Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cD0yMDI1LTA4LTEwKzE0JTNBMzUlM0E1Ny45NDkyNDclMkIwMCUzQTAw&format=api
{ "next": "https://api.plotly.com/v2/plots?cursor=cD0yMDI1LTA4LTA5KzE1JTNBNDMlM0EzOS44MzA0ODAlMkIwMCUzQTAw&format=api", "previous": "https://api.plotly.com/v2/plots?cursor=cj0xJnA9MjAyNS0wOC0xMCsxNCUzQTMwJTNBMDMuMzkzMjk5JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2025-08-10T14:30:03.393299Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~aylu/3.embed", "fid": "aylu:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/aylu:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/aylu:3/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/aylu/3/8_CTNRSEY43G808RZKJHNE65JUAB9RHG.png", "list-thumb": "https://api.plotly.com/v2/files/aylu:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/aylu:3", "plots": "https://api.plotly.com/v2/plots/aylu:3", "parent": "https://api.plotly.com/v2/folders/home?user=aylu" }, "owner": "aylu", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~aylu/3/", "world_readable": true, "date_modified": "2025-08-10T14:31:38.688Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~aylu/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "step", "y": "losses/train.total_loss" } }, "mode": "lines", "name": "Synthetic", "type": "scatter", "xsrc": "aylu:1:ddbf9f", "ysrc": "aylu:1:d096c7" }, { "meta": { "columnNames": { "x": "step", "y": "losses/train.total_loss" } }, "mode": "lines", "name": "Real ", "type": "scatter", "xsrc": "aylu:2:0c2e9a", "ysrc": "aylu:2:5549ba", "stackgroup": null }, { "meta": { "columnNames": { "x": "step", "y": "losses/train.total_loss" } }, "mode": "lines", "name": "Mixed", "type": "scatter", "xsrc": "aylu:0:617a7c", "ysrc": "aylu:0:9fd3a7", "stackgroup": null } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 1, 300 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -1.2077982925499551e-05, 0.016219734980647143 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~aylu", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/76.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-10.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-08-10 14:24:43", "mapbox_access_tokens": null, "has_password": null, "username": "aylu", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-08-10T12:44:49.247334Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~diannelauc/85.embed", "fid": "diannelauc:85", "filename": "28th day with fly ash TENSILE copy", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/diannelauc/85/9_P2TES5G4BVY4H9E31N799MHRI0887A.png", "image_urls": { "default": "https://api.plotly.com/v2/files/diannelauc:85/image?image_name=default", "block-thumb": "https://api.plotly.com/v2/files/diannelauc:85/image?image_name=block-thumb", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/diannelauc/85/9_P2TES5G4BVY4H9E31N799MHRI0887A.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/diannelauc:85", "plots": "https://api.plotly.com/v2/plots/diannelauc:85", "parent": "https://api.plotly.com/v2/folders/home?user=diannelauc" }, "owner": "diannelauc", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 135, "web_url": "https://chart-studio.plotly.com/~diannelauc/85/", "world_readable": true, "date_modified": "2025-08-12T06:29:53.850Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~diannelauc/85/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "y": "A" } }, "mode": "markers", "name": "Control", "type": "box", "ysrc": "diannelauc:84:13edea", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "hoveron": "boxes+points", "notched": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "B" } }, "name": "0% MSSA 30% CDW", "type": "box", "ysrc": "diannelauc:84:8254a2", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "C" } }, "name": "0% MSSA 50% CDW", "type": "box", "ysrc": "diannelauc:84:9f1d4c", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "D" } }, "name": "0% MSSA 70% CDW", "type": "box", "ysrc": "diannelauc:84:b05272", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "E" } }, "name": "5% MSSA 0% CDW ", "type": "box", "ysrc": "diannelauc:84:608f72", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "F" } }, "name": "5% MSSA 30% CDW", "type": "box", "ysrc": "diannelauc:84:7ae72f", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "G" } }, "name": "5% MSSA 50% CDW", "type": "box", "ysrc": "diannelauc:84:6f3228", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "H" } }, "name": "5% MSSA 70% CDW", "type": "box", "ysrc": "diannelauc:84:483831", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "I" } }, "name": "10% MSSA 0% CDW", "type": "box", "ysrc": "diannelauc:84:a71349", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "J" } }, "name": "10% MSSA 50% CDW", "type": "box", "ysrc": "diannelauc:84:8a7877", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "K" } }, "name": "15% MSSA 30% CDW", "type": "box", "ysrc": "diannelauc:84:2cc518", "marker": { "line": { "width": 0 }, "color": "rgb(0, 150, 255)", "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "x": "", "y": "" } }, "mode": "lines", "type": "scatter", "xaxis": "x", "yaxis": "y", "visible": "legendonly", "boxpoints": false }, { "meta": { "columnNames": { "y": "N" } }, "mode": "lines", "name": "5% Fly Ash 0% CDW", "type": "box", "ysrc": "diannelauc:84:095ef8", "visible": true, "boxpoints": false, "stackgroup": null }, { "meta": { "columnNames": { "y": "O" } }, "name": "5% Fly Ash 50% CDW", "type": "box", "ysrc": "diannelauc:84:6113a1", "boxpoints": false }, { "meta": { "columnNames": { "y": "P" } }, "name": "10% Fly Ash 0% CDW", "type": "box", "ysrc": "diannelauc:84:bb5304", "boxpoints": false }, { "meta": { "columnNames": { "y": "Q" } }, "name": "10% Fly Ash 50% CDW", "type": "box", "ysrc": "diannelauc:84:455117", "boxpoints": false } ], "frames": [], "layout": { "title": { "text": "28th Day Split Tensile Strength of M30 Concrete Mix Designs" }, "xaxis": { "type": "category", "dtick": 1, "range": [ -0.5, 15 ], "tick0": 0, "ticks": "", "title": { "text": "Click to enter X axis title" }, "domain": [ 0, 1 ], "showline": false, "tickmode": "auto", "autorange": false, "showspikes": true, "rangeslider": { "range": [ -0.8570504527813713, 11.014877102199224 ], "yaxis": {}, "visible": false, "autorange": true }, "showticklabels": false }, "yaxis": { "side": "left", "type": "linear", "dtick": 1, "range": [ -6.527027027027027, 8 ], "tick0": 0, "ticks": "", "title": { "text": "Tensile Strength, MPa" }, "domain": [ 0, 1 ], "tickmode": "auto", "autorange": false, "showspikes": true }, "shapes": [ { "x0": -0.5, "x1": 15, "y0": 24.1, "y1": 24.1, "line": { "color": "rgb(245, 8, 8)", "width": 2 }, "type": "line", "opacity": 0.3, "visible": false, "fillcolor": "#7f7f7f" }, { "x0": 3.5, "x1": 3.5, "y0": -4.5, "y1": 30, "line": { "dash": "solid", "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 7.5, "x1": 7.5, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 9.5, "x1": 9.5, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 10.700084881026578, "x1": 10.700084881026578, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 12.5, "x1": 12.5, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" } ], "autosize": true, "dragmode": "zoom", "hovermode": "x", "annotations": [ { "x": 1.5, "y": 2, "ax": -10, "ay": 29, "text": "0% MSSA", "arrowcolor": "rgb(255, 255, 255)" }, { "x": 5.5, "y": 2, "ax": 7, "ay": 28, "text": "5% MSSA", "arrowcolor": "rgb(255, 255, 255)" }, { "x": 8.5, "y": 2.6, "ax": -5, "ay": 42, "text": "10% MSSA", "arrowcolor": "rgb(255, 255, 255)" }, { "x": 0.03840728859401114, "y": -2.5, "ax": -1, "ay": -6, "text": "0% <br>" }, { "x": 1, "y": -2.5, "ax": -1, "ay": -7, "text": "30% " }, { "x": 2.1, "y": -2.5, "ax": -10, "ay": -8, "text": "50% " }, { "x": 3, "y": -2.5, "ax": -10, "ay": -8, "text": "70% " }, { "x": 1.3, "y": -3.5, "ax": 6, "ay": -4, "text": "CDW", "arrowcolor": "rgb(46, 28, 28)" }, { "x": 4, "y": -2.5, "ax": 3, "ay": -8, "text": "0%" }, { "x": 4.9, "y": -2.5, "ax": 2, "ay": -7, "text": "30%" }, { "x": 5.999929072681703, "y": -2.5, "ax": -2, "ay": -7, "text": "50%" }, { "x": 7, "y": -2.5, "ax": 0, "ay": -9, "text": "70%" }, { "x": 5.4, "y": -3.5, "ax": 8, "ay": -2, "text": "CDW" }, { "x": 8, "y": -2.5, "ax": -2, "ay": -8, "text": "0%" }, { "x": 9, "y": -2, "ax": -1, "ay": 4, "text": "50%" }, { "x": 8.5, "y": -3.5, "ax": -2, "ay": -4, "text": "CDW" }, { "x": 10, "y": -2.5, "ax": 6, "ay": -8, "text": "30%" }, { "x": 10, "y": -3.5, "ax": 6, "ay": -6, "text": "CDW" }, { "x": 11, "y": -2.5, "ax": 2, "ay": -8, "text": "0%" }, { "x": 12, "y": -2.5, "ax": 2, "ay": -7, "text": "50%" }, { "x": 11.5, "y": -3.5, "ax": 4, "ay": -2, "text": "CDW" }, { "x": 13, "y": -2, "ax": -2, "ay": 3, "text": "0%" }, { "x": 14, "y": -2, "ax": -10, "ay": 3, "text": "50%" }, { "x": 13.229422232493182, "y": -5, "ax": 10, "ay": -32, "text": "CDW", "arrowcolor": "rgb(255, 253, 253)" }, { "x": 11.7, "y": 1, "ax": -10, "ay": 8, "text": "5% Fly Ash" }, { "x": 13.5, "y": 1, "ax": -10, "ay": 7, "text": "10% Fly Ash" }, { "x": 10.5, "y": 1, "ax": -20, "ay": 8, "text": "15% MSSA" } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~diannelauc", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/69.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-25 22:45:50", "mapbox_access_tokens": null, "has_password": null, "username": "diannelauc", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-08-10T12:39:44.233134Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~aboveandbeyond/1.embed", "fid": "aboveandbeyond:1", "filename": "fless-salary-research", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/aboveandbeyond:1/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/aboveandbeyond/1/2_LQCEMPQFZZ1ZRUFGHG5S4HHSHBVHAH.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/aboveandbeyond/1/8_Y5GFD7H1ZHFRJ93L6U9ZB9RO47B6K0.png", "list-thumb": "https://api.plotly.com/v2/files/aboveandbeyond:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/aboveandbeyond:1", "plots": "https://api.plotly.com/v2/plots/aboveandbeyond:1", "parent": "https://api.plotly.com/v2/folders/home?user=aboveandbeyond" }, "owner": "aboveandbeyond", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 143, "web_url": "https://chart-studio.plotly.com/~aboveandbeyond/1/", "world_readable": true, "date_modified": "2025-08-10T12:46:06.508Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~aboveandbeyond/1/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "name": "Зарплата в год", "type": "bar", "xsrc": "aboveandbeyond:2:54ba1b", "ysrc": "aboveandbeyond:2:a6fb8a", "marker": { "color": "#636EFA" }, "textsrc": "aboveandbeyond:2:3215ba", "textfont": { "size": 10, "color": "rgb(184,189,252)" }, "textposition": "inside", "customdatasrc": "aboveandbeyond:2:c76d08", "hovertemplate": "<b>%{customdata[0]}</b><br>%{customdata[1]}<br>", "insidetextanchor": "end" }, { "name": "Годовой бонус", "type": "bar", "xsrc": "aboveandbeyond:2:117dcc", "ysrc": "aboveandbeyond:2:2a3c2b", "marker": { "color": "#EF553B" }, "textsrc": "aboveandbeyond:2:e44787", "textfont": { "size": 10, "color": "rgb(249,195,186)" }, "textposition": "inside", "customdatasrc": "aboveandbeyond:2:59fb92", "hovertemplate": "<b>%{customdata[0]}</b><br>%{customdata[1]}<br>", "insidetextanchor": "end" }, { "line": { "color": "white", "width": 2 }, "mode": "lines", "name": "Зарплата в месяц", "type": "scatter", "xsrc": "aboveandbeyond:2:603059", "ysrc": "aboveandbeyond:2:7290f5", "yaxis": "y2", "customdatasrc": "aboveandbeyond:2:a0b5e6", "hovertemplate": "<b>%{customdata[0]}</b><br>%{customdata[1]}<br>Зарплата в месяц: %{customdata[2]:,}<br>" } ], "layout": { "title": { "text": "Зарплата и бонусы по компаниям" }, "xaxis": { "type": "linear", "title": { "text": "Компания" }, "tickmode": "array", "ticktext": [ "Tier 2 consulting company", "Консалтинговый бутик", "Kearney", "Одна из Биг Фарма компаний ", "PwC", "Яков и Партнеры", "HQ", "Accenture", "NDA, trading", "Roland Berger", "Яндекс ", "Яндекс", "Крупная компания из сферы горной добычи", "Bolt", "Сибур", "Private", "Авито", "Яков и Партнёры", "BCG", "Ростех (один из холдингов)", "McK", "Озон", "Б1", "Yandex", "Авито", "Anonym", "Goldman Sachs", "Etched ", "АТК", "VC Fund", "X5", "Яндекс", "Норильский никель", "Family office", "ООО ВКонтакте", "Small IT company ", "Яндекс", "Биржа", "ДОМ РФ", "сбер", "ГНИВЦ", "Вб", "Мкб", "ФЦК", "WB Tech", "Yeresoft", "СИБУР ", "Т1 (ИТ Холдинг)", "Яндекс", "Яндекс", "Кэпт", "Indefi", "GFO X", "Северсталь", "Роснефть (дочернее общество в группе)", "Avito", "Т-банк", "Яндекс", "-", null, "не скажу", "Travel tech", "Авито", "Х5", "Банки.