Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?format=api
{ "next": "https://api.plotly.com/v2/plots?cursor=cD0yMDI1LTEwLTE0KzE4JTNBNDAlM0ExNS4yODkxMzElMkIwMCUzQTAw&format=api", "previous": null, "results": [ { "creation_time": "2025-10-14T22:45:32.302446Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~paperness/309.embed", "fid": "paperness:309", "filename": "when modal pp copy", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/paperness:309/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/paperness:309/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/paperness/309/8_VYIFI148BZTYD7H67MS18YATKQI590.png", "list-thumb": "https://api.plotly.com/v2/files/paperness:309/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/paperness:309", "plots": "https://api.plotly.com/v2/plots/paperness:309", "parent": "https://api.plotly.com/v2/folders/home?user=paperness" }, "owner": "paperness", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~paperness/309/", "world_readable": true, "date_modified": "2025-10-14T22:45:33.865Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~paperness/309/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "B", "y": "acan", "labels": "B", "values": "acan" } }, "mode": "markers", "type": "bar", "xsrc": "paperness:308:b234d2", "ysrc": "paperness:308:832ff4", "contours": { "end": 0.9, "size": 0.1, "start": 0.1 }, "bandwidth": 0, "boxpoints": false, "labelssrc": "paperness:308:b234d2", "valuessrc": "paperness:308:832ff4", "autocontour": true, "orientation": "v", "autocolorscale": true }, { "meta": { "columnNames": { "x": "B", "y": "ashould" } }, "type": "bar", "xsrc": "paperness:308:b234d2", "ysrc": "paperness:308:80c28e", "xaxis": "x6", "yaxis": "y5", "marker": { "color": "rgb(231, 99, 250)" }, "orientation": "v" }, { "meta": { "columnNames": { "x": "B", "y": "awill" } }, "type": "bar", "xsrc": "paperness:308:b234d2", "ysrc": "paperness:308:0d7838", "xaxis": "x7", "yaxis": "y5", "marker": { "color": "rgb(254, 203, 82)" }, "orientation": "v" }, { "meta": { "columnNames": { "x": "B", "y": "awould" } }, "type": "bar", "xsrc": "paperness:308:b234d2", "ysrc": "paperness:308:2eace6", "xaxis": "x8", "yaxis": "y5", "marker": { "color": "rgb(255, 161, 90)" }, "orientation": "v" } ], "frames": [], "layout": { "title": { "font": { "size": 24 }, "text": "when" }, "xaxis": { "side": "top", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "can" }, "domain": [ 0, 0.25 ], "tickfont": { "size": 14 }, "autorange": true, "automargin": true, "showticklabels": false }, "yaxis": { "range": [ 0, 65 ], "title": { "text": "" }, "anchor": "x", "domain": [ 0.625, 1 ], "autorange": false, "ticksuffix": "%", "showticklabels": true }, "xaxis2": { "range": [ 3, 5 ], "autorange": true }, "xaxis3": { "range": [ 1, 3 ], "autorange": true }, "xaxis4": { "range": [ -1, 1 ], "title": { "text": "" }, "autorange": true }, "xaxis6": { "side": "top", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "should" }, "anchor": "y5", "domain": [ 0.25, 0.5 ], "autorange": true, "overlaying": false, "showticklabels": false }, "xaxis7": { "side": "top", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "will" }, "anchor": "y5", "domain": [ 0.5, 0.75 ], "autorange": true, "overlaying": false, "showticklabels": false }, "xaxis8": { "side": "top", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "would" }, "anchor": "y5", "domain": [ 0.75, 1 ], "autorange": true, "overlaying": false, "showticklabels": false }, "yaxis5": { "side": "left", "type": "linear", "range": [ 0, 65 ], "title": { "text": "" }, "anchor": "x5", "domain": [ 0.625, 1 ], "autorange": false, "overlaying": false, "ticksuffix": "%", "showticklabels": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "showlegend": false, "annotations": [ { "x": 0, "y": 0.58, "ax": -5, "ay": -30, "font": { "size": 18 }, "text": "I", "xref": "paper", "yref": "paper", "axref": "pixel", "yanchor": "middle", "showarrow": false, "textangle": 90 }, { "x": 1, "y": 0.55, "font": { "size": 18 }, "text": "we", "yref": "paper", "showarrow": false, "textangle": 90 }, { "x": 2, "y": 0.54, "font": { "size": 18 }, "text": "you", "yref": "paper", "showarrow": false, "textangle": 90 }, { "x": 3, "y": 0.24, "font": { "size": 18 }, "text": "he/she/they", "yref": "paper", "showarrow": false, "textangle": 90 }, { "x": 4, "y": 0.16, "font": { "size": 16 }, "text": "it/a/the/this/that", "yref": "paper", "showarrow": false, "textangle": 90 }, { "x": 0, "y": 0.58, "font": { "size": 18 }, "text": "I", "xref": "x6", "yref": "paper", "axref": "x6", "showarrow": false, "textangle": 90 }, { "x": 1, "y": 0.55, "font": { "size": 18 }, "text": "we", "xref": "x6", "yref": "paper", "axref": "x6", "showarrow": false, "textangle": 90 }, { "x": 2, "y": 0.54, "font": { "size": 18 }, "text": "you", "xref": "x6", "yref": "paper", "axref": "x6", "showarrow": false, "textangle": 90 }, { "x": 3, "y": 0.24, "font": { "size": 18 }, "text": "he/she/they", "xref": "x6", "yref": "paper", "axref": "x6", "showarrow": false, "textangle": 90 }, { "x": 4, "y": 0.16, "font": { "size": 16 }, "text": "it/a/the/this/that", "xref": "x6", "yref": "paper", "axref": "x6", "showarrow": false, "textangle": 90 }, { "x": 0, "y": 0.58, "font": { "size": 18 }, "text": "I", "xref": "x7", "yref": "paper", "axref": "x7", "showarrow": false, "textangle": 90 }, { "x": 1, "y": 0.55, "font": { "size": 18 }, "text": "we", "xref": "x7", "yref": "paper", "axref": "x7", "showarrow": false, "textangle": 90 }, { "x": 2, "y": 0.54, "font": { "size": 18 }, "text": "you", "xref": "x7", "yref": "paper", "axref": "x7", "showarrow": false, "textangle": 90 }, { "x": 3, "y": 0.24, "font": { "size": 18 }, "text": "he/she/they", "xref": "x7", "yref": "paper", "axref": "x7", "showarrow": false, "textangle": 90 }, { "x": 4, "y": 0.2, "font": { "size": 15 }, "text": "it/a/the/this/that", "xref": "x7", "yref": "paper", "axref": "x7", "showarrow": false, "textangle": 90 }, { "x": 0, "y": 0.58, "font": { "size": 18 }, "text": "I", "xref": "x8", "yref": "paper", "axref": "x8", "showarrow": false, "textangle": 90 }, { "x": 1, "y": 0.55, "font": { "size": 18 }, "text": "we", "xref": "x8", "yref": "paper", "axref": "x8", "showarrow": false, "textangle": 90 }, { "x": 2, "y": 0.54, "font": { "size": 18 }, "text": "you", "xref": "x8", "yref": "paper", "axref": "x8", "showarrow": false, "textangle": 90 }, { "x": 3, "y": 0.24, "font": { "size": 18 }, "text": "he/she/they", "xref": "x8", "yref": "paper", "axref": "x8", "xanchor": "auto", "showarrow": false, "textangle": 90 }, { "x": 4, "y": 0.16, "font": { "size": 16 }, "text": "it/a/the/this/that", "xref": "x8", "yref": "paper", "axref": "x8", "showarrow": false, "textangle": 90 } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~paperness", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/46.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-17 14:54:53", "mapbox_access_tokens": null, "has_password": null, "username": "paperness", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-10-14T22:00:50.697379Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~paperness/303.embed", "fid": "paperness:303", "filename": "yesnosujet", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/paperness:303/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/paperness:303/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/paperness/303/8_D47J5MWGJDTFUBGC10ZGSFR9Q08QZW.png", "list-thumb": "https://api.plotly.com/v2/files/paperness:303/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/paperness:303", "plots": "https://api.plotly.com/v2/plots/paperness:303", "parent": "https://api.plotly.com/v2/folders/home?user=paperness" }, "owner": "paperness", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~paperness/303/", "world_readable": true, "date_modified": "2025-10-14T22:44:37.212Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~paperness/303/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "B", "y": "acan", "labels": "B", "values": "acan" } }, "mode": "markers", "name": "can", "type": "bar", "xsrc": "paperness:302:b234d2", "ysrc": "paperness:302:832ff4", "contours": { "end": 0.9, "size": 0.1, "start": 0.1 }, "bandwidth": 0, "boxpoints": false, "labelssrc": "paperness:302:b234d2", "valuessrc": "paperness:302:832ff4", "autocontour": true, "orientation": "v", "autocolorscale": true }, { "meta": { "columnNames": { "x": "B", "y": "acould" } }, "name": "could", "type": "bar", "xsrc": "paperness:302:b234d2", "ysrc": "paperness:302:3e8e53", "xaxis": "x2", "yaxis": "y", "orientation": "v" }, { "meta": { "columnNames": { "x": "B", "y": "amight" } }, "name": "might", "type": "bar", "xsrc": "paperness:302:b234d2", "ysrc": "paperness:302:79963b", "xaxis": "x3", "yaxis": "y", "orientation": "v" }, { "meta": { "columnNames": { "x": "B", "y": "amust" } }, "name": "must", "type": "bar", "xsrc": "paperness:302:b234d2", "ysrc": "paperness:302:a24b9e", "xaxis": "x4", "yaxis": "y", "orientation": "v" }, { "meta": { "columnNames": { "x": "B", "y": "ashall" } }, "name": "shall", "type": "bar", "xsrc": "paperness:302:b234d2", "ysrc": "paperness:302:a03b1e", "xaxis": "x5", "yaxis": "y5", "orientation": "v" }, { "meta": { "columnNames": { "x": "B", "y": "ashould" } }, "name": "should", "type": "bar", "xsrc": "paperness:302:b234d2", "ysrc": "paperness:302:80c28e", "xaxis": "x6", "yaxis": "y5", "orientation": "v" }, { "meta": { "columnNames": { "x": "B", "y": "awill" } }, "name": "will", "type": "bar", "xsrc": "paperness:302:b234d2", "ysrc": "paperness:302:0d7838", "xaxis": "x7", "yaxis": "y5", "orientation": "v" }, { "meta": { "columnNames": { "x": "B", "y": "awould" } }, "name": "would", "type": "bar", "xsrc": "paperness:302:b234d2", "ysrc": "paperness:302:2eace6", "xaxis": "x8", "yaxis": "y5", "orientation": "v" }, { "meta": { "columnNames": { "x": "B", "y": "amay" } }, "name": "may", "type": "bar", "xsrc": "paperness:302:b234d2", "ysrc": "paperness:302:986d44", "xaxis": "x9", "marker": { "color": "rgb(207, 