Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cj0xJnA9MjAyNS0wNi0wNSsyMCUzQTEyJTNBMjguNzQwODkzJTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plotly.com/v2/plots?cursor=cD0yMDI1LTA2LTA1KzIwJTNBMTYlM0EzNy4xNzA3NDQlMkIwMCUzQTAw&format=api", "previous": "https://api.plotly.com/v2/plots?cursor=cj0xJnA9MjAyNS0wNi0wNSsyMCUzQTM1JTNBNDUuNjU1NTA3JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2025-06-05T20:35:45.655507Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38501.embed", "fid": "cpsievert:38501", "filename": "Plot 38501", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38501/9_XJM030IXE6IT9UP06H2F9DC75YLUDZ.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38501/2_F1V4JUCFXP1U6Z0DDURO9IE5NZOSUN.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38501/8_ZRQ8G3LGTX7RLUUNMO0357IZETYKRN.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38501/9_XJM030IXE6IT9UP06H2F9DC75YLUDZ.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38501", "plots": "https://api.plotly.com/v2/plots/cpsievert:38501", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38501/", "world_readable": true, "date_modified": "2025-06-05T20:35:45.687Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38501/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(31,119,180,1)" }, "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38500:bc5777", "ysrc": "cpsievert:38500:f92c32", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(31,119,180,1)" }, "color": "rgba(31,119,180,1)" }, "error_x": { "color": "rgba(31,119,180,1)" }, "error_y": { "color": "rgba(31,119,180,1)" } } ], "layout": { "xaxis": { "title": "mpg", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": "wt", "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T20:24:25.273077Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38496.embed", "fid": "cpsievert:38496", "filename": "Plot 38496", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38496/9_4XCVVJL8WP7K9XSHQLEB1UAHT7G4Y1.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38496/2_KYMCD49X7NCTOANBE7AWZ2D5519IZM.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38496/8_WAN51HO4W4FVLJ8E10AON1PUQ6ZNNG.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38496/9_4XCVVJL8WP7K9XSHQLEB1UAHT7G4Y1.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38496", "plots": "https://api.plotly.com/v2/plots/cpsievert:38496", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38496/", "world_readable": true, "date_modified": "2025-06-05T20:24:25.305Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38496/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "type": "bar", "xsrc": "cpsievert:38495:cea8a0", "ysrc": "cpsievert:38495:6b8458", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "transparent", "width": 1.8897637795275593 }, "color": "rgba(89,89,89,1)", "autocolorscale": false }, "basesrc": "cpsievert:38495:89da6d", "textsrc": "cpsievert:38495:295246", "widthsrc": "cpsievert:38495:ed7395", "hoverinfo": "text", "showlegend": false, "orientation": "v", "textposition": "none" } ], "layout": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "xaxis": { "type": "linear", "range": [ 0.055000000000000104, 10.944999999999999 ], "ticks": "outside", "title": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "text": "1:10" }, "anchor": "y", "domain": [ 0, 1 ], "nticks": null, "ticklen": 3.652968036529681, "showgrid": true, "showline": false, "tickfont": { "size": 11.68949771689498, "color": "rgba(77,77,77,1)", "family": "" }, "tickmode": "array", "ticktext": [ "2.5", "5.0", "7.5", "10.0" ], "tickvals": [ 2.5, 5, 7.500000000000001, 10 ], "zeroline": false, "autorange": false, "gridcolor": "rgba(255,255,255,1)", "gridwidth": 0.66417600664176, "linecolor": null, "linewidth": 0, "tickangle": 0, "tickcolor": "rgba(51,51,51,1)", "tickwidth": 0.66417600664176, "automargin": true, "hoverformat": ".2f", "categoryarray": [ "2.5", "5.0", "7.5", "10.0" ], "categoryorder": "array", "showticklabels": true }, "yaxis": { "type": "linear", "range": [ -0.05, 1.05 ], "ticks": "outside", "title": { "font": { "size": 14.611872146118724, "color": "rgba(0,0,0,1)", "family": "" }, "text": "count" }, "anchor": "x", "domain": [ 0, 1 ], "nticks": null, "ticklen": 3.652968036529681, "showgrid": true, "showline": false, "tickfont": { "size": 11.68949771689498, "color": "rgba(77,77,77,1)", "family": "" }, "tickmode": "array", "ticktext": [ "0.00", "0.25", "0.50", "0.75", "1.00" ], "tickvals": [ 0, 0.25, 0.5, 0.75, 1 ], "zeroline": false, "autorange": false, "gridcolor": "rgba(255,255,255,1)", "gridwidth": 0.66417600664176, "linecolor": null, "linewidth": 0, "tickangle": 0, "tickcolor": "rgba(51,51,51,1)", "tickwidth": 