ру", "Газпром нефть ", "Яндекс", "Правительство Московской области ", "Втб", "Альфа банк", "МТС", "Сбер", "-", "Небольшая компания с выручкой менее 10 млрд руб (Metals&Mining)", "VK", "Erste", "Family Office", "Альфа Банк", "Мегафон ", "Яндекс", "Девелоперская компания", "Консалтинг бутик", "Яндекс", "Sporting goods", "Xxx", "Dodo Brands", "Arthur Consulting", "Группа Неман", "IDF Eurasia", "Пепсико", "OilTeam", "Альфа-Банк", "Яндекс", "Компания в сфере энергетике ", "Сбербанк", "Промсвязьбанк", "Excellence Expert", "AT", "ЦБП", "Федеральный застройщик", "Дефендер", "Билайн", "Ozon", "IQVIA", "Дочка Лукойла ", "Самокат тех", "МТС Рекламные технологий ", "ТеДо", "Ростелеком", "Департамент информационных технологий ", "Retail ", "Итмо", "ГК Альфа", "Сбер", "Втб", "Татнефть", "Arthur Consulting", "Сколково", "Sminex", "F", "Магнит", "Т-Банк", "GlowByte", "Точка", "Альфа-банк ", "Яндекс", "Яндекс Такси", "Wildberries", "ФЦК", "Яндекс", "Газпромнефть-Ямал", "Группа Неман", "ВТБ", "Б1", "OKS Labs", "Технологии Доверия", "Экопси", "Avitotech", "Яндекс ", "ООО Технологии Доверия", "Samolet", "Альфа банк ", "Центр по внешней торговле при Минпромторге", "ПАО Банк ПСБ", "Компания в области решений для Советов директоров", "Big4", "Strategy partners", "Яков и Партнёры", "Технологии Доверия", "VK", "ТБанк", "ДРТ", "Спортмастер", "ТБанк", "-", "Тбанк", "Авито", "Т-Банк", "Kept", "Kept (ex KPMG)", "Тбанк", "Kept", "Sber", "McK Partners", "Технологии доверия", "Технологии Доверия", "Strategy partners", "Газпром нефть", "Яндекс", "Роснефть", "НДА", "Б1", "Технологии Доверия", "Банк Хлынов", "Технологии Доверия", "Отраслевой консалтинг", "Тедо", "o2consulting", "EY", "Б1", "\"Деловые решения и технологии\" ex. Deloitte", "Сбер", "EY", "Strategy partners", "ООО «РУСАУДИТ»", "АО Узбекнефтегаз" ], "tickvals": [ 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 70, 71, 72, 73, 74, 75, 76, 77, 78, 79, 80, 81, 82, 83, 84, 85, 86, 87, 88, 89, 90, 91, 92, 93, 94, 95, 96, 97, 98, 99, 100, 101, 102, 103, 104, 105, 106, 107, 108, 109, 110, 111, 112, 113, 114, 115, 116, 117, 118, 119, 120, 121, 122, 123, 124, 125, 126, 127, 128, 129, 130, 131, 132, 133, 134, 135, 136, 137, 138, 139, 140, 141, 142, 143, 144, 145, 146, 147, 148, 149, 150, 151, 152, 153, 154, 155, 156, 157, 158, 159, 160, 161, 162, 163, 164, 165, 166, 167, 168, 169, 170, 171, 172, 173, 174, 175, 176, 177, 178, 179, 180, 181, 182, 183, 184, 185 ], "tickangle": -60, "rangeslider": { "visible": true }, "showticklabels": true }, "yaxis": { "title": { "font": { "color": "rgba(220,220,220,0.9)" }, "text": "Млн руб" }, "showgrid": true, "tickfont": { "color": "rgba(220,220,220,0.9)" }, "ticktext": [ "0", "5", "10", "15", "20", "25", "30" ], "tickvals": [ 0, 5000000, 10000000, 15000000, 20000000, 25000000, 30000000 ], "zeroline": true, "gridcolor": "rgba(255,255,255,0.08)", "zerolinecolor": "rgba(255,255,255,0.25)" }, "height": 1000, "legend": { "x": 0.5, "y": 1.02, "xanchor": "center", "yanchor": "bottom", "orientation": "h" }, "margin": { "b": 140, "t": 90 }, "yaxis2": { "side": "right", "title": { "font": { "color": "white" }, "text": "Зарплата в месяц (руб)" }, "showgrid": false, "tickfont": { "color": "white" }, "rangemode": "tozero", "overlaying": "y" }, "barmode": "stack", "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "rgb(17,17,17)", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#f2f5fa" }, "error_y": { "color": "#f2f5fa" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#506784" }, "line": { "color": "rgb(17,17,17)" } }, "header": { "fill": { "color": "#2a3f5f" }, "line": { "color": "rgb(17,17,17)" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#506784", "linecolor": "#506784", "endlinecolor": "#A2B1C6", "minorgridcolor": "#506784", "startlinecolor": "#A2B1C6" }, "baxis": { "gridcolor": "#506784", "linecolor": "#506784", "endlinecolor": "#A2B1C6", "minorgridcolor": "#506784", "startlinecolor": "#A2B1C6" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "marker": { "line": { "color": "#283442" } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "rgb(17,17,17)", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "line": { "color": "#283442" } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "rgb(17,17,17)", "showland": true, "lakecolor": "rgb(17,17,17)", "landcolor": "rgb(17,17,17)", "showlakes": true, "subunitcolor": "#506784" }, "font": { "color": "#f2f5fa" }, "polar": { "bgcolor": "rgb(17,17,17)", "radialaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "angularaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" }, "yaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" }, "zaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "#283442", "linecolor": "#506784", "automargin": true, "zerolinecolor": "#283442", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "#283442", "linecolor": "#506784", "automargin": true, "zerolinecolor": "#283442", "zerolinewidth": 2 }, "mapbox": { "style": "dark" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "baxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "caxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "bgcolor": "rgb(17,17,17)" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "rgb(17,17,17)", "paper_bgcolor": "rgb(17,17,17)", "shapedefaults": { "line": { "color": "#f2f5fa" } }, "sliderdefaults": { "bgcolor": "#C8D4E3", "tickwidth": 0, "bordercolor": "rgb(17,17,17)", "borderwidth": 1 }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#f2f5fa", "arrowwidth": 1 }, "updatemenudefaults": { "bgcolor": "#506784", "borderwidth": 0 } } }, "showlegend": true, "annotations": [ { "x": 0, "y": 28800000.0, "font": { "size": 10, "color": "#797979" }, "text": "28.8", "yshift": 10, "showarrow": false }, { "x": 1, "y": 22400000.0, "font": { "size": 10, "color": "#797979" }, "text": "22.4", "yshift": 10, "showarrow": false }, { "x": 2, "y": 18000000.0, "font": { "size": 10, "color": "#797979" }, "text": "18", "yshift": 10, "showarrow": false }, { "x": 3, "y": 17420000.0, "font": { "size": 10, "color": "#797979" }, "text": "17.4", "yshift": 10, "showarrow": false }, { "x": 4, "y": 15975000.0, "font": { "size": 10, "color": "#797979" }, "text": "16.0", "yshift": 10, "showarrow": false }, { "x": 5, "y": 15000000.0, "font": { "size": 10, "color": "#797979" }, "text": "15", "yshift": 10, "showarrow": false }, { "x": 6, "y": 13600000.0, "font": { "size": 10, "color": "#797979" }, "text": "13.6", "yshift": 10, "showarrow": false }, { "x": 7, "y": 13000000.0, "font": { "size": 10, "color": "#797979" }, "text": "13", "yshift": 10, "showarrow": false }, { "x": 8, "y": 12800000.0, "font": { "size": 10, "color": "#797979" }, "text": "12.8", "yshift": 10, "showarrow": false }, { "x": 9, "y": 12750000.0, "font": { "size": 10, "color": "#797979" }, "text": "12.8", "yshift": 10, "showarrow": false }, { "x": 10, "y": 11900000.0, "font": { "size": 10, "color": "#797979" }, "text": "11.9", "yshift": 10, "showarrow": false }, { "x": 11, "y": 11050000.0, "font": { "size": 10, "color": "#797979" }, "text": "11.1", "yshift": 10, "showarrow": false }, { "x": 12, "y": 10800000.0, "font": { "size": 10, "color": "#797979" }, "text": "10.8", "yshift": 10, "showarrow": false }, { "x": 13, "y": 10080000.0, "font": { "size": 10, "color": "#797979" }, "text": "10.1", "yshift": 10, "showarrow": false }, { "x": 14, "y": 10080000.0, "font": { "size": 10, "color": "#797979" }, "text": "10.1", "yshift": 10, "showarrow": false }, { "x": 15, "y": 9600000.0, "font": { "size": 10, "color": "#797979" }, "text": "9.6", "yshift": 10, "showarrow": false }, { "x": 16, "y": 9520000.0, "font": { "size": 10, "color": "#797979" }, "text": "9.5", "yshift": 10, "showarrow": false }, { "x": 17, "y": 9300000.0, "font": { "size": 10, "color": "#797979" }, "text": "9.3", "yshift": 10, "showarrow": false }, { "x": 18, "y": 9062500.0, "font": { "size": 10, "color": "#797979" }, "text": "9.1", "yshift": 10, "showarrow": false }, { "x": 19, "y": 8850000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.8", "yshift": 10, "showarrow": false }, { "x": 20, "y": 8400000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.4", "yshift": 10, "showarrow": false }, { "x": 21, "y": 8320000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.3", "yshift": 10, "showarrow": false }, { "x": 22, "y": 8250000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.2", "yshift": 10, "showarrow": false }, { "x": 23, "y": 8160000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.2", "yshift": 10, "showarrow": false }, { "x": 24, "y": 8100000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.1", "yshift": 10, "showarrow": false }, { "x": 25, "y": 8000000.0, "font": { "size": 10, "color": "#797979" }, "text": "8", "yshift": 10, "showarrow": false }, { "x": 26, "y": 7750000.0, "font": { "size": 10, "color": "#797979" }, "text": "7.8", "yshift": 10, "showarrow": false }, { "x": 27, "y": 7680000.0, "font": { "size": 10, "color": "#797979" }, "text": "7.7", "yshift": 10, "showarrow": false }, { "x": 28, "y": 7500000.0, "font": { "size": 10, "color": "#797979" }, "text": "7.5", "yshift": 10, "showarrow": false }, { "x": 29, "y": 7500000.0, "font": { "size": 10, "color": "#797979" }, "text": "7.5", "yshift": 10, "showarrow": false }, { "x": 30, "y": 7310000.0, "font": { "size": 10, "color": "#797979" }, "text": "7.3", "yshift": 10, "showarrow": false }, { "x": 31, "y": 6750000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.8", "yshift": 10, "showarrow": false }, { "x": 32, "y": 6720000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.7", "yshift": 10, "showarrow": false }, { "x": 33, "y": 6650000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.7", "yshift": 10, "showarrow": false }, { "x": 34, "y": 6510000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.5", "yshift": 10, "showarrow": false }, { "x": 35, "y": 6480000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.5", "yshift": 10, "showarrow": false }, { "x": 36, "y": 6400000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.4", "yshift": 10, "showarrow": false }, { "x": 37, "y": 6360000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.4", "yshift": 10, "showarrow": false }, { "x": 38, "y": 6300000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.3", "yshift": 10, "showarrow": false }, { "x": 39, "y": 6200000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.2", "yshift": 10, "showarrow": false }, { "x": 40, "y": 6090000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.1", "yshift": 10, "showarrow": false }, { "x": 41, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 42, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 43, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 44, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 45, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 46, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 47, "y": 5940000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.9", "yshift": 10, "showarrow": false }, { "x": 48, "y": 5920000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.9", "yshift": 10, "showarrow": false }, { "x": 49, "y": 5696000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.7", "yshift": 10, "showarrow": false }, { "x": 50, "y": 5670000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.7", "yshift": 10, "showarrow": false }, { "x": 51, "y": 5600000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.6", "yshift": 10, "showarrow": false }, { "x": 52, "y": 