255, 102)" }, "orientation": "v" } ], "frames": [], "layout": { "title": { "font": { "size": 24 }, "text": "yes/no" }, "xaxis": { "side": "top", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "can" }, "domain": [ 0, 0.19 ], "tickfont": { "size": 14 }, "autorange": true, "automargin": true, "showticklabels": false }, "yaxis": { "side": "left", "type": "linear", "range": [ 0, 65 ], "title": { "text": "" }, "anchor": "x", "domain": [ 0.625, 1 ], "autorange": false, "ticksuffix": "%", "showticklabels": true }, "xaxis2": { "side": "top", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "could" }, "anchor": "y", "domain": [ 0.2, 0.39 ], "autorange": true, "overlaying": false, "showticklabels": false }, "xaxis3": { "side": "top", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "might" }, "anchor": "y3", "domain": [ 0.6, 0.79 ], "autorange": true, "overlaying": false, "showticklabels": false }, "xaxis4": { "side": "top", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "must" }, "anchor": "y4", "domain": [ 0.8, 1 ], "autorange": true, "overlaying": false, "showticklabels": false }, "xaxis5": { "side": "bottom", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "shall" }, "anchor": "y5", "domain": [ 0, 0.19 ], "autorange": true, "overlaying": false, "showticklabels": false }, "xaxis6": { "side": "bottom", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "should" }, "anchor": "y5", "domain": [ 0.2, 0.39 ], "autorange": true, "overlaying": false, "showticklabels": false }, "xaxis7": { "side": "bottom", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "will" }, "anchor": "y5", "domain": [ 0.4, 0.59 ], "autorange": true, "overlaying": false, "showticklabels": false }, "xaxis8": { "side": "bottom", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "would" }, "anchor": "y5", "domain": [ 0.6, 0.79 ], "autorange": true, "overlaying": false, "showticklabels": false }, "xaxis9": { "side": "top", "type": "category", "range": [ -0.5, 4.5 ], "title": { "text": "may" }, "anchor": "y", "domain": [ 0.4, 0.59 ], "autorange": true, "overlaying": false, "showticklabels": false }, "yaxis5": { "side": "left", "type": "linear", "range": [ 0, 65 ], "title": { "text": "" }, "anchor": "x5", "domain": [ 0, 0.375 ], "autorange": false, "overlaying": false, "ticksuffix": "%", "showticklabels": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "showlegend": false, "annotations": [ { "x": 0, "y": 0.58, "ax": -5, "ay": -30, "font": { "size": 18 }, "text": "I", "xref": "paper", "yref": "paper", "axref": "pixel", "yanchor": "middle", "showarrow": false, "textangle": 90 }, { "x": 1, "y": 0.55, "font": { "size": 18 }, "text": "we", "yref": "paper", "showarrow": false, "textangle": 90 }, { "x": 2, "y": 0.54, "font": { "size": 18 }, "text": "you", "yref": "paper", "showarrow": false, "textangle": 90 }, { "x": 3, "y": 0.24, "font": { "size": 18 }, "text": "he/she/they", "yref": "paper", "showarrow": false, "textangle": 90 }, { "x": 4, "y": 0.16, "font": { "size": 16 }, "text": "it/a/the/this/that", "yref": "paper", "showarrow": false, "textangle": 90 }, { "x": 0, "y": 0.58, "font": { "size": 18 }, "text": "I", "xref": "x2", "yref": "paper", "axref": "x2", "showarrow": false, "textangle": 90 }, { "x": 1, "y": 0.55, "font": { "size": 18 }, "text": "we", "xref": "x2", "yref": "paper", "axref": "x2", "showarrow": false, "textangle": 90 }, { "x": 2, "y": 0.54, "font": { "size": 18 }, "text": "you", "xref": "x2", "yref": "paper", "axref": "x2", "showarrow": false, "textangle": 90 }, { "x": 3, "y": 0.24, "font": { "size": 18 }, "text": "he/she/they", "xref": "x2", "yref": "paper", "axref": "x2", "showarrow": false, "textangle": 90 }, { "x": 4, "y": 0.16, "font": { "size": 16 }, "text": "it/a/the/this/that", "xref": "x2", "yref": "paper", "axref": "x2", "showarrow": false, "textangle": 90 }, { "x": 0, "y": 0.58, "font": { "size": 18 }, "text": "I", "xref": "x3", "yref": "paper", "axref": "x3", "showarrow": false, "textangle": 90 }, { "x": 1, "y": 0.55, "font": { "size": 18 }, "text": "we", "xref": "x3", "yref": "paper", "axref": "x3", "showarrow": false, "textangle": 90 }, { "x": 2, "y": 0.54, "font": { "size": 18 }, "text": "you", "xref": "x3", "yref": "paper", "axref": "x3", "showarrow": false, "textangle": 90 }, { "x": 3, "y": 0.24, "font": { "size": 18 }, "text": "he/she/they", "xref": "x3", "yref": "paper", "axref": "x3", "showarrow": false, "textangle": 90 }, { "x": 4, "y": 0.16, "font": { "size": 16 }, "text": "it/a/the/this/that", "xref": "x3", "yref": "paper", "axref": "x3", "showarrow": false, "textangle": 90 }, { "x": 0, "y": 0.58, "font": { "size": 18 }, "text": "I", "xref": "x4", "yref": "paper", "axref": "x4", "showarrow": false, "textangle": 90 }, { "x": 1, "y": 0.55, "font": { "size": 18 }, "text": "we", "xref": "x4", "yref": "paper", "showarrow": false, "textangle": 90 }, { "x": 2, "y": 0.54, "font": { "size": 18 }, "text": "you", "xref": "x4", "yref": "paper", "axref": "x4", "showarrow": false, "textangle": 90 }, { "x": 3, "y": 0.24, "font": { "size": 18 }, "text": "he/she/they", "xref": "x4", "yref": "paper", "xanchor": "center", "showarrow": false, "textangle": 90 }, { "x": 4, "y": 0.16, "font": { "size": 16 }, "text": "it/a/the/this/that", "xref": "x4", "yref": "paper", "axref": "x4", "showarrow": false, "textangle": 90 }, { "x": 0, "y": 0.58, "font": { "size": 18 }, "text": "I", "xref": "x9", "yref": "paper", "axref": "x9", "showarrow": false, "textangle": 90 }, { "x": 1, "y": 0.55, "font": { "size": 19 }, "text": "we", "xref": "x9", "yref": "paper", "axref": "x9", "showarrow": false, "textangle": 90 }, { "x": 2, "y": 0.54, "font": { "size": 18 }, "text": "you", "xref": "x9", "yref": "paper", "showarrow": false, "textangle": 90 }, { "x": 3, "y": 0.24, "font": { "size": 18 }, "text": "he/she/they", "xref": "x9", "yref": "paper", "axref": "x9", "xanchor": "center", "showarrow": false, "textangle": 90 }, { "x": 4, "y": 0.16, "font": { "size": 16 }, "text": "it/a/the/this/that", "xref": "x9", "yref": "paper", "axref": "x9", "showarrow": false, "textangle": 90 } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~paperness", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/46.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-17 14:54:53", "mapbox_access_tokens": null, "has_password": null, "username": "paperness", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-10-14T20:37:30.164731Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~aejohn18/3.embed", "fid": "aejohn18:3", "filename": "Age values plot", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/aejohn18:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/aejohn18:3/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/aejohn18/3/8_PV0DE76TZMW2Z1Y6JGBE7RLP1TRUKY.png", "list-thumb": "https://api.plotly.com/v2/files/aejohn18:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/aejohn18:3", "plots": "https://api.plotly.com/v2/plots/aejohn18:3", "parent": "https://api.plotly.com/v2/folders/home?user=aejohn18" }, "owner": "aejohn18", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~aejohn18/3/", "world_readable": true, "date_modified": "2025-10-14T20:37:30.180Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~aejohn18/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers", "name": "Molars", "type": "scatter", "xsrc": "aejohn18:2:1461b0", "ysrc": "aejohn18:2:ce7e59", "marker": { "color": "rgb(31, 8, 240)" } }, { "meta": { "columnNames": { "x": "A", "y": "C" } }, "mode": "markers", "name": "Premolars", "type": "scatter", "xsrc": "aejohn18:2:1461b0", "ysrc": "aejohn18:2:ef173b", "marker": { "color": "rgb(251, 14, 255)" }, "stackgroup": null }, { "meta": { "columnNames": { "x": "A", "y": "D" } }, "mode": "markers", "name": "Canines", "type": "scatter", "xsrc": "aejohn18:2:1461b0", "ysrc": "aejohn18:2:46492b", "marker": { "color": "rgb(20, 208, 20)" }, "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Estimated Age by Individual and Tooth Type" }, "xaxis": { "type": "category", "range": [ -0.8363983519244298, 14.83639835192443 ], "title": { "text": "Individual" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 17.962057549141814, 64.17301421085818 ], "title": { "text": "Age" }, "autorange": true }, "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~aejohn18", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/89.