0.66417600664176, "automargin": true, "hoverformat": ".2f", "categoryarray": [ "0.00", "0.25", "0.50", "0.75", "1.00" ], "categoryorder": "array", "showticklabels": true }, "legend": { "font": { "size": 11.68949771689498, "color": "rgba(0,0,0,1)", "family": "" }, "bgcolor": "rgba(255,255,255,1)", "bordercolor": "transparent", "borderwidth": 1.8897637795275593 }, "margin": { "b": 39.69558599695587, "l": 48.94977168949772, "r": 7.305936073059362, "t": 25.74124809741248 }, "shapes": [ { "x0": 0, "x1": 1, "y0": 0, "y1": 1, "line": { "color": null, "width": 0, "linetype": [] }, "type": "rect", "xref": "paper", "yref": "paper", "layer": "below", "fillcolor": null } ], "barmode": "relative", "hovermode": "closest", "showlegend": false, "plot_bgcolor": "rgba(235,235,235,1)", "paper_bgcolor": "rgba(255,255,255,1)" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T20:24:23.406828Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38494.embed", "fid": "cpsievert:38494", "filename": "Plot 38494", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/cpsievert:38494/image?image_name=list-thumb", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38494/2_Q3JMCMY1JGZHRAD8LJSNODBYQKDLDK.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38494/8_SFMXYHXZV9HGY9HZMUNF2BS84SWIK9.png", "list-thumb": "https://api.plotly.com/v2/files/cpsievert:38494/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38494", "plots": "https://api.plotly.com/v2/plots/cpsievert:38494", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38494/", "world_readable": true, "date_modified": "2025-06-05T20:24:23.439Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38494/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38493:1ec1ad", "ysrc": "cpsievert:38493:a67b18", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38493:8c0b88", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38493:566340", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true }, { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38493:1342e5", "ysrc": "cpsievert:38493:6f17d1", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "color": "rgba(255,127,14,1)" }, "colorbar": { "y": 1, "len": 0.5, "title": "", "lenmode": "fraction", "ticklen": 2, "yanchor": "top" }, "colorsrc": "cpsievert:38493:5ecd94", "showscale": true, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "opacity": 0, "hoverinfo": "none", "showlegend": false } ], "frames": [ { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38493:b31777", "ysrc": "cpsievert:38493:4b19cc", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38493:fdf1e9", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38493:91ea3f", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true } ], "name": "1", "traces": [ 0 ] }, { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38493:490c12", "ysrc": "cpsievert:38493:04df1b", "frame": "2", "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38493:c9434d", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38493:fff762", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "visible": true } ], "name": "2", "traces": [ 0 ] } ], "layout": { "xaxis": { "range": [ 0.55, 10.45 ], "title": [], "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "range": [ 0.55, 10.45 ], "title": [], "domain": [ 0, 1 ], "automargin": true }, "legend": { "y": 0.5, "yanchor": "top" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "sliders": [ { "pad": { "t": 40 }, "steps": [ { "args": [ [ "1" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "1", "value": "1", "method": "animate" }, { "args": [ [ "2" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "2", "value": "2", "method": "animate" } ], "visible": true } ], "hovermode": "closest", "showlegend": false, "updatemenus": [ { "x": 0, "y": 0, "pad": { "r": 5, "t": 60 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 }, "fromcurrent": true } ], "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "direction": "right", "showactive": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T20:24:21.553651Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38492.embed", "fid": "cpsievert:38492", "filename": "Plot 38492", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38492/9_PJO98O582X2O0OIV6UIOT7AX1VDQ15.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38492/2_JA1EGWZE7R26UE4VAST36ZRH77FTX0.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38492/8_PQERSHAESGZ3V5KIL3K78XOV9ATKR4.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38492/9_PJO98O582X2O0OIV6UIOT7AX1VDQ15.