5600000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.6", "yshift": 10, "showarrow": false }, { "x": 53, "y": 5550000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.5", "yshift": 10, "showarrow": false }, { "x": 54, "y": 5520000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.5", "yshift": 10, "showarrow": false }, { "x": 55, "y": 5478000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.5", "yshift": 10, "showarrow": false }, { "x": 56, "y": 5460000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.5", "yshift": 10, "showarrow": false }, { "x": 57, "y": 5445000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.4", "yshift": 10, "showarrow": false }, { "x": 58, "y": 5400000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.4", "yshift": 10, "showarrow": false }, { "x": 59, "y": 5400000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.4", "yshift": 10, "showarrow": false }, { "x": 60, "y": 5355000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.4", "yshift": 10, "showarrow": false }, { "x": 61, "y": 5330000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.3", "yshift": 10, "showarrow": false }, { "x": 62, "y": 5200000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.2", "yshift": 10, "showarrow": false }, { "x": 63, "y": 5100000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.1", "yshift": 10, "showarrow": false }, { "x": 64, "y": 4987500.0, "font": { "size": 10, "color": "#797979" }, "text": "5.0", "yshift": 10, "showarrow": false }, { "x": 65, "y": 4960000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.0", "yshift": 10, "showarrow": false }, { "x": 66, "y": 4906800.0, "font": { "size": 10, "color": "#797979" }, "text": "4.9", "yshift": 10, "showarrow": false }, { "x": 67, "y": 4900000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.9", "yshift": 10, "showarrow": false }, { "x": 68, "y": 4860000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.9", "yshift": 10, "showarrow": false }, { "x": 69, "y": 4830000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.8", "yshift": 10, "showarrow": false }, { "x": 70, "y": 4800000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.8", "yshift": 10, "showarrow": false }, { "x": 71, "y": 4800000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.8", "yshift": 10, "showarrow": false }, { "x": 72, "y": 4800000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.8", "yshift": 10, "showarrow": false }, { "x": 73, "y": 4745000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.7", "yshift": 10, "showarrow": false }, { "x": 74, "y": 4695000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.7", "yshift": 10, "showarrow": false }, { "x": 75, "y": 4680000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.7", "yshift": 10, "showarrow": false }, { "x": 76, "y": 4620000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.6", "yshift": 10, "showarrow": false }, { "x": 77, "y": 4560000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.6", "yshift": 10, "showarrow": false }, { "x": 78, "y": 4550000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.5", "yshift": 10, "showarrow": false }, { "x": 79, "y": 4410000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.4", "yshift": 10, "showarrow": false }, { "x": 80, "y": 4400000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.4", "yshift": 10, "showarrow": false }, { "x": 81, "y": 4350000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.3", "yshift": 10, "showarrow": false }, { "x": 82, "y": 4350000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.3", "yshift": 10, "showarrow": false }, { "x": 83, "y": 4290000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.3", "yshift": 10, "showarrow": false }, { "x": 84, "y": 4290000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.3", "yshift": 10, "showarrow": false }, { "x": 85, "y": 4200000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.2", "yshift": 10, "showarrow": false }, { "x": 86, "y": 4200000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.2", "yshift": 10, "showarrow": false }, { "x": 87, "y": 4200000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.2", "yshift": 10, "showarrow": false }, { "x": 88, "y": 4200000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.2", "yshift": 10, "showarrow": false }, { "x": 89, "y": 4200000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.2", "yshift": 10, "showarrow": false }, { "x": 90, "y": 4132500.0, "font": { "size": 10, "color": "#797979" }, "text": "4.1", "yshift": 10, "showarrow": false }, { "x": 91, "y": 4080000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.1", "yshift": 10, "showarrow": false }, { "x": 92, "y": 4060000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.1", "yshift": 10, "showarrow": false }, { "x": 93, "y": 4000000.0, "font": { "size": 10, "color": "#797979" }, "text": "4", "yshift": 10, "showarrow": false }, { "x": 94, "y": 3976000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.0", "yshift": 10, "showarrow": false }, { "x": 95, "y": 3952000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.0", "yshift": 10, "showarrow": false }, { "x": 96, "y": 3920000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.9", "yshift": 10, "showarrow": false }, { "x": 97, "y": 3915000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.9", "yshift": 10, "showarrow": false }, { "x": 98, "y": 3850000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.9", "yshift": 10, "showarrow": false }, { "x": 99, "y": 3842500.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 100, "y": 3780000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 101, "y": 3780000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 102, "y": 3780000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 103, "y": 3780000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 104, "y": 3778500.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 105, "y": 3756000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 106, "y": 3654000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.7", "yshift": 10, "showarrow": false }, { "x": 107, "y": 3640000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 108, "y": 3640000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 109, "y": 3640000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 110, "y": 3640000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 111, "y": 3600000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 112, "y": 3600000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 113, "y": 3600000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 114, "y": 3528000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.5", "yshift": 10, "showarrow": false }, { "x": 115, "y": 3520000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.5", "yshift": 10, "showarrow": false }, { "x": 116, "y": 3510000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.5", "yshift": 10, "showarrow": false }, { "x": 117, "y": 3500000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.5", "yshift": 10, "showarrow": false }, { "x": 118, "y": 3467500.0, "font": { "size": 10, "color": "#797979" }, "text": "3.5", "yshift": 10, "showarrow": false }, { "x": 119, "y": 3307500.0, "font": { "size": 10, "color": "#797979" }, "text": "3.3", "yshift": 10, "showarrow": false }, { "x": 120, "y": 3300000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.3", "yshift": 10, "showarrow": false }, { "x": 121, "y": 3248000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.2", "yshift": 10, "showarrow": false }, { "x": 122, "y": 3220000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.2", "yshift": 10, "showarrow": false }, { "x": 123, "y": 3180000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.2", "yshift": 10, "showarrow": false }, { "x": 124, "y": 3151500.0, "font": { "size": 10, "color": "#797979" }, "text": "3.2", "yshift": 10, "showarrow": false }, { "x": 125, "y": 3150000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.1", "yshift": 10, "showarrow": false }, { "x": 126, "y": 3150000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.1", "yshift": 10, "showarrow": false }, { "x": 127, "y": 3120000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.1", "yshift": 10, "showarrow": false }, { "x": 128, "y": 3080000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.1", "yshift": 10, "showarrow": false }, { "x": 129, "y": 3000000.0, "font": { "size": 10, "color": "#797979" }, "text": "3", "yshift": 10, "showarrow": false }, { "x": 130, "y": 2880000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.9", "yshift": 10, "showarrow": false }, { "x": 131, "y": 2860000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.9", "yshift": 10, "showarrow": false }, { "x": 132, "y": 2835000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.8", "yshift": 10, "showarrow": false }, { "x": 133, "y": 2800000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.8", "yshift": 10, "showarrow": false }, { "x": 134, "y": 2800000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.8", "yshift": 10, "showarrow": false }, { "x": 135, "y": 2784000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.8", "yshift": 10, "showarrow": false }, { "x": 136, "y": 2775000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.8", "yshift": 10, "showarrow": false }, { "x": 137, "y": 2730000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.7", "yshift": 10, "showarrow": false }, { "x": 138, "y": 2700000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.7", "yshift": 10, "showarrow": false }, { "x": 139, "y": 2639000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.6", "yshift": 10, "showarrow": false }, { "x": 140, "y": 2600000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.6", "yshift": 10, "showarrow": false }, { "x": 141, "y": 2502000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.5", "yshift": 10, "showarrow": false }, { "x": 142, "y": 2500000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.5", "yshift": 10, "showarrow": false }, { "x": 143, "y": 2475000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.5", "yshift": 10, "showarrow": false }, { "x": 144, "y": 2400000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.4", "yshift": 10, "showarrow": false }, { "x": 145, "y": 2340000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.3", "yshift": 10, "showarrow": false }, { "x": 146, "y": 2304000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.3", "yshift": 10, "showarrow": false }, { "x": 147, "y": 2280000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.3", "yshift": 10, "showarrow": false }, { "x": 148, "y": 2262000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.3", "yshift": 10, "showarrow": false }, { "x": 149, "y": 2223000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.2", "yshift": 10, "showarrow": false }, { "x": 150, "y": 2210000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.2", "yshift": 10, "showarrow": false }, { "x": 151, "y": 2160000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.2", "yshift": 10, "showarrow": false }, { "x": 152, "y": 2145000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.1", "yshift": 10, "showarrow": false }, { "x": 153, "y": 2145000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.1", "yshift": 10, "showarrow": false }, { "x": 154, "y": 2145000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.1", "yshift": 10, "showarrow": false }, { "x": 155, "y": 2080000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.1", "yshift": 10, "showarrow": false }, { "x": 156, "y": 2040000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.0", "yshift": 10, "showarrow": false }, { "x": 157, "y": 2028000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.0", "yshift": 10, "showarrow": false }, { "x": 158, "y": 2028000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.0", "yshift": 10, "showarrow": false }, { "x": 159, "y": 1980000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.0", "yshift": 10, "showarrow": false }, { "x": 