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-10-14 20:31:11", "mapbox_access_tokens": null, "has_password": null, "username": "aejohn18", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-10-14T20:33:23.417441Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~aejohn18/1.embed", "fid": "aejohn18:1", "filename": "TCI values plot", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/aejohn18:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/aejohn18:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/aejohn18/1/8_QT71ZDAGY9L8KPELYU83ZWNBSSUJWB.png", "list-thumb": "https://api.plotly.com/v2/files/aejohn18:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/aejohn18:1", "plots": "https://api.plotly.com/v2/plots/aejohn18:1", "parent": "https://api.plotly.com/v2/folders/home?user=aejohn18" }, "owner": "aejohn18", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~aejohn18/1/", "world_readable": true, "date_modified": "2025-10-14T20:33:23.429Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~aejohn18/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers", "name": "Molars", "type": "scatter", "xsrc": "aejohn18:0:94ac20", "ysrc": "aejohn18:0:6e1c60", "marker": { "color": "rgb(46, 17, 242)" } }, { "meta": { "columnNames": { "x": "A", "y": "C" } }, "mode": "markers", "name": "Premolars", "type": "scatter", "xsrc": "aejohn18:0:94ac20", "ysrc": "aejohn18:0:61b659", "marker": { "color": "rgb(255, 14, 219)" }, "stackgroup": null }, { "meta": { "columnNames": { "x": "A", "y": "D" } }, "mode": "markers", "name": "Canines", "type": "scatter", "xsrc": "aejohn18:0:94ac20", "ysrc": "aejohn18:0:23ea0f", "marker": { "color": "rgb(24, 200, 47)" }, "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "TCI Values by Individual and Tooth Type" }, "xaxis": { "type": "category", "range": [ -0.9082774049217003, 14.9082774049217 ], "title": { "text": "Individual" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 8.18541969889065, 51.84724030110935 ], "title": { "text": "TCI Value" }, "autorange": true }, "autosize": true, "hovermode": "x" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~aejohn18", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/89.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-10-14 20:31:11", "mapbox_access_tokens": null, "has_password": null, "username": "aejohn18", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-10-14T20:20:47.974355Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~paperness/301.embed", "fid": "paperness:301", "filename": "yesno modals", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/paperness:301/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/paperness:301/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/paperness/301/8_R5XNAX7P38ZGQTISL7MML2ARK39VN7.png", "list-thumb": "https://api.plotly.com/v2/files/paperness:301/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/paperness:301", "plots": "https://api.plotly.com/v2/plots/paperness:301", "parent": "https://api.plotly.com/v2/folders/home?user=paperness" }, "owner": "paperness", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~paperness/301/", "world_readable": true, "date_modified": "2025-10-14T22:00:31.092Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~paperness/301/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": false, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "A", "y": "B", "text": "B", "marker": { "color": "B" } } }, "mode": "markers", "name": "total", "type": "bar", "xsrc": "paperness:300:5ad9b2", "ysrc": "paperness:300:342e7e", "marker": { "line": { "color": "rgb(49, 57, 77)", "width": 1 }, "meta": { "columnNames": { "color": "B" } }, "color": "rgb(255, 255, 255)" }, "textsrc": "paperness:300:342e7e", "textfont": { "size": 18 }, "cliponaxis": false, "orientation": "v", "textposition": "outside", "autocolorscale": false }, { "meta": { "columnNames": { "x": "A", "y": "C", "text": "C" } }, "name": "%", "type": "bar", "xsrc": "paperness:300:5ad9b2", "ysrc": "paperness:300:18c537", "xaxis": "x2", "yaxis": "y2", "marker": { "color": "rgb(49, 57, 77)" }, "textsrc": "paperness:300:18c537", "textfont": { "size": 18 }, "cliponaxis": false, "orientation": "v", "textposition": "outside" } ], "frames": [], "layout": { "title": { "font": { "size": 24 }, "text": "yes/no" }, "width": 1000, "xaxis": { "type": "category", "range": [ -0.5, 8.5 ], "title": { "font": { "size": 18 }, "text": "occurrences totales" }, "domain": [ 0, 0.5905797101449275 ], "tickfont": { "size": 18 }, "autorange": true, "showticklabels": true }, "yaxis": { "type": "linear", "range": [ 0, 187029.47368421053 ], "title": { "text": "" }, "domain": [ 0, 1 ], "autorange": true, "showticklabels": false }, "bargap": 0.18999999999999995, "height": 452, "margin": { "t": 100 }, "xaxis2": { "side": "bottom", "type": "category", "range": [ -0.5, 8.5 ], "title": { "font": { "size": 18 }, "text": "/ 100 structures interrogatives par modal" }, "anchor": "y2", "domain": [ 0.625, 1 ], "tickfont": { "size": 18 }, "autorange": true, "tickangle": 45, "overlaying": false }, "yaxis2": { "side": "left", "type": "linear", "range": [ 0, 98.94736842105263 ], "title": { "text": "" }, "anchor": "x2", "domain": [ 0.5, 1 ], "autorange": true, "overlaying": false, "showticklabels": false }, "autosize": false, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "showlegend": false } }, "height": 452, "width": 1000, "user": { "profile_url": "https://chart-studio.plotly.com/~paperness", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/46.