automargin": true }, "legend": { "y": 0.5, "yanchor": "top" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "sliders": [ { "pad": { "t": 40 }, "steps": [ { "args": [ [ "1" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "1", "value": "1", "method": "animate" }, { "args": [ [ "2" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "2", "value": "2", "method": "animate" } ], "visible": true } ], "hovermode": "closest", "showlegend": false, "updatemenus": [ { "x": 0, "y": 0, "pad": { "r": 5, "t": 60 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 }, "fromcurrent": true } ], "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "direction": "right", "showactive": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T21:21:03.893907Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38606.embed", "fid": "cpsievert:38606", "filename": "Plot 38606", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38606/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38606/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38606/8_EWTVAE7J4Q4UDCKU38KYEANDNKSBK7.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38606/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38606", "plots": "https://api.plotly.com/v2/plots/cpsievert:38606", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38606/", "world_readable": true, "date_modified": "2025-06-05T21:21:03.961Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38606/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38605:0b3607", "ysrc": "cpsievert:38605:a1d407", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38605:90684a", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38605:047782", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] } }, { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38605:1a139a", "ysrc": "cpsievert:38605:5177b5", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "color": "rgba(255,127,14,1)" }, "colorbar": { "y": 1, "len": 0.5, "title": "", "lenmode": "fraction", "ticklen": 2, "yanchor": "top" }, "colorsrc": "cpsievert:38605:5cc1a3", "showscale": true, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "opacity": 0, "hoverinfo": "none", "showlegend": false } ], "layout": { "xaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "legend": { "y": 0.5, "yanchor": "top" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T21:21:02.091214Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38604.embed", "fid": "cpsievert:38604", "filename": "Plot 38604", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38604/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38604/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38604/8_659G5XNZ8TF1HDSP33BP0IF0K2785Y.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38604/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38604", "plots": "https://api.plotly.com/v2/plots/cpsievert:38604", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38604/", "world_readable": true, "date_modified": "2025-06-05T21:21:02.126Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38604/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(31,119,180,1)" }, "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38603:39f827", "ysrc": "cpsievert:38603:45c3de", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(31,119,180,1)" }, "color": "red" }, "error_x": { "color": "rgba(31,119,180,1)" }, "error_y": { "color": "rgba(31,119,180,1)" } } ], "layout": { "xaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T21:20:59.302360Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38602.embed", "fid": "cpsievert:38602", "filename": "9b81a1d4d98", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38602/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38602/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38602/8_Q80IGQPDDUTMLAZRDYL7J12FSIDOJJ.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38602/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38602", "plots": "https://api.plotly.com/v2/plots/cpsievert:38602", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38602/", "world_readable": true, "date_modified": "2025-06-05T21:21:00.447Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38602/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(31,119,180,1)" }, "mode": "markers", "type": "scatter", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(31,119,180,1)" }, "color": "rgba(31,119,180,1)" }, "error_x": { "color": "rgba(31,119,180,1)" }, "error_y": { "color": "rgba(31,119,180,1)" } } ], "layout": { "title": "test", "xaxis": { "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T21:20:50.519978Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38600.embed", "fid": "cpsievert:38600", "filename": "Plot 38600", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38600/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38600/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38600/8_9C6WVJ5XATHTEQBP8BRI8KUJT2ZQMO.