160, "y": 1930500.0, "font": { "size": 10, "color": "#797979" }, "text": "1.9", "yshift": 10, "showarrow": false }, { "x": 161, "y": 1900800.0, "font": { "size": 10, "color": "#797979" }, "text": "1.9", "yshift": 10, "showarrow": false }, { "x": 162, "y": 1860000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.9", "yshift": 10, "showarrow": false }, { "x": 163, "y": 1800000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.8", "yshift": 10, "showarrow": false }, { "x": 164, "y": 1755000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.8", "yshift": 10, "showarrow": false }, { "x": 165, "y": 1690000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.7", "yshift": 10, "showarrow": false }, { "x": 166, "y": 1644300.0, "font": { "size": 10, "color": "#797979" }, "text": "1.6", "yshift": 10, "showarrow": false }, { "x": 167, "y": 1518000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.5", "yshift": 10, "showarrow": false }, { "x": 168, "y": 1365000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.4", "yshift": 10, "showarrow": false }, { "x": 169, "y": 1250000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.2", "yshift": 10, "showarrow": false }, { "x": 170, "y": 1200000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.2", "yshift": 10, "showarrow": false }, { "x": 171, "y": 1131000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.1", "yshift": 10, "showarrow": false }, { "x": 172, "y": 1120000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.1", "yshift": 10, "showarrow": false }, { "x": 173, "y": 1087500.0, "font": { "size": 10, "color": "#797979" }, "text": "1.1", "yshift": 10, "showarrow": false }, { "x": 174, "y": 1080000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.1", "yshift": 10, "showarrow": false }, { "x": 175, "y": 1044000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.0", "yshift": 10, "showarrow": false }, { "x": 176, "y": 1040000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.0", "yshift": 10, "showarrow": false }, { "x": 177, "y": 1020000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.0", "yshift": 10, "showarrow": false }, { "x": 178, "y": 912500.0, "font": { "size": 10, "color": "#797979" }, "text": "0.9", "yshift": 10, "showarrow": false }, { "x": 179, "y": 840000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.8", "yshift": 10, "showarrow": false }, { "x": 180, "y": 809100.0, "font": { "size": 10, "color": "#797979" }, "text": "0.8", "yshift": 10, "showarrow": false }, { "x": 181, "y": 804000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.8", "yshift": 10, "showarrow": false }, { "x": 182, "y": 725000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.7", "yshift": 10, "showarrow": false }, { "x": 183, "y": 648000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.6", "yshift": 10, "showarrow": false }, { "x": 184, "y": 600000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.6", "yshift": 10, "showarrow": false }, { "x": 185, "y": 520000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.5", "yshift": 10, "showarrow": false } ], "updatemenus": [ { "x": 1, "y": 1.16, "pad": { "b": 2, "l": 4, "r": 4, "t": 2 }, "font": { "size": 11, "color": "white" }, "type": "buttons", "active": 0, "bgcolor": "rgba(60,60,60,0.9)", "buttons": [ { "args": [ { "visible": [ true, true, true ] } ], "label": "Show the line", "method": "update" }, { "args": [ { "visible": [ true, true, false ] } ], "label": "Hide the line", "method": "update" } ], "xanchor": "right", "yanchor": "top", "direction": "right", "showactive": false, "bordercolor": "rgba(100,100,100,0.5)", "borderwidth": 1 } ] } }, "height": 1000, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~aboveandbeyond", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/82.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-9.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-08-10 12:36:04", "mapbox_access_tokens": null, "has_password": null, "username": "aboveandbeyond", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-08-10T12:34:15.634807Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~diannelauc/83.embed", "fid": "diannelauc:83", "filename": "14th day with fly ash TENSILE", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/diannelauc/83/9_Z9PL9BAA0MOB4O1LXIE16UUWT9KIBR.png", "image_urls": { "default": "https://api.plotly.com/v2/files/diannelauc:83/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/diannelauc/83/8_B3N89KZJ520RZEQ7ZPIHV6AD9ETQMW.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/diannelauc/83/9_Z9PL9BAA0MOB4O1LXIE16UUWT9KIBR.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/diannelauc:83", "plots": "https://api.plotly.com/v2/plots/diannelauc:83", "parent": "https://api.plotly.com/v2/folders/home?user=diannelauc" }, "owner": "diannelauc", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 135, "web_url": "https://chart-studio.plotly.com/~diannelauc/83/", "world_readable": true, "date_modified": "2025-08-10T12:44:38.731Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~diannelauc/83/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "y": "A" } }, "mode": "markers", "name": "Control", "type": "box", "ysrc": "diannelauc:82:13edea", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "hoveron": "boxes+points", "notched": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "B" } }, "name": "0% MSSA 30% CDW", "type": "box", "ysrc": "diannelauc:82:8254a2", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "C" } }, "name": "0% MSSA 50% CDW", "type": "box", "ysrc": "diannelauc:82:9f1d4c", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "D" } }, "name": "0% MSSA 70% CDW", "type": "box", "ysrc": "diannelauc:82:b05272", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "E" } }, "name": "5% MSSA 0% CDW ", "type": "box", "ysrc": "diannelauc:82:608f72", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "F" } }, "name": "5% MSSA 30% CDW", "type": "box", "ysrc": "diannelauc:82:7ae72f", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "G" } }, "name": "5% MSSA 50% CDW", "type": "box", "ysrc": "diannelauc:82:6f3228", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "H" } }, "name": "5% MSSA 70% CDW", "type": "box", "ysrc": "diannelauc:82:483831", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "I" } }, "name": "10% MSSA 0% CDW", "type": "box", "ysrc": "diannelauc:82:a71349", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "J" } }, "name": "10% MSSA 50% CDW", "type": "box", "ysrc": "diannelauc:82:8a7877", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "K" } }, "name": "15% MSSA 30% CDW", "type": "box", "ysrc": "diannelauc:82:2cc518", "marker": { "line": { "width": 0 }, "color": "rgb(0, 150, 255)", "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "x": "", "y": "" } }, "mode": "lines", "type": "scatter", "xaxis": "x", "yaxis": "y", "visible": "legendonly", "boxpoints": false }, { "meta": { "columnNames": { "y": "N" } }, "mode": "lines", "name": "5% Fly Ash 0% CDW", "type": "box", "ysrc": "diannelauc:82:095ef8", "visible": true, "boxpoints": false, "stackgroup": null }, { "meta": { "columnNames": { "y": "O" } }, "name": "5% Fly Ash 50% CDW", "type": "box", "ysrc": "diannelauc:82:6113a1", "boxpoints": false }, { "meta": { "columnNames": { "y": "P" } }, "name": "10% Fly Ash 0% CDW", "type": "box", "ysrc": "diannelauc:82:bb5304", "boxpoints": false }, { "meta": { "columnNames": { "y": "Q" } }, "name": "10% Fly Ash 50% CDW", "type": "box", "ysrc": "diannelauc:82:455117", "boxpoints": false } ], "frames": [], "layout": { "title": { "text": "14th Day Split Tensile Strength of M30 Concrete Mix Designs" }, "xaxis": { "type": "category", "dtick": 1, "range": [ -0.5, 15 ], "tick0": 0, "ticks": "", "title": { "text": "Click to enter X axis title" }, "domain": [ 0, 1 ], "showline": false, "tickmode": "auto", "autorange": false, "showspikes": true, "rangeslider": { "range": [ -0.8570504527813713, 11.014877102199224 ], "yaxis": {}, "visible": false, "autorange": true }, "showticklabels": false }, "yaxis": { "side": "left", "type": "linear", "dtick": 1, "range": [ -6.527027027027027, 8 ], "tick0": 0, "ticks": "", "title": { "text": "Tensile Strength, MPa" }, "domain": [ 0, 1 ], "tickmode": "auto", "autorange": false, "showspikes": true }, "shapes": [ { "x0": -0.5, "x1": 15, "y0": 24.1, "y1": 24.1, "line": { "color": "rgb(245, 8, 8)", "width": 2 }, "type": "line", "opacity": 0.3, "visible": false, "fillcolor": "#7f7f7f" }, { "x0": 3.5, "x1": 3.5, "y0": -4.5, "y1": 30, "line": { "dash": "solid", "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 7.5, "x1": 7.5, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 9.5, "x1": 9.5, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 10.700084881026578, "x1": 10.700084881026578, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 12.5, "x1": 12.5, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" } ], "autosize": true, "dragmode": "zoom", "hovermode": "x", "annotations": [ { "x": 1.5, "y": 2, "ax": -10, "ay": 29, "text": "0% MSSA", "arrowcolor": "rgb(255, 255, 255)" }, { "x": 5.5, "y": 2, "ax": 7, "ay": 28, "text": "5% MSSA", "arrowcolor": "rgb(255, 255, 255)" }, { "x": 8.5, "y": 2.6, "ax": -5, "ay": 42, "text": "10% MSSA", "arrowcolor": "rgb(255, 255, 255)" }, { "x": 0.03840728859401114, "y": -2.5, "ax": -1, "ay": -6, "text": "0% <br>" }, { "x": 1, "y": -2.5, "ax": -1, "ay": -7, "text": "30% " }, { "x": 2.1, "y": -2.5, "ax": -10, "ay": -8, "text": "50% " }, { "x": 3, "y": -2.5, "ax": -10, "ay": -8, "text": "70% " }, { "x": 1.3, "y": -3.5, "ax": 6, "ay": -4, "text": "CDW", "arrowcolor": "rgb(46, 28, 28)" }, { "x": 4, "y": -2.5, "ax": 3, "ay": -8, "text": "0%" }, { "x": 4.9, "y": -2.5, "ax": 2, "ay": -7, "text": "30%" }, { "x": 5.999929072681703, "y": -2.5, "ax": -2, "ay": -7, "text": "50%" }, { "x": 7, "y": -2.5, "ax": 0, "ay": -9, "text": "70%" }, { "x": 5.4, "y": -3.5, "ax": 8, "ay": -2, "text": "CDW" }, { "x": 8, "y": -2.5, "ax": -2, "ay": -8, "text": "0%" }, { "x": 9, "y": -2, "ax": -1, "ay": 4, "text": "50%" }, { "x": 8.5, "y": -3.5, "ax": -2, "ay": -4, "text": "CDW" }, { "x": 10, "y": -2.5, "ax": 6, "ay": -8, "text": "30%" }, { "x": 10, "y": -3.5, "ax": 6, "ay": -6, "text": "CDW" }, { "x": 11, "y": -2.5, "ax": 2, "ay": -8, "text": "0%" }, { "x": 12, "y": -2.5, "ax": 2, "ay": -7, "text": "50%" }, { "x": 11.5, "y": -3.5, "ax": 4, "ay": -2, "text": "CDW" }, { "x": 13, "y": -2, "ax": -2, "ay": 3, "text": "0%" }, { "x": 14, "y": -2, "ax": -10, "ay": 3, "text": "50%" }, { "x": 13.229422232493182, "y": -5, "ax": 10, "ay": -32, "text": "CDW", "arrowcolor": "rgb(255, 253, 253)" }, { "x": 11.7, "y": 1, "ax": -10, "ay": 8, "text": "5% Fly Ash" }, { "x": 13.5, "y": 1, "ax": -10, "ay": 7, "text": "10% Fly Ash" }, { "x": 10.5, "y": 1, "ax": -20, "ay": 8, "text": "15% MSSA" } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~diannelauc", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/69.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-25 22:45:50", "mapbox_access_tokens": null, "has_password": null, "username": "diannelauc", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-08-10T12:07:29.702109Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~diannelauc/81.embed", "fid": "diannelauc:81", "filename": "7th day with fly ash TENSILE", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/diannelauc/81/9_XLB5I9HXP8PEN8UYNLVKVDHHMH5M6U.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/diannelauc/81/2_R26TVWCXBMUA5UTDI15IE9JA8NJSV9.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/diannelauc/81/8_CRX18JOUZVBUMAOUY3K29GOC25YQHH.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/diannelauc/81/9_XLB5I9HXP8PEN8UYNLVKVDHHMH5M6U.