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38492", "plots": "https://api.plotly.com/v2/plots/cpsievert:38492", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38492/", "world_readable": true, "date_modified": "2025-06-05T20:24:21.585Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38492/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38491:2e8727", "ysrc": "cpsievert:38491:bf491f", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "cmax": 10, "cmin": 1, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38491:5a64c2", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "colorbar": { "title": "", "ticklen": 2 }, "colorsrc": "cpsievert:38491:567901", "showscale": false, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] } }, { "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38491:99c991", "ysrc": "cpsievert:38491:b6f662", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "cmax": 10, "cmin": 1, "line": { "color": "rgba(255,127,14,1)" }, "colorbar": { "y": 1, "len": 0.5, "title": "", "lenmode": "fraction", "ticklen": 2, "yanchor": "top" }, "colorsrc": "cpsievert:38491:008250", "showscale": true, "colorscale": [ [ "0", "rgba(68,1,84,1)" ], [ "0.0416666666666667", "rgba(70,19,97,1)" ], [ "0.0833333333333333", "rgba(72,32,111,1)" ], [ "0.125", "rgba(71,45,122,1)" ], [ "0.166666666666667", "rgba(68,58,128,1)" ], [ "0.208333333333333", "rgba(64,70,135,1)" ], [ "0.25", "rgba(60,82,138,1)" ], [ "0.291666666666667", "rgba(56,93,140,1)" ], [ "0.333333333333333", "rgba(49,104,142,1)" ], [ "0.375", "rgba(46,114,142,1)" ], [ "0.416666666666667", "rgba(42,123,142,1)" ], [ "0.458333333333333", "rgba(38,133,141,1)" ], [ "0.5", "rgba(37,144,140,1)" ], [ "0.541666666666667", "rgba(33,154,138,1)" ], [ "0.583333333333333", "rgba(39,164,133,1)" ], [ "0.625", "rgba(47,174,127,1)" ], [ "0.666666666666667", "rgba(53,183,121,1)" ], [ "0.708333333333333", "rgba(79,191,110,1)" ], [ "0.75", "rgba(98,199,98,1)" ], [ "0.791666666666667", "rgba(119,207,85,1)" ], [ "0.833333333333333", "rgba(147,214,70,1)" ], [ "0.875", "rgba(172,220,52,1)" ], [ "0.916666666666667", "rgba(199,225,42,1)" ], [ "0.958333333333333", "rgba(226,228,40,1)" ], [ "1", "rgba(253,231,37,1)" ] ] }, "opacity": 0, "hoverinfo": "none", "showlegend": false } ], "layout": { "xaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "legend": { "y": 0.5, "yanchor": "top" }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T20:24:19.730444Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38490.embed", "fid": "cpsievert:38490", "filename": "Plot 38490", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38490/9_71GJFFYSCOBQKNR8ZAOY5Y0GOLZTIN.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38490/2_3FQM6VX0110PPJALE0S26J3HVJT4DO.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38490/8_ZVTBQE9U8Q88S6IBSANBIK17HR6IUL.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38490/9_71GJFFYSCOBQKNR8ZAOY5Y0GOLZTIN.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38490", "plots": "https://api.plotly.com/v2/plots/cpsievert:38490", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38490/", "world_readable": true, "date_modified": "2025-06-05T20:24:19.762Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38490/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(31,119,180,1)" }, "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38489:43e79b", "ysrc": "cpsievert:38489:9c2b0b", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(31,119,180,1)" }, "color": "red" }, "error_x": { "color": "rgba(31,119,180,1)" }, "error_y": { "color": "rgba(31,119,180,1)" } } ], "layout": { "xaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": [], "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T20:24:16.707397Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38488.embed", "fid": "cpsievert:38488", "filename": "58876d84b5e", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38488/9_H6O29M67AIAPW0F0MG3F31SMQYCQZM.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38488/2_CI96XL308PS5JQ8DCSCRTO537K2ZFM.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38488/8_0U7TMMEOETQE0HLB7EQYREP02T1YIF.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38488/9_H6O29M67AIAPW0F0MG3F31SMQYCQZM.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38488", "plots": "https://api.plotly.com/v2/plots/cpsievert:38488", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38488/", "world_readable": true, "date_modified": "2025-06-05T20:24:18.113Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38488/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(31,119,180,1)" }, "mode": "markers", "type": "scatter", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(31,119,180,1)" }, "color": "rgba(31,119,180,1)" }, "error_x": { "color": "rgba(31,119,180,1)" }, "error_y": { "color": "rgba(31,119,180,1)" } } ], "layout": { "title": "test", "xaxis": { "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T20:24:08.647391Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38486.embed", "fid": "cpsievert:38486", "filename": "Plot 38486", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38486/9_4J6ENMPNNPFGF5XNPIM1O4L0RN1UUG.