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38600/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38600", "plots": "https://api.plotly.com/v2/plots/cpsievert:38600", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38600/", "world_readable": true, "date_modified": "2025-06-05T21:20:50.552Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38600/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38599:7cfb22", "ysrc": "cpsievert:38599:108e12", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "visible": true, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38599:ce84ce", "ysrc": "cpsievert:38599:419670", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "visible": true, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38599:16ae70", "ysrc": "cpsievert:38599:655af4", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "visible": true, "textfont": { "color": "rgba(141,160,203,1)" } } ], "frames": [ { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38599:a75c91", "ysrc": "cpsievert:38599:b2e3de", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "visible": true, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38599:f8d59d", "ysrc": "cpsievert:38599:06ebe0", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "visible": true, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38599:bbfd44", "ysrc": "cpsievert:38599:8e1ed4", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "visible": true, "textfont": { "color": "rgba(141,160,203,1)" } } ], "name": "0", "traces": [ 0, 1, 2 ] }, { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38599:37b9b5", "ysrc": "cpsievert:38599:abbea7", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "visible": true, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38599:6e41c8", "ysrc": "cpsievert:38599:6549aa", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "visible": true, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38599:b1fc0b", "ysrc": "cpsievert:38599:bf2737", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "visible": false, "textfont": { "color": "rgba(141,160,203,1)" } } ], "name": "1", "traces": [ 0, 1, 2 ] } ], "layout": { "xaxis": { "range": [ 9.225, 35.074999999999996 ], "title": "mpg", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "range": [ 1.3174499999999998, 5.61955 ], "title": "wt", "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "sliders": [ { "pad": { "t": 40 }, "steps": [ { "args": [ [ "0" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "0", "value": "0", "method": "animate" }, { "args": [ [ "1" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "1", "value": "1", "method": "animate" } ], "visible": true, "currentvalue": { "font": { "size": 16, "color": "rgba(204,204,204,1)" }, "prefix": "factor(vs): ", "xanchor": "right" } } ], "hovermode": "closest", "showlegend": true, "updatemenus": [ { "x": 0, "y": 0, "pad": { "r": 5, "t": 60 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 }, "fromcurrent": true } ], "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "direction": "right", "showactive": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T21:20:44.464369Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38598.embed", "fid": "cpsievert:38598", "filename": "Plot 38598", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38598/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38598/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38598/8_5W4QHJWCRGH74UG917KXHMJ4QVD7T0.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38598/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38598", "plots": "https://api.plotly.com/v2/plots/cpsievert:38598", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38598/", "world_readable": true, "date_modified": "2025-06-05T21:20:44.502Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38598/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38597:2998fc", "ysrc": "cpsievert:38597:2cf9b1", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38597:1170ef", "ysrc": "cpsievert:38597:6728e5", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38597:b7cd3f", "ysrc": "cpsievert:38597:9a8f9d", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "textfont": { "color": "rgba(141,160,203,1)" } } ], "layout": { "xaxis": { "title": "mpg", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": "wt", "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T21:20:38.292439Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38596.embed", "fid": "cpsievert:38596", "filename": "Plot 38596", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38596/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38596/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38596/8_H2VNE3BEM7A19JN92BKJV8UYZVU14X.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38596/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38596", "plots": "https://api.plotly.com/v2/plots/cpsievert:38596", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38596/", "world_readable": true, "date_modified": "2025-06-05T21:20:38.326Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38596/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(31,119,180,1)" }, "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38595:504cbd", "ysrc": "cpsievert:38595:961c77", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(31,119,180,1)" }, "color": "rgba(31,119,180,1)" }, "error_x": { "color": "rgba(31,119,180,1)" }, "error_y": { "color": "rgba(31,119,180,1)" } } ], "layout": { "xaxis": { "title": "mpg", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": "wt", "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T21:16:46.942740Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38591.embed", "fid": "cpsievert:38591", "filename": "Plot 38591", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38591/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38591/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38591/8_5QDLUZBFQA7YT5N6LAAIL0TV5AUCKP.