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/diannelauc:81", "plots": "https://api.plotly.com/v2/plots/diannelauc:81", "parent": "https://api.plotly.com/v2/folders/home?user=diannelauc" }, "owner": "diannelauc", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 135, "web_url": "https://chart-studio.plotly.com/~diannelauc/81/", "world_readable": true, "date_modified": "2025-08-10T12:54:28.109Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~diannelauc/81/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "y": "A" } }, "mode": "markers", "name": "Control", "type": "box", "ysrc": "diannelauc:80:13edea", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "hoveron": "boxes+points", "notched": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "B" } }, "name": "0% MSSA 30% CDW", "type": "box", "ysrc": "diannelauc:80:8254a2", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "C" } }, "name": "0% MSSA 50% CDW", "type": "box", "ysrc": "diannelauc:80:9f1d4c", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "D" } }, "name": "0% MSSA 70% CDW", "type": "box", "ysrc": "diannelauc:80:b05272", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "E" } }, "name": "5% MSSA 0% CDW ", "type": "box", "ysrc": "diannelauc:80:608f72", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "F" } }, "name": "5% MSSA 30% CDW", "type": "box", "ysrc": "diannelauc:80:7ae72f", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "G" } }, "name": "5% MSSA 50% CDW", "type": "box", "ysrc": "diannelauc:80:6f3228", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "H" } }, "name": "5% MSSA 70% CDW", "type": "box", "ysrc": "diannelauc:80:483831", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "I" } }, "name": "10% MSSA 0% CDW", "type": "box", "ysrc": "diannelauc:80:a71349", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "J" } }, "name": "10% MSSA 50% CDW", "type": "box", "ysrc": "diannelauc:80:8a7877", "marker": { "line": { "width": 0 }, "opacity": 1 }, "boxmean": false, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "y": "K" } }, "name": "15% MSSA 30% CDW", "type": "box", "ysrc": "diannelauc:80:2cc518", "marker": { "line": { "width": 0 }, "color": "rgb(0, 150, 255)", "opacity": 1 }, "boxmean": false, "visible": true, "boxpoints": "outliers", "hoverinfo": "name", "hovertemplate": "<br>" }, { "meta": { "columnNames": { "x": "", "y": "" } }, "mode": "lines", "type": "scatter", "xaxis": "x", "yaxis": "y", "visible": "legendonly", "boxpoints": false }, { "meta": { "columnNames": { "y": "N" } }, "mode": "lines", "name": "5% Fly Ash 0% CDW", "type": "box", "ysrc": "diannelauc:80:095ef8", "visible": true, "boxpoints": false, "stackgroup": null }, { "meta": { "columnNames": { "y": "O" } }, "name": "5% Fly Ash 50% CDW", "type": "box", "ysrc": "diannelauc:80:6113a1", "boxpoints": false }, { "meta": { "columnNames": { "y": "P" } }, "name": "10% Fly Ash 0% CDW", "type": "box", "ysrc": "diannelauc:80:bb5304", "boxpoints": false }, { "meta": { "columnNames": { "y": "Q" } }, "name": "10% Fly Ash 50% CDW", "type": "box", "ysrc": "diannelauc:80:455117", "boxpoints": false } ], "frames": [], "layout": { "title": { "text": "7th Day Split Tensile Strength of M30 Concrete Mix Designs" }, "xaxis": { "type": "category", "dtick": 1, "range": [ -0.5, 15 ], "tick0": 0, "ticks": "", "title": { "text": "Click to enter X axis title" }, "domain": [ 0, 1 ], "showline": false, "tickmode": "auto", "autorange": false, "showspikes": true, "rangeslider": { "range": [ -0.8570504527813713, 11.014877102199224 ], "yaxis": {}, "visible": false, "autorange": true }, "showticklabels": false }, "yaxis": { "side": "left", "type": "linear", "dtick": 1, "range": [ -6.527027027027027, 8 ], "tick0": 0, "ticks": "", "title": { "text": "Tensile Strength, MPa" }, "domain": [ 0, 1 ], "tickmode": "auto", "autorange": false, "showspikes": true }, "shapes": [ { "x0": -0.5, "x1": 15, "y0": 24.1, "y1": 24.1, "line": { "color": "rgb(245, 8, 8)", "width": 2 }, "type": "line", "opacity": 0.3, "visible": false, "fillcolor": "#7f7f7f" }, { "x0": 3.5, "x1": 3.5, "y0": -4.5, "y1": 30, "line": { "dash": "solid", "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 7.5, "x1": 7.5, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 9.5, "x1": 9.5, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 10.700084881026578, "x1": 10.700084881026578, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" }, { "x0": 12.5, "x1": 12.5, "y0": -4.5, "y1": 30, "line": { "color": "#444444" }, "type": "line", "opacity": 0.3, "fillcolor": "#7f7f7f" } ], "autosize": true, "dragmode": "zoom", "hovermode": "x", "annotations": [ { "x": 1.5, "y": 2, "ax": -10, "ay": 29, "text": "0% MSSA", "arrowcolor": "rgb(255, 255, 255)" }, { "x": 5.5, "y": 2, "ax": 7, "ay": 28, "text": "5% MSSA", "arrowcolor": "rgb(255, 255, 255)" }, { "x": 8.5, "y": 2.6, "ax": -5, "ay": 42, "text": "10% MSSA", "arrowcolor": "rgb(255, 255, 255)" }, { "x": 0.03840728859401114, "y": -2.5, "ax": -1, "ay": -6, "text": "0% <br>" }, { "x": 1, "y": -2.5, "ax": -1, "ay": -7, "text": "30% " }, { "x": 2.1, "y": -2.5, "ax": -10, "ay": -8, "text": "50% " }, { "x": 3, "y": -2.5, "ax": -10, "ay": -8, "text": "70% " }, { "x": 1.3, "y": -3.5, "ax": 6, "ay": -4, "text": "CDW", "arrowcolor": "rgb(46, 28, 28)" }, { "x": 4, "y": -2.5, "ax": 3, "ay": -8, "text": "0%" }, { "x": 4.9, "y": -2.5, "ax": 2, "ay": -7, "text": "30%" }, { "x": 5.999929072681703, "y": -2.5, "ax": -2, "ay": -7, "text": "50%" }, { "x": 7, "y": -2.5, "ax": 0, "ay": -9, "text": "70%" }, { "x": 5.4, "y": -3.5, "ax": 8, "ay": -2, "text": "CDW" }, { "x": 8, "y": -2.5, "ax": -2, "ay": -8, "text": "0%" }, { "x": 9, "y": -2, "ax": -1, "ay": 4, "text": "50%" }, { "x": 8.5, "y": -3.5, "ax": -2, "ay": -4, "text": "CDW" }, { "x": 10, "y": -2.5, "ax": 6, "ay": -8, "text": "30%" }, { "x": 10, "y": -3.5, "ax": 6, "ay": -6, "text": "CDW" }, { "x": 11, "y": -2.5, "ax": 2, "ay": -8, "text": "0%" }, { "x": 12, "y": -2.5, "ax": 2, "ay": -7, "text": "50%" }, { "x": 11.5, "y": -3.5, "ax": 4, "ay": -2, "text": "CDW" }, { "x": 13, "y": -2, "ax": -2, "ay": 3, "text": "0%" }, { "x": 14, "y": -2, "ax": -10, "ay": 3, "text": "50%" }, { "x": 13.229422232493182, "y": -5, "ax": 10, "ay": -32, "text": "CDW", "arrowcolor": "rgb(255, 253, 253)" }, { "x": 11.7, "y": 1, "ax": -10, "ay": 8, "text": "5% Fly Ash" }, { "x": 13.5, "y": 1, "ax": -10, "ay": 7, "text": "10% Fly Ash" }, { "x": 10.5, "y": 1, "ax": -20, "ay": 8, "text": "15% MSSA" } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~diannelauc", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/69.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-25 22:45:50", "mapbox_access_tokens": null, "has_password": null, "username": "diannelauc", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-08-10T11:22:05.497337Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~4e/541.embed", "fid": "4e:541", "filename": "Plot 541", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/4e:541/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/4e/541/2_M2L00OHB4W07HWK5KDYSNTUPP9JAHT.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/4e/541/8_T5I1VVSZH3M0GWOKVNX5PV2LDSK4JM.png", "list-thumb": "https://api.plotly.com/v2/files/4e:541/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/4e:541", "plots": "https://api.plotly.com/v2/plots/4e:541", "parent": "https://api.plotly.com/v2/folders/home?user=4e" }, "owner": "4e", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~4e/541/", "world_readable": true, "date_modified": "2025-08-10T17:49:02.926Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~4e/541/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(16, 140, 3)" }, "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "lines", "type": "scatter", "xsrc": "4e:540:b10413", "ysrc": "4e:540:e4d66f", "visible": true, "connectgaps": true }, { "meta": { "columnNames": { "x": "A", "y": "C" } }, "mode": "lines", "type": "scatter", "xsrc": "4e:540:b10413", "ysrc": "4e:540:00a725", "stackgroup": null }, { "line": { "color": "rgb(16, 140, 3)" }, "meta": { "columnNames": { "x": "D", "y": "E" } }, "mode": "lines", "type": "scatter", "xsrc": "4e:540:f6708f", "ysrc": "4e:540:209c52", "visible": true, "stackgroup": null, "connectgaps": true } ], "frames": [], "layout": { "title": { "text": "Bandit" }, "xaxis": { "type": "category", "range": [ 0, 5688 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ -3549.1666666666665, 67434.16666666667 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "hovermode": "x" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~4e", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/25.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-12.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-09-12 13:44:49", "mapbox_access_tokens": null, "has_password": null, "username": "4e", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-08-10T06:23:21.369567Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~NEHAAAAAAAA/1.embed", "fid": "NEHAAAAAAAA:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/NEHAAAAAAAA/1/9_ICX8ONFXXW8I0BLLVPHSKTZUVN4BVY.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/NEHAAAAAAAA/1/2_R4BFTUWGVKXM6YJ9IBS9MF6XZUWV87.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/NEHAAAAAAAA/1/8_F1K26I4CW1GRK7M6B9L74VW7K10B8M.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/NEHAAAAAAAA/1/9_ICX8ONFXXW8I0BLLVPHSKTZUVN4BVY.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/NEHAAAAAAAA:1", "plots": "https://api.plotly.com/v2/plots/NEHAAAAAAAA:1", "parent": "https://api.plotly.com/v2/folders/home?user=NEHAAAAAAAA" }, "owner": "NEHAAAAAAAA", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~NEHAAAAAAAA/1/", "world_readable": true, "date_modified": "2025-08-10T06:36:19.102Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~NEHAAAAAAAA/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "A", "y": "B" } }, "mode": "lines", "type": "scatter", "xsrc": "NEHAAAAAAAA:0:139889", "ysrc": "NEHAAAAAAAA:0:f8be1d", "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "MACHINE OIL" }, "xaxis": { "type": "linear", "range": [ 35, 60 ], "title": { "text": "ANGLE OF INCIDENCE" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 33, 53 ], "title": { "text": "ANGLE OF DEVIATION" }, "autorange": true }, "autosize": true, "dragmode": "zoom", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~NEHAAAAAAAA", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/82.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-08-10 06:19:55", "mapbox_access_tokens": null, "has_password": null, "username": "NEHAAAAAAAA", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-08-10T01:23:00.407428Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~nikschankin/4.embed", "fid": "nikschankin:4", "filename": "fless-salary-research", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/nikschankin/4/9_0EMN43DIDNRIYHM5FL6FNWXYPY4HA1.png", "image_urls": { "default": "https://api.plotly.com/v2/files/nikschankin:4/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/nikschankin/4/8_4JM4UU4WN1LIN4TGUERN7U8J6QMWH8.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/nikschankin/4/9_0EMN43DIDNRIYHM5FL6FNWXYPY4HA1.