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38486/2_DK4K9LI1MH0U10TQAOBZFGW6LVY4AA.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38486/8_U3BYBFY1LZIUB4D78Y51M7OH837DCV.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38486/9_4J6ENMPNNPFGF5XNPIM1O4L0RN1UUG.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38486", "plots": "https://api.plotly.com/v2/plots/cpsievert:38486", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38486/", "world_readable": true, "date_modified": "2025-06-05T20:24:08.680Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38486/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38485:05673b", "ysrc": "cpsievert:38485:2cb4ef", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "visible": true, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38485:321b39", "ysrc": "cpsievert:38485:85a4f3", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "visible": true, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38485:7b5c2e", "ysrc": "cpsievert:38485:2ab55a", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "visible": true, "textfont": { "color": "rgba(141,160,203,1)" } } ], "frames": [ { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38485:eb6659", "ysrc": "cpsievert:38485:9c273e", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "visible": true, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38485:571f82", "ysrc": "cpsievert:38485:2c8004", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "visible": true, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38485:7b6e01", "ysrc": "cpsievert:38485:faa70c", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "visible": true, "textfont": { "color": "rgba(141,160,203,1)" } } ], "name": "0", "traces": [ 0, 1, 2 ] }, { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38485:58cdc8", "ysrc": "cpsievert:38485:641767", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "visible": true, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38485:40e085", "ysrc": "cpsievert:38485:7b75da", "frame": "1", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "visible": true, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38485:29b039", "ysrc": "cpsievert:38485:3b101a", "frame": "0", "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "visible": false, "textfont": { "color": "rgba(141,160,203,1)" } } ], "name": "1", "traces": [ 0, 1, 2 ] } ], "layout": { "xaxis": { "range": [ 9.225, 35.074999999999996 ], "title": "mpg", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "range": [ 1.3174499999999998, 5.61955 ], "title": "wt", "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "sliders": [ { "pad": { "t": 40 }, "steps": [ { "args": [ [ "0" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "0", "value": "0", "method": "animate" }, { "args": [ [ "1" ], { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 } } ], "label": "1", "value": "1", "method": "animate" } ], "visible": true, "currentvalue": { "font": { "size": 16, "color": "rgba(204,204,204,1)" }, "prefix": "factor(vs): ", "xanchor": "right" } } ], "hovermode": "closest", "showlegend": true, "updatemenus": [ { "x": 0, "y": 0, "pad": { "r": 5, "t": 60 }, "type": "buttons", "buttons": [ { "args": [ null, { "mode": "immediate", "frame": { "redraw": false, "duration": 500 }, "transition": { "easing": "linear", "duration": 500 }, "fromcurrent": true } ], "label": "Play", "method": "animate" } ], "xanchor": "right", "yanchor": "top", "direction": "right", "showactive": false } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T20:24:02.474355Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38484.embed", "fid": "cpsievert:38484", "filename": "Plot 38484", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38484/9_MBN3L59WF361DD92L01KNN4KG89NFF.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38484/2_9OIWPYH8AFK7WINLR2RVIWL4NRH4EY.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38484/8_JF10FAGWXB95DU6UWUEV2M2F1NQDK0.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38484/9_MBN3L59WF361DD92L01KNN4KG89NFF.