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38591/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38591", "plots": "https://api.plotly.com/v2/plots/cpsievert:38591", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38591/", "world_readable": true, "date_modified": "2025-06-05T21:16:46.976Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38591/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "bar", "xsrc": "cpsievert:38590:a3b22f", "ysrc": "cpsievert:38590:942f12", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "transparent", "width": 1.8897637795275593 }, "color": "rgba(89,89,89,1)", "autocolorscale": false }, "basesrc": "cpsievert:38590:ab2e74", "textsrc": "cpsievert:38590:d7ac4e", "widthsrc": "cpsievert:38590:cc8112", "hoverinfo": "text", "showlegend": false, "orientation": "v", "textposition": "none" } ], "layout": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "xaxis": { "type": "linear", "range": [ 0.055000000000000104, 10.944999999999999 ], "ticks": "outside", "title": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "text": "1:10" }, "anchor": "y", "domain": [ 0, 1 ], "nticks": null, "ticklen": 3.652968036529681, "showgrid": true, "showline": false, "tickfont": { "size": 11.68949771689498, "color": "rgba(77,77,77,1)", "family": "" }, "tickmode": "array", "ticktext": [ "2.5", "5.0", "7.5", "10.0" ], "tickvals": [ 2.5, 5, 7.500000000000001, 10 ], "zeroline": false, "autorange": false, "gridcolor": "rgba(255,255,255,1)", "gridwidth": 0.66417600664176, "linecolor": null, "linewidth": 0, "tickangle": 0, "tickcolor": "rgba(51,51,51,1)", "tickwidth": 0.66417600664176, "automargin": true, "hoverformat": ".2f", "categoryarray": [ "2.5", "5.0", "7.5", "10.0" ], "categoryorder": "array", "showticklabels": true }, "yaxis": { "type": "linear", "range": [ -0.05, 1.05 ], "ticks": "outside", "title": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "text": "count" }, "anchor": "x", "domain": [ 0, 1 ], "nticks": null, "ticklen": 3.652968036529681, "showgrid": true, "showline": false, "tickfont": { "size": 11.68949771689498, "color": "rgba(77,77,77,1)", "family": "" }, "tickmode": "array", "ticktext": [ "0.00", "0.25", "0.50", "0.75", "1.00" ], "tickvals": [ 0, 0.25, 0.5, 0.75, 1 ], "zeroline": false, "autorange": false, "gridcolor": "rgba(255,255,255,1)", "gridwidth": 0.66417600664176, "linecolor": null, "linewidth": 0, "tickangle": 0, "tickcolor": "rgba(51,51,51,1)", "tickwidth": 0.66417600664176, "automargin": true, "hoverformat": ".2f", "categoryarray": [ "0.00", "0.25", "0.50", "0.75", "1.00" ], "categoryorder": "array", "showticklabels": true }, "legend": { "font": { "size": 11.68949771689498, "color": "rgba(0,0,0,1)", "family": "" }, "bgcolor": "rgba(255,255,255,1)", "bordercolor": "transparent", "borderwidth": 1.8897637795275593 }, "margin": { "b": 39.69558599695587, "l": 48.94977168949772, "r": 7.305936073059362, "t": 25.74124809741248 }, "shapes": [ { "x0": 0, "x1": 1, "y0": 0, "y1": 1, "line": { "color": null, "width": 0, "linetype": [] }, "type": "rect", "xref": "paper", "yref": "paper", "layer": "below", "fillcolor": null } ], "barmode": "relative", "hovermode": "closest", "showlegend": false, "plot_bgcolor": "rgba(235,235,235,1)", "paper_bgcolor": "rgba(255,255,255,1)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T21:16:45.092192Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38589.embed", "fid": "cpsievert:38589", "filename": "Plot 38589", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38589/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/cpsievert:38589/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38589/8_GY1KPK4IGC1CDS3LC5MD30T2YRNK43.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38589/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38589", "plots": "https://api.plotly.com/v2/plots/cpsievert:38589", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38589/", "world_readable": true, "date_modified": "2025-06-05T21:16:45.123Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38589/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38588:ba6ca0", "ysrc": "cpsievert:38588:001998", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38588:dd3f38", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38588:d55499", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true }, { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38588:0e80eb", "ysrc": "cpsievert:38588:f80a80", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "color": "rgba(255,127,14,1)" }, "colorbar": { "y": 1, "len": 0.5, "title": "", "lenmode": "fraction", "ticklen": 2, "yanchor": "top" }, "colorsrc": "cpsievert:38588:4c3364", "showscale": true, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "opacity": 0, "hoverinfo": "none", "showlegend": false } ], "frames": [ { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38588:6154be", "ysrc": "cpsievert:38588:91e3c8", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38588:c49e5e", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38588:be2bf6", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true } ], "name": "1", "traces": [ 0 ] }, { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38588:0c8a5f", "ysrc": "cpsievert:38588:dc0948", "frame": "2", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38588:d518d3", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38588:cb2178", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true } ], "name": "2", "traces": [ 0 ] } ], "layout": { "xaxis": { "range": [ 0.55, 10.45 ], "title": [], "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "range": [ 0.55, 10.45 ], "title": [], "domain": [ 0, 1 ], "automargin": true }, "legend": { "y": 0.5, "yanchor": "top" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "sliders": [ { "pad": { "t": 40 }, "steps": [ { "args": [ [ "1" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "1", "value": "1", "method": "animate" }, { "args": [ [ "2" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "2", "value": "2", "method": "animate" } ], "visible": true } ], "hovermode": "closest", "showlegend": false, "updatemenus": [ { "x": 0, "y": 0, "pad": { "r": 5, "t": 60 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 }, "fromcurrent": true } ], "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "direction": "right", "showactive": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