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/nikschankin:4", "plots": "https://api.plotly.com/v2/plots/nikschankin:4", "parent": "https://api.plotly.com/v2/folders/home?user=nikschankin" }, "owner": "nikschankin", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~nikschankin/4/", "world_readable": true, "date_modified": "2025-08-10T12:37:39.533Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~nikschankin/4/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "name": "Зарплата в год", "type": "bar", "xsrc": "nikschankin:5:93047d", "ysrc": "nikschankin:5:605c8e", "marker": { "color": "#636EFA" }, "textsrc": "nikschankin:5:f352f4", "textfont": { "size": 10, "color": "rgb(184,189,252)" }, "textposition": "inside", "customdatasrc": "nikschankin:5:783ed5", "hovertemplate": "<b>%{customdata[0]}</b><br>%{customdata[1]}<br>", "insidetextanchor": "end" }, { "name": "Годовой бонус", "type": "bar", "xsrc": "nikschankin:5:1ce1f6", "ysrc": "nikschankin:5:75cae7", "marker": { "color": "#EF553B" }, "textsrc": "nikschankin:5:e7926b", "textfont": { "size": 10, "color": "rgb(249,195,186)" }, "textposition": "inside", "customdatasrc": "nikschankin:5:b8f68c", "hovertemplate": "<b>%{customdata[0]}</b><br>%{customdata[1]}<br>", "insidetextanchor": "end" }, { "line": { "color": "white", "width": 2 }, "mode": "lines", "name": "Зарплата в месяц", "type": "scatter", "xsrc": "nikschankin:5:dfceb8", "ysrc": "nikschankin:5:b16edb", "yaxis": "y2", "customdatasrc": "nikschankin:5:ac7f0d", "hovertemplate": "<b>%{customdata[0]}</b><br>%{customdata[1]}<br>Зарплата в месяц: %{customdata[2]:,}<br>" } ], "layout": { "title": { "text": "Зарплата и бонусы по компаниям" }, "xaxis": { "type": "linear", "title": { "text": "Компания" }, "tickmode": "array", "ticktext": [ "Tier 2 consulting company", "Консалтинговый бутик", "Kearney", "Одна из Биг Фарма компаний ", "PwC", "Яков и Партнеры", "HQ", "Accenture", "NDA, trading", "Roland Berger", "Яндекс ", "Яндекс", "Крупная компания из сферы горной добычи", "Bolt", "Сибур", "Private", "Авито", "Яков и Партнёры", "BCG", "Ростех (один из холдингов)", "McK", "Озон", "Б1", "Yandex", "Авито", "Anonym", "Goldman Sachs", "Etched ", "АТК", "VC Fund", "X5", "Яндекс", "Норильский никель", "Family office", "ООО ВКонтакте", "Small IT company ", "Яндекс", "Биржа", "ДОМ РФ", "сбер", "ГНИВЦ", "Вб", "Мкб", "ФЦК", "WB Tech", "Yeresoft", "СИБУР ", "Т1 (ИТ Холдинг)", "Яндекс", "Яндекс", "Кэпт", "Indefi", "GFO X", "Северсталь", "Роснефть (дочернее общество в группе)", "Avito", "Т-банк", "Яндекс", "-", null, "не скажу", "Travel tech", "Авито", "Х5", "Банки.ру", "Газпром нефть ", "Яндекс", "Правительство Московской области ", "Втб", "Альфа банк", "МТС", "Сбер", "-", "Небольшая компания с выручкой менее 10 млрд руб (Metals&Mining)", "VK", "Erste", "Family Office", "Альфа Банк", "Мегафон ", "Яндекс", "Девелоперская компания", "Консалтинг бутик", "Яндекс", "Sporting goods", "Xxx", "Dodo Brands", "Arthur Consulting", "Группа Неман", "IDF Eurasia", "Пепсико", "OilTeam", "Альфа-Банк", "Яндекс", "Компания в сфере энергетике ", "Сбербанк", "Промсвязьбанк", "Excellence Expert", "AT", "ЦБП", "Федеральный застройщик", "Дефендер", "Билайн", "Ozon", "IQVIA", "Дочка Лукойла ", "Самокат тех", "МТС Рекламные технологий ", "ТеДо", "Ростелеком", "Департамент информационных технологий ", "Retail ", "Итмо", "ГК Альфа", "Сбер", "Втб", "Татнефть", "Arthur Consulting", "Сколково", "Sminex", "F", "Магнит", "Т-Банк", "GlowByte", "Точка", "Альфа-банк ", "Яндекс", "Яндекс Такси", "Wildberries", "ФЦК", "Яндекс", "Газпромнефть-Ямал", "Группа Неман", "ВТБ", "Б1", "OKS Labs", "Технологии Доверия", "Экопси", "Avitotech", "Яндекс ", "ООО Технологии Доверия", "Samolet", "Альфа банк ", "Центр по внешней торговле при Минпромторге", "ПАО Банк ПСБ", "Компания в области решений для Советов директоров", "Big4", "Strategy partners", "Яков и Партнёры", "Технологии Доверия", "VK", "ТБанк", "ДРТ", "Спортмастер", "ТБанк", "-", "Тбанк", "Авито", "Т-Банк", "Kept", "Kept (ex KPMG)", "Тбанк", "Kept", "Sber", "McK Partners", "Технологии доверия", "Технологии Доверия", "Strategy partners", "Газпром нефть", "Яндекс", "Роснефть", "НДА", "Б1", "Технологии Доверия", "Банк Хлынов", "Технологии Доверия", "Отраслевой консалтинг", "Тедо", "o2consulting", "EY", "Б1", "\"Деловые решения и технологии\" ex. Deloitte", "Сбер", "EY", "Strategy partners", "ООО «РУСАУДИТ»", "АО Узбекнефтегаз" ], "tickvals": [ 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 70, 71, 72, 73, 74, 75, 76, 77, 78, 79, 80, 81, 82, 83, 84, 85, 86, 87, 88, 89, 90, 91, 92, 93, 94, 95, 96, 97, 98, 99, 100, 101, 102, 103, 104, 105, 106, 107, 108, 109, 110, 111, 112, 113, 114, 115, 116, 117, 118, 119, 120, 121, 122, 123, 124, 125, 126, 127, 128, 129, 130, 131, 132, 133, 134, 135, 136, 137, 138, 139, 140, 141, 142, 143, 144, 145, 146, 147, 148, 149, 150, 151, 152, 153, 154, 155, 156, 157, 158, 159, 160, 161, 162, 163, 164, 165, 166, 167, 168, 169, 170, 171, 172, 173, 174, 175, 176, 177, 178, 179, 180, 181, 182, 183, 184, 185 ], "tickangle": -60, "rangeslider": { "visible": true }, "showticklabels": true }, "yaxis": { "title": { "font": { "color": "rgba(220,220,220,0.9)" }, "text": "Млн руб" }, "showgrid": true, "tickfont": { "color": "rgba(220,220,220,0.9)" }, "ticktext": [ "0", "5", "10", "15", "20", "25", "30" ], "tickvals": [ 0, 5000000, 10000000, 15000000, 20000000, 25000000, 30000000 ], "zeroline": true, "gridcolor": "rgba(255,255,255,0.08)", "zerolinecolor": "rgba(255,255,255,0.25)" }, "height": 1000, "legend": { "x": 0.5, "y": 1.02, "xanchor": "center", "yanchor": "bottom", "orientation": "h" }, "margin": { "b": 140, "t": 90 }, "yaxis2": { "side": "right", "title": { "font": { "color": "white" }, "text": "Зарплата в месяц (руб)" }, "showgrid": false, "tickfont": { "color": "white" }, "rangemode": "tozero", "overlaying": "y" }, "barmode": "stack", "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "rgb(17,17,17)", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#f2f5fa" }, "error_y": { "color": "#f2f5fa" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#506784" }, "line": { "color": "rgb(17,17,17)" } }, "header": { "fill": { "color": "#2a3f5f" }, "line": { "color": "rgb(17,17,17)" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#506784", "linecolor": "#506784", "endlinecolor": "#A2B1C6", "minorgridcolor": "#506784", "startlinecolor": "#A2B1C6" }, "baxis": { "gridcolor": "#506784", "linecolor": "#506784", "endlinecolor": "#A2B1C6", "minorgridcolor": "#506784", "startlinecolor": "#A2B1C6" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "marker": { "line": { "color": "#283442" } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "rgb(17,17,17)", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "line": { "color": "#283442" } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "rgb(17,17,17)", "showland": true, "lakecolor": "rgb(17,17,17)", "landcolor": "rgb(17,17,17)", "showlakes": true, "subunitcolor": "#506784" }, "font": { "color": "#f2f5fa" }, "polar": { "bgcolor": "rgb(17,17,17)", "radialaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "angularaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" }, "yaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" }, "zaxis": { "ticks": "", "gridcolor": "#506784", "gridwidth": 2, "linecolor": "#506784", "zerolinecolor": "#C8D4E3", "showbackground": true, "backgroundcolor": "rgb(17,17,17)" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "#283442", "linecolor": "#506784", "automargin": true, "zerolinecolor": "#283442", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "#283442", "linecolor": "#506784", "automargin": true, "zerolinecolor": "#283442", "zerolinewidth": 2 }, "mapbox": { "style": "dark" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "baxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "caxis": { "ticks": "", "gridcolor": "#506784", "linecolor": "#506784" }, "bgcolor": "rgb(17,17,17)" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "rgb(17,17,17)", "paper_bgcolor": "rgb(17,17,17)", "shapedefaults": { "line": { "color": "#f2f5fa" } }, "sliderdefaults": { "bgcolor": "#C8D4E3", "tickwidth": 0, "bordercolor": "rgb(17,17,17)", "borderwidth": 1 }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#f2f5fa", "arrowwidth": 1 }, "updatemenudefaults": { "bgcolor": "#506784", "borderwidth": 0 } } }, "showlegend": true, "annotations": [ { "x": 0, "y": 28800000.0, "font": { "size": 10, "color": "#797979" }, "text": "28.8", "yshift": 10, "showarrow": false }, { "x": 1, "y": 22400000.0, "font": { "size": 10, "color": "#797979" }, "text": "22.4", "yshift": 10, "showarrow": false }, { "x": 2, "y": 18000000.0, "font": { "size": 10, "color": "#797979" }, "text": "18", "yshift": 10, "showarrow": false }, { "x": 3, "y": 17420000.0, "font": { "size": 10, "color": "#797979" }, "text": "17.4", "yshift": 10, "showarrow": false }, { "x": 4, "y": 15975000.0, "font": { "size": 10, "color": "#797979" }, "text": "16.0", "yshift": 10, "showarrow": false }, { "x": 5, "y": 15000000.0, "font": { "size": 10, "color": "#797979" }, "text": "15", "yshift": 10, "showarrow": false }, { "x": 6, "y": 13600000.0, "font": { "size": 10, "color": "#797979" }, "text": "13.6", "yshift": 10, "showarrow": false }, { "x": 7, "y": 13000000.0, "font": { "size": 10, "color": "#797979" }, "text": "13", "yshift": 10, "showarrow": false }, { "x": 8, "y": 12800000.0, "font": { "size": 10, "color": "#797979" }, "text": "12.8", "yshift": 10, "showarrow": false }, { "x": 9, "y": 12750000.0, "font": { "size": 10, "color": "#797979" }, "text": "12.8", "yshift": 10, "showarrow": false }, { "x": 10, "y": 11900000.0, "font": { "size": 10, "color": "#797979" }, "text": "11.9", "yshift": 10, "showarrow": false }, { "x": 11, "y": 11050000.0, "font": { "size": 10, "color": "#797979" }, "text": "11.1", "yshift": 10, "showarrow": false }, { "x": 12, "y": 10800000.0, "font": { "size": 10, "color": "#797979" }, "text": "10.8", "yshift": 10, "showarrow": false }, { "x": 13, "y": 10080000.0, "font": { "size": 10, "color": "#797979" }, "text": "10.1", "yshift": 10, "showarrow": false }, { "x": 14, "y": 10080000.0, "font": { "size": 10, "color": "#797979" }, "text": "10.1", "yshift": 10, "showarrow": false }, { "x": 15, "y": 9600000.0, "font": { "size": 10, "color": "#797979" }, "text": "9.6", "yshift": 10, "showarrow": false }, { "x": 16, "y": 9520000.0, "font": { "size": 10, "color": "#797979" }, "text": "9.5", "yshift": 10, "showarrow": false }, { "x": 17, "y": 9300000.0, "font": { "size": 10, "color": "#797979" }, "text": "9.3", "yshift": 10, "showarrow": false }, { "x": 18, "y": 9062500.0, "font": { "size": 10, "color": "#797979" }, "text": "9.1", "yshift": 10, "showarrow": false }, { "x": 19, "y": 8850000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.8", "yshift": 10, "showarrow": false }, { "x": 20, "y": 8400000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.4", "yshift": 10, "showarrow": false }, { "x": 21, "y": 8320000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.3", "yshift": 10, "showarrow": false }, { "x": 22, "y": 8250000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.2", "yshift": 10, "showarrow": false }, { "x": 23, "y": 8160000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.2", "yshift": 10, "showarrow": false }, { "x": 24, "y": 8100000.0, "font": { "size": 10, "color": "#797979" }, "text": "8.1", "yshift": 10, "showarrow": false }, { "x": 25, "y": 8000000.0, "font": { "size": 10, "color": "#797979" }, "text": "8", "yshift": 10, "showarrow": false }, { "x": 26, "y": 7750000.0, "font": { "size": 10, "color": "#797979" }, "text": "7.8", "yshift": 10, "showarrow": false }, { "x": 27, "y": 7680000.0, "font": { "size": 10, "color": "#797979" }, "text": "7.7", "yshift": 10, "showarrow": false }, { "x": 28, "y": 7500000.0, "font": { "size": 10, "color": "#797979" }, "text": "7.5", "yshift": 10, "showarrow": false }, { "x": 29, "y": 7500000.0, "font": { "size": 10, "color": "#797979" }, "text": "7.5", "yshift": 10, "showarrow": false }, { "x": 30, "y": 7310000.0, "font": { "size": 10, "color": "#797979" }, "text": "7.3", "yshift": 10, "showarrow": false }, { "x": 31, "y": 6750000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.8", "yshift": 10, "showarrow": false }, { "x": 32, "y": 6720000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.7", "yshift": 10, "showarrow": false }, { "x": 33, "y": 6650000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.7", "yshift": 10, "showarrow": false }, { "x": 34, "y": 6510000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.5", "yshift": 10, "showarrow": false }, { "x": 35, "y": 6480000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.5", "yshift": 10, "showarrow": false }, { "x": 36, "y": 6400000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.4", "yshift": 10, "showarrow": false }, { "x": 37, "y": 6360000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.4", "yshift": 10, "showarrow": false }, { "x": 38, "y": 6300000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.3", "yshift": 10, "showarrow": false }, { "x": 39, "y": 6200000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.2", "yshift": 10, "showarrow": false }, { "x": 40, "y": 6090000.0, "font": { "size": 