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-4.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2019-03-17 14:54:53", "mapbox_access_tokens": null, "has_password": null, "username": "paperness", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-10-14T19:58:17.441288Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~bhavani_bandreddy/9.embed", "fid": "bhavani_bandreddy:9", "filename": "Plot 4 copy", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/bhavani_bandreddy:9/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/bhavani_bandreddy:9/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/bhavani_bandreddy/9/8_44KU9MYNT12KRIBXEQMYGIJ9RRZ7WS.png", "list-thumb": "https://api.plotly.com/v2/files/bhavani_bandreddy:9/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/bhavani_bandreddy:9", "plots": "https://api.plotly.com/v2/plots/bhavani_bandreddy:9", "parent": "https://api.plotly.com/v2/folders/home?user=bhavani_bandreddy" }, "owner": "bhavani_bandreddy", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~bhavani_bandreddy/9/", "world_readable": true, "date_modified": "2025-10-14T19:58:18.648Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~bhavani_bandreddy/9/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Freq [GHz]", "y": "dB(S(1,1)) []" } }, "mode": "lines", "name": "insetdepth_3.1mm", "type": "scatter", "xsrc": "bhavani_bandreddy:5:37848b", "ysrc": "bhavani_bandreddy:5:da95ff" }, { "meta": { "columnNames": { "x": "Freq [GHz]", "y": "dB(S(1,1)) []" } }, "mode": "lines", "name": "insetdepth_4.1mm", "type": "scatter", "xsrc": "bhavani_bandreddy:6:6e23df", "ysrc": "bhavani_bandreddy:6:875b91", "stackgroup": null }, { "meta": { "columnNames": { "x": "Freq [GHz]", "y": "dB(S(1,1)) []" } }, "mode": "lines", "name": "insetdepth_4.5mm", "type": "scatter", "xsrc": "bhavani_bandreddy:7:4e6b3a", "ysrc": "bhavani_bandreddy:7:406a5a", "stackgroup": null }, { "meta": { "columnNames": { "x": "Freq [GHz]", "y": "dB(S(1,1)) []" } }, "mode": "lines", "name": "insetdepth_5.1mm", "type": "scatter", "xsrc": "bhavani_bandreddy:8:5e835c", "ysrc": "bhavani_bandreddy:8:b7e65c", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Frequency Vs. Gain variations" }, "xaxis": { "type": "linear", "range": [ 3, 6 ], "title": { "text": "Frequency[GHz]" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -25.423101540140493, 0.7206188003253977 ], "title": { "text": "Gain(dB)" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~bhavani_bandreddy", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/71.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-10-13 14:36:50", "mapbox_access_tokens": null, "has_password": null, "username": "bhavani_bandreddy", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-10-14T19:58:13.294775Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~yuyangp3/1.embed", "fid": "yuyangp3:1", "filename": "Plot rent", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/yuyangp3:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/yuyangp3:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/yuyangp3/1/8_SHD00O8P1LEROAK8B2VNWIAWSOYA8W.png", "list-thumb": "https://api.plotly.com/v2/files/yuyangp3:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/yuyangp3:1", "plots": "https://api.plotly.com/v2/plots/yuyangp3:1", "parent": "https://api.plotly.com/v2/folders/home?user=yuyangp3" }, "owner": "yuyangp3", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~yuyangp3/1/", "world_readable": true, "date_modified": "2025-10-14T20:15:21.966Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~yuyangp3/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "width": 5 }, "meta": { "columnNames": { "x": "Boston Rent Burden", "y": "" } }, "mode": "markers", "name": "Boston", "type": "box", "xsrc": "yuyangp3:2:dafa4c", "boxpoints": false, "whiskerwidth": 0.5 }, { "line": { "width": 5 }, "meta": { "columnNames": { "x": "Seattle Rent Burden", "y": "" } }, "name": "Seattle", "type": "box", "xsrc": "yuyangp3:2:ec9d34", "boxpoints": false } ], "frames": [], "layout": { "title": { "x": 0.2, "font": { "size": 20 }, "text": "<b>Tracts Level Rent Burden