10, "color": "#797979" }, "text": "6.1", "yshift": 10, "showarrow": false }, { "x": 41, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 42, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 43, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 44, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 45, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 46, "y": 6000000.0, "font": { "size": 10, "color": "#797979" }, "text": "6", "yshift": 10, "showarrow": false }, { "x": 47, "y": 5940000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.9", "yshift": 10, "showarrow": false }, { "x": 48, "y": 5920000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.9", "yshift": 10, "showarrow": false }, { "x": 49, "y": 5696000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.7", "yshift": 10, "showarrow": false }, { "x": 50, "y": 5670000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.7", "yshift": 10, "showarrow": false }, { "x": 51, "y": 5600000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.6", "yshift": 10, "showarrow": false }, { "x": 52, "y": 5600000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.6", "yshift": 10, "showarrow": false }, { "x": 53, "y": 5550000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.5", "yshift": 10, "showarrow": false }, { "x": 54, "y": 5520000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.5", "yshift": 10, "showarrow": false }, { "x": 55, "y": 5478000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.5", "yshift": 10, "showarrow": false }, { "x": 56, "y": 5460000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.5", "yshift": 10, "showarrow": false }, { "x": 57, "y": 5445000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.4", "yshift": 10, "showarrow": false }, { "x": 58, "y": 5400000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.4", "yshift": 10, "showarrow": false }, { "x": 59, "y": 5400000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.4", "yshift": 10, "showarrow": false }, { "x": 60, "y": 5355000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.4", "yshift": 10, "showarrow": false }, { "x": 61, "y": 5330000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.3", "yshift": 10, "showarrow": false }, { "x": 62, "y": 5200000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.2", "yshift": 10, "showarrow": false }, { "x": 63, "y": 5100000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.1", "yshift": 10, "showarrow": false }, { "x": 64, "y": 4987500.0, "font": { "size": 10, "color": "#797979" }, "text": "5.0", "yshift": 10, "showarrow": false }, { "x": 65, "y": 4960000.0, "font": { "size": 10, "color": "#797979" }, "text": "5.0", "yshift": 10, "showarrow": false }, { "x": 66, "y": 4906800.0, "font": { "size": 10, "color": "#797979" }, "text": "4.9", "yshift": 10, "showarrow": false }, { "x": 67, "y": 4900000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.9", "yshift": 10, "showarrow": false }, { "x": 68, "y": 4860000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.9", "yshift": 10, "showarrow": false }, { "x": 69, "y": 4830000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.8", "yshift": 10, "showarrow": false }, { "x": 70, "y": 4800000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.8", "yshift": 10, "showarrow": false }, { "x": 71, "y": 4800000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.8", "yshift": 10, "showarrow": false }, { "x": 72, "y": 4800000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.8", "yshift": 10, "showarrow": false }, { "x": 73, "y": 4745000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.7", "yshift": 10, "showarrow": false }, { "x": 74, "y": 4695000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.7", "yshift": 10, "showarrow": false }, { "x": 75, "y": 4680000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.7", "yshift": 10, "showarrow": false }, { "x": 76, "y": 4620000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.6", "yshift": 10, "showarrow": false }, { "x": 77, "y": 4560000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.6", "yshift": 10, "showarrow": false }, { "x": 78, "y": 4550000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.5", "yshift": 10, "showarrow": false }, { "x": 79, "y": 4410000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.4", "yshift": 10, "showarrow": false }, { "x": 80, "y": 4400000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.4", "yshift": 10, "showarrow": false }, { "x": 81, "y": 4350000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.3", "yshift": 10, "showarrow": false }, { "x": 82, "y": 4350000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.3", "yshift": 10, "showarrow": false }, { "x": 83, "y": 4290000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.3", "yshift": 10, "showarrow": false }, { "x": 84, "y": 4290000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.3", "yshift": 10, "showarrow": false }, { "x": 85, "y": 4200000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.2", "yshift": 10, "showarrow": false }, { "x": 86, "y": 4200000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.2", "yshift": 10, "showarrow": false }, { "x": 87, "y": 4200000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.2", "yshift": 10, "showarrow": false }, { "x": 88, "y": 4200000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.2", "yshift": 10, "showarrow": false }, { "x": 89, "y": 4200000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.2", "yshift": 10, "showarrow": false }, { "x": 90, "y": 4132500.0, "font": { "size": 10, "color": "#797979" }, "text": "4.1", "yshift": 10, "showarrow": false }, { "x": 91, "y": 4080000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.1", "yshift": 10, "showarrow": false }, { "x": 92, "y": 4060000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.1", "yshift": 10, "showarrow": false }, { "x": 93, "y": 4000000.0, "font": { "size": 10, "color": "#797979" }, "text": "4", "yshift": 10, "showarrow": false }, { "x": 94, "y": 3976000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.0", "yshift": 10, "showarrow": false }, { "x": 95, "y": 3952000.0, "font": { "size": 10, "color": "#797979" }, "text": "4.0", "yshift": 10, "showarrow": false }, { "x": 96, "y": 3920000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.9", "yshift": 10, "showarrow": false }, { "x": 97, "y": 3915000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.9", "yshift": 10, "showarrow": false }, { "x": 98, "y": 3850000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.9", "yshift": 10, "showarrow": false }, { "x": 99, "y": 3842500.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 100, "y": 3780000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 101, "y": 3780000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 102, "y": 3780000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 103, "y": 3780000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 104, "y": 3778500.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 105, "y": 3756000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.8", "yshift": 10, "showarrow": false }, { "x": 106, "y": 3654000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.7", "yshift": 10, "showarrow": false }, { "x": 107, "y": 3640000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 108, "y": 3640000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 109, "y": 3640000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 110, "y": 3640000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 111, "y": 3600000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 112, "y": 3600000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 113, "y": 3600000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.6", "yshift": 10, "showarrow": false }, { "x": 114, "y": 3528000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.5", "yshift": 10, "showarrow": false }, { "x": 115, "y": 3520000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.5", "yshift": 10, "showarrow": false }, { "x": 116, "y": 3510000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.5", "yshift": 10, "showarrow": false }, { "x": 117, "y": 3500000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.5", "yshift": 10, "showarrow": false }, { "x": 118, "y": 3467500.0, "font": { "size": 10, "color": "#797979" }, "text": "3.5", "yshift": 10, "showarrow": false }, { "x": 119, "y": 3307500.0, "font": { "size": 10, "color": "#797979" }, "text": "3.3", "yshift": 10, "showarrow": false }, { "x": 120, "y": 3300000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.3", "yshift": 10, "showarrow": false }, { "x": 121, "y": 3248000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.2", "yshift": 10, "showarrow": false }, { "x": 122, "y": 3220000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.2", "yshift": 10, "showarrow": false }, { "x": 123, "y": 3180000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.2", "yshift": 10, "showarrow": false }, { "x": 124, "y": 3151500.0, "font": { "size": 10, "color": "#797979" }, "text": "3.2", "yshift": 10, "showarrow": false }, { "x": 125, "y": 3150000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.1", "yshift": 10, "showarrow": false }, { "x": 126, "y": 3150000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.1", "yshift": 10, "showarrow": false }, { "x": 127, "y": 3120000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.1", "yshift": 10, "showarrow": false }, { "x": 128, "y": 3080000.0, "font": { "size": 10, "color": "#797979" }, "text": "3.1", "yshift": 10, "showarrow": false }, { "x": 129, "y": 3000000.0, "font": { "size": 10, "color": "#797979" }, "text": "3", "yshift": 10, "showarrow": false }, { "x": 130, "y": 2880000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.9", "yshift": 10, "showarrow": false }, { "x": 131, "y": 2860000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.9", "yshift": 10, "showarrow": false }, { "x": 132, "y": 2835000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.8", "yshift": 10, "showarrow": false }, { "x": 133, "y": 2800000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.8", "yshift": 10, "showarrow": false }, { "x": 134, "y": 2800000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.8", "yshift": 10, "showarrow": false }, { "x": 135, "y": 2784000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.8", "yshift": 10, "showarrow": false }, { "x": 136, "y": 2775000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.8", "yshift": 10, "showarrow": false }, { "x": 137, "y": 2730000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.7", "yshift": 10, "showarrow": false }, { "x": 138, "y": 2700000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.7", "yshift": 10, "showarrow": false }, { "x": 139, "y": 2639000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.6", "yshift": 10, "showarrow": false }, { "x": 140, "y": 2600000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.6", "yshift": 10, "showarrow": false }, { "x": 141, "y": 2502000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.5", "yshift": 10, "showarrow": false }, { "x": 142, "y": 2500000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.5", "yshift": 10, "showarrow": false }, { "x": 143, "y": 2475000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.5", "yshift": 10, "showarrow": false }, { "x": 144, "y": 2400000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.4", "yshift": 10, "showarrow": false }, { "x": 145, "y": 2340000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.3", "yshift": 10, "showarrow": false }, { "x": 146, "y": 2304000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.3", "yshift": 10, "showarrow": false }, { "x": 147, "y": 2280000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.3", "yshift": 10, "showarrow": false }, { "x": 148, "y": 2262000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.3", "yshift": 10, "showarrow": false }, { "x": 149, "y": 2223000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.2", "yshift": 10, "showarrow": false }, { "x": 150, "y": 2210000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.2", "yshift": 10, "showarrow": false }, { "x": 151, "y": 2160000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.2", "yshift": 10, "showarrow": false }, { "x": 152, "y": 2145000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.1", "yshift": 10, "showarrow": false }, { "x": 153, "y": 2145000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.1", "yshift": 10, "showarrow": false }, { "x": 154, "y": 2145000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.1", "yshift": 10, "showarrow": false }, { "x": 155, "y": 2080000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.1", "yshift": 10, "showarrow": false }, { "x": 156, "y": 2040000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.0", "yshift": 10, "showarrow": false }, { "x": 157, "y": 2028000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.0", "yshift": 10, "showarrow": false }, { "x": 158, "y": 2028000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.0", "yshift": 10, "showarrow": false }, { "x": 159, "y": 1980000.0, "font": { "size": 10, "color": "#797979" }, "text": "2.0", "yshift": 10, "showarrow": false }, { "x": 160, "y": 1930500.0, "font": { "size": 10, "color": "#797979" }, "text": "1.9", "yshift": 10, "showarrow": false }, { "x": 161, "y": 1900800.0, "font": { "size": 10, "color": "#797979" }, "text": "1.9", "yshift": 10, "showarrow": false }, { "x": 162, "y": 1860000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.9", "yshift": 10, "showarrow": false }, { "x": 163, "y": 1800000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.8", "yshift": 10, "showarrow": false }, { "x": 164, "y": 1755000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.8", "yshift": 10, "showarrow": false }, { "x": 165, "y": 1690000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.7", "yshift": 10, "showarrow": false }, { "x": 166, "y": 1644300.0, "font": { "size": 10, "color": "#797979" }, "text": "1.6", "yshift": 10, "showarrow": false }, { "x": 167, "y": 1518000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.5", "yshift": 10, "showarrow": false }, { "x": 168, "y": 1365000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.4", "yshift": 10, "showarrow": false }, { "x": 169, "y": 1250000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.2", "yshift": 10, "showarrow": false }, { "x": 170, "y": 1200000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.2", "yshift": 10, "showarrow": false }, { "x": 171, "y": 1131000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.1", "yshift": 10, "showarrow": false }, { "x": 172, "y": 1120000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.1", "yshift": 10, "showarrow": false }, { "x": 173, "y": 1087500.0, "font": { "size": 10, "color": "#797979" }, "text": "1.1", "yshift": 10, "showarrow": false }, { "x": 174, "y": 1080000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.1", "yshift": 10, "showarrow": false }, { "x": 175, "y": 1044000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.0", "yshift": 10, "showarrow": false }, { "x": 176, "y": 1040000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.0", "yshift": 10, "showarrow": false }, { "x": 177, "y": 1020000.0, "font": { "size": 10, "color": "#797979" }, "text": "1.0", "yshift": 10, "showarrow": false }, { "x": 178, "y": 912500.0, "font": { "size": 10, "color": "#797979" }, "text": "0.9", "yshift": 10, "showarrow": false }, { "x": 179, "y": 840000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.8", "yshift": 10, "showarrow": false }, { "x": 180, "y": 809100.0, "font": { "size": 10, "color": "#797979" }, "text": "0.8", "yshift": 10, "showarrow": false }, { "x": 181, "y": 804000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.8", "yshift": 10, "showarrow": false }, { "x": 182, "y": 725000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.7", "yshift": 10, "showarrow": false }, { "x": 183, "y": 648000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.6", "yshift": 10, "showarrow": false }, { "x": 184, "y": 600000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.6", "yshift": 10, "showarrow": false }, { "x": 185, "y": 520000.0, "font": { "size": 10, "color": "#797979" }, "text": "0.5", "yshift": 10, "showarrow": false } ], "updatemenus": [ { "x": 1, "y": 1.16, "pad": { "b": 2, "l": 4, "r": 4, "t": 2 }, "type": "buttons", "buttons": [ { "args": [ { "visible": [ true, true, true ] } ], "label": "Линия: Вкл", "method": "update" }, { "args": [ { "visible": [ true, true, false ] } ], "label": "Линия: Выкл", "method": "update" } ], "xanchor": "right", "yanchor": "top", "direction": "right", "showactive": true } ] } }, "height": 1000, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~nikschankin", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/30.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "n1xon", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-04-06 19:17:16", "mapbox_access_tokens": null, "has_password": null, "username": "nikschankin", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-08-09T16:07:46.271107Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jdavis-graphs/3.embed", "fid": "jdavis-graphs:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/jdavis-graphs/3/9_DFCEFUKGZ5ZBGV8ZOE5XHIFBYPZWSW.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/jdavis-graphs/3/2_FQL2HFP53LERFAU16XCI5S1KQCN1F7.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/jdavis-graphs/3/8_37FAP6TJBOSQ0L6OT1JUX3XDAJVD9Q.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/jdavis-graphs/3/9_DFCEFUKGZ5ZBGV8ZOE5XHIFBYPZWSW.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jdavis-graphs:3", "plots": "https://api.plotly.com/v2/plots/jdavis-graphs:3", "parent": "https://api.plotly.com/v2/folders/home?user=jdavis-graphs" }, "owner": "jdavis-graphs", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~jdavis-graphs/3/", "world_readable": true, "date_modified": "2025-08-09T16:20:41.817Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jdavis-graphs/3/", "current_user_permission": "read", "is_theme": null, "is_template": true, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "12:46:23", "y": "1" } }, "mode": "lines", "type": "bar", "xsrc": "jdavis-graphs:2:0fdf33", "ysrc": "jdavis-graphs:2:06f49c", "yaxis": "y3", "marker": { "color": "rgba(163, 4, 6, 0.5)" }, "orientation": "v", "selectedpoints": [ 58 ] }, { "meta": { "columnNames": { "x": "12:46:23", "y": "70.34" } }, "mode": "lines", "type": "scatter", "xsrc": "jdavis-graphs:2:0fdf33", "ysrc": "jdavis-graphs:2:371533" }, { "meta": { "columnNames": { "x": "12:46:23", "y": "76.70" } }, "mode": "lines", "type": "scatter", "xsrc": "jdavis-graphs:2:0fdf33", "ysrc": "jdavis-graphs:2:a74e1a", "yaxis": "y", "stackgroup": null, "transforms": [ { "meta": { "columnNames": { "target": "1" } }, "type": "filter", "value": "0", "enabled": false, "operation": "=", "targetsrc": "jdavis-graphs:2:06f49c" } ] }, { "meta": { "columnNames": { "x": "12:46:23", "y": "70.52" } }, "mode": "lines", "type": "scatter", "xsrc": "jdavis-graphs:2:0fdf33", "ysrc": "jdavis-graphs:2:0e691b", "yaxis": "y2", "stackgroup": null }, { "meta": { "columnNames": { "x": "12:46:23", "y": "77.70" } }, "mode": "lines", "type": "scatter", "xsrc": "jdavis-graphs:2:0fdf33", "ysrc": "jdavis-graphs:2:c945e4", "yaxis": "y2", "stackgroup": null } ], "frames": [], "layout": { "title": { "text": "Grain Brain Humidity and temperature" }, "xaxis": { "side": "bottom", "type": "category", "range": [ -0.5, 58.5 ], "anchor": "free", "domain": [ 0, 1 ], "showline": false, "zeroline": true, "autorange": true, "rangeslider": { "yaxis": {}, "yaxis2": {}, "yaxis3": {}, "visible": false }, "zerolinecolor": "rgb(0, 0, 0)", "showticklabels": true }, "yaxis": { "type": "linear", "range": [ 66.60555555555555, 84.49444444444444 ], "title": { "text": "Humidity" }, "domain": [ 0.5, 1 ], "autorange": true, "showticklabels": true }, "bargap": 0, "yaxis2": { "side": "left", "type": "linear", "range": [ 68.39999999999999, 82.4 ], "title": { "text": "Temp" }, "domain": [ 0, 0.5 ], "autorange": true, "overlaying": false }, "yaxis3": { "side": "right", "type": "linear", "range": [ 0, 1.0526315789473684 ], "title": { "text": "Click to enter Y axis title" }, "anchor": "free", "domain": [ 0, 1 ], "showgrid": false, "showline": false, "zeroline": false, "autorange": true, "overlaying": false, "showticklabels": false }, "modebar": { "orientation": "h" }, "autosize": true, "dragmode": "pan", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "clickmode": "event+select", "hovermode": "closest", "bargroupgap": 0, "plot_bgcolor": "rgba(255, 255, 255, 0)", "paper_bgcolor": "rgba(255, 255, 255, 0)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~jdavis-graphs", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/70.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-08-09 15:33:07", "mapbox_access_tokens": null, "has_password": null, "username": "jdavis-graphs", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-08-09T15:43:39.830480Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~jdavis-graphs/1.embed", "fid": "jdavis-graphs:1", "filename": "grain brain data plot", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/jdavis-graphs/1/9_0KHOEOO0HXC5OEUM7AP9FJUWOSLDAO.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/jdavis-graphs/1/2_BFR4CQKB3QGH5K9P62DKZR8DOAFBD0.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/jdavis-graphs/1/8_GXJY1BYMMIET7P75ACSCSM05X8DOJ2.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/jdavis-graphs/1/9_0KHOEOO0HXC5OEUM7AP9FJUWOSLDAO.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/jdavis-graphs:1", "plots": "https://api.plotly.com/v2/plots/jdavis-graphs:1", "parent": "https://api.plotly.com/v2/folders/home?user=jdavis-graphs" }, "owner": "jdavis-graphs", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~jdavis-graphs/1/", "world_readable": true, "date_modified": "2025-08-09T15:43:39.841Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~jdavis-graphs/1/", "current_user_permission": "read", "is_theme": null, "is_template": true, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "12:46:23", "y": "70.34" } }, "mode": "lines", "type": "scatter", "xsrc": "jdavis-graphs:0:05c174", "ysrc": "jdavis-graphs:0:668f44" }, { "meta": { "columnNames": { "x": "12:46:23", "y": "76.70" } }, "mode": "lines", "type": "scatter", "xsrc": "jdavis-graphs:0:05c174", "ysrc": "jdavis-graphs:0:4226d1", "yaxis": "y", "stackgroup": null, "transforms": [ { "meta": { "columnNames": { "target": "1" } }, "type": "filter", "value": "0", "enabled": true, "operation": "=", "targetsrc": "jdavis-graphs:0:57c26f" } ] }, { "meta": { "columnNames": { "x": "12:46:23", "y": "70.52" } }, "mode": "lines", "type": "scatter", "xsrc": "jdavis-graphs:0:05c174", "ysrc": "jdavis-graphs:0:b8c082", "yaxis": "y2", "stackgroup": null }, { "meta": { "columnNames": { "x": "12:46:23", "y": "77.70" } }, "mode": "lines", "type": "scatter", "xsrc": "jdavis-graphs:0:05c174", "ysrc": "jdavis-graphs:0:fcef48", "yaxis": "y2", "stackgroup": null }, { "meta": { "columnNames": { "x": "1", "y": "12:46:23" } }, "mode": "lines", "type": "scatter", "xsrc": "jdavis-graphs:0:57c26f", "ysrc": "jdavis-graphs:0:05c174", "yaxis": "y2", "orientation": "v" } ], "frames": [], "layout": { "title": { "text": "Click to enter Plot title" }, "xaxis": { "type": "category", "range": [ 0, 60 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ 69.41333333333333, 84.34666666666666 ], "autorange": true }, "yaxis2": { "side": "right", "type": "linear", "range": [ 68.39999999999999, 82.4 ], "autorange": true, "overlaying": "y" }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~jdavis-graphs", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/70.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-13.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-08-09 15:33:07", "mapbox_access_tokens": null, "has_password": null, "username": "jdavis-graphs", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