Values Boxplot-Boston vs Seattle</b>" }, "xaxis": { "type": "linear", "range": [ 16.433333333333334, 51.766666666666666 ], "autorange": true }, "yaxis": { "type": "category", "range": [ -0.5, 1.5406947890818858 ], "autorange": true }, "boxgap": 0.5, "margin": { "r": 80, "t": 100 }, "shapes": [], "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "annotations": [ { "x": 31.2, "y": 0.1, "ax": 0, "ay": -40, "font": { "size": 10 }, "text": "Boston:<br>Mean= 31.19 | SD=7.4", "xanchor": "center", "arrowhead": 7, "arrowsize": 1, "arrowcolor": "rgb(99, 110, 250)", "arrowwidth": 2 }, { "x": 28.61, "y": 1.1, "ax": 0, "ay": -40, "font": { "size": 10 }, "text": "Seattle：<br>Mean=28.61 | SD= 6.14", "arrowhead": 7, "arrowsize": 1, "arrowcolor": "rgb(239, 85, 59)", "arrowwidth": 2 } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~yuyangp3", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/77.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-10-14 17:18:01", "mapbox_access_tokens": null, "has_password": null, "username": "yuyangp3", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-10-14T19:57:10.674658Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~bhavani_bandreddy/4.embed", "fid": "bhavani_bandreddy:4", "filename": "Plot 4", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/bhavani_bandreddy:4/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/bhavani_bandreddy:4/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/bhavani_bandreddy/4/8_M9TI8PDOM38MZPX0WQ90VTR50TV2CX.png", "list-thumb": "https://api.plotly.com/v2/files/bhavani_bandreddy:4/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/bhavani_bandreddy:4", "plots": "https://api.plotly.com/v2/plots/bhavani_bandreddy:4", "parent": "https://api.plotly.com/v2/folders/home?user=bhavani_bandreddy" }, "owner": "bhavani_bandreddy", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~bhavani_bandreddy/4/", "world_readable": true, "date_modified": "2025-10-14T19:57:10.699Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~bhavani_bandreddy/4/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Freq [GHz]", "y": "dB(S(1,1)) []" } }, "mode": "lines", "name": "insetdepth_3.1mm", "type": "scatter", "xsrc": "bhavani_bandreddy:0:37848b", "ysrc": "bhavani_bandreddy:0:da95ff" }, { "meta": { "columnNames": { "x": "Freq [GHz]", "y": "dB(S(1,1)) []" } }, "mode": "lines", "name": "insetdepth_4.1mm", "type": "scatter", "xsrc": "bhavani_bandreddy:1:6e23df", "ysrc": "bhavani_bandreddy:1:875b91", "stackgroup": null }, { "meta": { "columnNames": { "x": "Freq [GHz]", "y": "dB(S(1,1)) []" } }, "mode": "lines", "name": "insetdepth_4.5mm", "type": "scatter", "xsrc": "bhavani_bandreddy:2:4e6b3a", "ysrc": "bhavani_bandreddy:2:406a5a", "stackgroup": null }, { "meta": { "columnNames": { "x": "Freq [GHz]", "y": "dB(S(1,1)) []" } }, "mode": "lines", "name": "insetdepth_5.1mm", "type": "scatter", "xsrc": "bhavani_bandreddy:3:5e835c", "ysrc": "bhavani_bandreddy:3:b7e65c", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Frequency Vs. Gain variations" }, "xaxis": { "type": "linear", "range": [ 3, 6 ], "title": { "text": "Frequency[GHz]" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -25.423101540140493, 0.7206188003253977 ], "title": { "text": "Gain(dB)" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~bhavani_bandreddy", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/71.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-10-13 14:36:50", "mapbox_access_tokens": null, "has_password": null, "username": "bhavani_bandreddy", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-10-14T18:59:34.634623Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Pia.Schmidt2008/1.embed", "fid": "Pia.Schmidt2008:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Pia.Schmidt2008:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/Pia.Schmidt2008:1/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/Pia.Schmidt2008:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/Pia.Schmidt2008:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Pia.Schmidt2008:1", "plots": "https://api.plotly.com/v2/plots/Pia.Schmidt2008:1", "parent": "https://api.plotly.com/v2/folders/home?user=Pia.Schmidt2008" }, "owner": "Pia.Schmidt2008", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~Pia.Schmidt2008/1/", "world_readable": true, "date_modified": "2025-10-14T19:00:41.869Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Pia.Schmidt2008/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(0, 0, 0)", "shape": "linear", "width": 3 }, "meta": { "columnNames": { "x": "A", "y": "B", "error_y": { "array": "C" } } }, "mode": "lines", "type": "scatter", "xsrc": "Pia.Schmidt2008:0:42b2ac", "ysrc": "Pia.Schmidt2008:0:0fb41d", "error_x": { "type": "percent", "color": "#636efa", "value": 10, "width": 4, "visible": false, "symmetric": true, "thickness": 2, "copy_ystyle": false }, "error_y": { "meta": { "columnNames": { "array": "C" } }, "type": "data", "color": "rgb(0, 0, 0)", "value": 9, "width": 4, "visible": true, "arraysrc": "Pia.Schmidt2008:0:c87a2b", "symmetric": true, "thickness": 3 }, "boxpoints": false } ], "frames": [], "layout": { "font": { "size": 17, "color": "rgb(0, 0, 0)" }, "title": { "font": { "size": 20 }, "text": "Effect of temperature of the cell membrane in <i>Beta vulgaris</i> on the transmission of light <br>(measured using a colorimeter with wavelength 520 nm ± 1 nm)" }, "xaxis": { "side": "bottom", "type": "linear", "dtick": 10, "range": [ -4.4444444444444455, 84.44444444444444 ], "tick0": 0, "ticks": "", "title": { "font": { "size": 18 }, "text": "Temperature (°C)" }, "nticks": 6, "showgrid": true, "showline": true, "tickmode": "auto", "zeroline": true, "autorange": true, "linewidth": 1, "fixedrange": true, "showspikes": false, "tickformat": "", "rangeslider": { "range": [ 0, 80 ], "yaxis": {}, "visible": false, "autorange": true } }, "yaxis": { "side": "left", "type": "linear", "range": [ -5.823927979193812, 31.589007344189287 ], "title": { "font": { "size": 17 }, "text": "Transmission of light (%)" }, "domain": [ 0, 1 ], "autorange": false, "showspikes": false }, "margin": { "b": 80, "t": 100 }, "shapes": [], "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "colorscale": { "sequential": [ [ 0, "#fcfbfd" ], [ 0.125, "#efedf5" ], [ 0.25, "#dadaeb" ], [ 0.375, "#bcbddc" ], [ 0.5, "#9e9ac8" ], [ 0.625, "#807dba" ], [ 0.75, "#6a51a3" ], [ 0.875, "#54278f" ], [ 1, "#3f007d" ] ] }, "hoverlabel": { "font": { "size": 17 } }, "separators": ",.", "showlegend": false, "annotations": [ { "x": 17.418527072106745, "y": -17.506495949576447, "text": "" } ], "uniformtext": { "mode": "show", "minsize": 17 }, "paper_bgcolor": "rgba(0, 0, 0, 0.01)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Pia.Schmidt2008", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/7.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-08-18 14:25:41", "mapbox_access_tokens": null, "has_password": null, "username": "Pia.Schmidt2008", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-10-14T18:40:15.289131Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~mcg04595/1.embed", "fid": "mcg04595:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/mcg04595:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/mcg04595:1/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/mcg04595:1/image?image_name=block-thumb", "list-thumb": "https://api.plotly.com/v2/files/mcg04595:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/mcg04595:1", "plots": "https://api.plotly.com/v2/plots/mcg04595:1", "parent": "https://api.plotly.com/v2/folders/home?user=mcg04595" }, "owner": "mcg04595", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~mcg04595/1/", "world_readable": true, "date_modified": "2025-10-14T18:40:15.303Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~mcg04595/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "markers+lines", "name": "SImulated R-C", "type": "scatter", "xsrc": "mcg04595:0:fa4908", "ysrc": "mcg04595:0:50e71d", "xaxis": "x", "opacity": 0.75 }, { "meta": { "columnNames": { "x": "A", "y": "C" } }, "mode": "markers+lines", "name": "Mesured R-c ", "type": "scatter", "xsrc": "mcg04595:0:fa4908", "ysrc": "mcg04595:0:520cf7", "opacity": 0.75, "stackgroup": null }, { "meta": { "columnNames": { "x": "A", "y": "D" } }, "mode": "markers+lines", "name": "Simulated R-L", "type": "scatter", "xsrc": "mcg04595:0:fa4908", "ysrc": "mcg04595:0:91bbc2", "opacity": 0.75 }, { "meta": { "columnNames": { "x": "A", "y": "E" } }, "mode": "markers+lines", "name": "Mesured R-L", "type": "scatter", "xsrc": "mcg04595:0:fa4908", "ysrc": "mcg04595:0:f61bee", "opacity": 0.75, "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Phase diff (Deg) vs Frequency" }, "xaxis": { "type": "category", "range": [ -0.6363989134652696, 10.63639891346527 ], "title": { "text": "Frequency (Hz)" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -8.770224215246637, 109.93022421524664 ], "title": { "text": "Phase Offset (Deg)" }, "autorange": true }, "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~mcg04595", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/91.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-10-14 18:38:53", "mapbox_access_tokens": null, "has_password": null, "username": "mcg04595", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