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38484", "plots": "https://api.plotly.com/v2/plots/cpsievert:38484", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38484/", "world_readable": true, "date_modified": "2025-06-05T20:24:02.506Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38484/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(102,194,165,1)" }, "mode": "markers", "name": "4", "type": "scatter", "xsrc": "cpsievert:38483:5782ba", "ysrc": "cpsievert:38483:f41f50", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(102,194,165,1)" }, "color": "rgba(102,194,165,1)" }, "error_x": { "color": "rgba(102,194,165,1)" }, "error_y": { "color": "rgba(102,194,165,1)" }, "textfont": { "color": "rgba(102,194,165,1)" } }, { "line": { "color": "rgba(252,141,98,1)" }, "mode": "markers", "name": "6", "type": "scatter", "xsrc": "cpsievert:38483:ab1c30", "ysrc": "cpsievert:38483:3ae07a", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(252,141,98,1)" }, "color": "rgba(252,141,98,1)" }, "error_x": { "color": "rgba(252,141,98,1)" }, "error_y": { "color": "rgba(252,141,98,1)" }, "textfont": { "color": "rgba(252,141,98,1)" } }, { "line": { "color": "rgba(141,160,203,1)" }, "mode": "markers", "name": "8", "type": "scatter", "xsrc": "cpsievert:38483:822538", "ysrc": "cpsievert:38483:add174", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(141,160,203,1)" }, "color": "rgba(141,160,203,1)" }, "error_x": { "color": "rgba(141,160,203,1)" }, "error_y": { "color": "rgba(141,160,203,1)" }, "textfont": { "color": "rgba(141,160,203,1)" } } ], "layout": { "xaxis": { "title": "mpg", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": "wt", "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T20:23:56.328216Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~cpsievert/38482.embed", "fid": "cpsievert:38482", "filename": "Plot 38482", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38482/9_KVT2ZFUKCIMUIR0HS0LSUVAKP8DMU0.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38482/2_MYZV2S86YN6KV77RFJOUGFD4JLBK7B.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38482/8_B963YWUBJA0MHI0T7KPO4AJ85X7EEK.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/cpsievert/38482/9_KVT2ZFUKCIMUIR0HS0LSUVAKP8DMU0.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/cpsievert:38482", "plots": "https://api.plotly.com/v2/plots/cpsievert:38482", "parent": "https://api.plotly.com/v2/folders/home?user=cpsievert" }, "owner": "cpsievert", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~cpsievert/38482/", "world_readable": true, "date_modified": "2025-06-05T20:23:56.360Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~cpsievert/38482/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgba(31,119,180,1)" }, "mode": "markers", "type": "scatter", "xsrc": "cpsievert:38481:32f91d", "ysrc": "cpsievert:38481:bbb74c", "frame": null, "xaxis": "x", "yaxis": "y", "marker": { "line": { "color": "rgba(31,119,180,1)" }, "color": "rgba(31,119,180,1)" }, "error_x": { "color": "rgba(31,119,180,1)" }, "error_y": { "color": "rgba(31,119,180,1)" } } ], "layout": { "xaxis": { "title": "mpg", "domain": [ 0, 1 ], "automargin": true }, "yaxis": { "title": "wt", "domain": [ 0, 1 ], "automargin": true }, "margin": { "b": 40, "l": 60, "r": 10, "t": 25 }, "hovermode": "closest", "showlegend": false } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~cpsievert", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/41.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2014-07-23 00:30:48", "mapbox_access_tokens": null, "has_password": null, "username": "cpsievert", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-06-05T20:16:37.170744Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~vivek2305/1.embed", "fid": "vivek2305:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/vivek2305/1/9_N1H0O2KFZZY5NUSOMNL4V1W5QE18SA.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/vivek2305/1/2_GW0HRKESUKSJO8RJR2SWPDIHZQ8JB4.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/vivek2305/1/8_YXRTQKAEI3Q6Z3N2ZAW6CWRMVQM7ZD.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/vivek2305/1/9_N1H0O2KFZZY5NUSOMNL4V1W5QE18SA.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/vivek2305:1", "plots": "https://api.plotly.com/v2/plots/vivek2305:1", "parent": "https://api.plotly.com/v2/folders/home?user=vivek2305" }, "owner": "vivek2305", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 0, "web_url": "https://chart-studio.plotly.com/~vivek2305/1/", "world_readable": true, "date_modified": "2025-06-05T20:16:37.184Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~vivek2305/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "B", "y": "A" } }, "mode": "lines", "type": "scatter", "xsrc": "vivek2305:0:6d2461", "ysrc": "vivek2305:0:525dc3" } ], "frames": [], "layout": { "title": { "text": "Demand Curve" }, "xaxis": { "type": "linear", "range": [ 4, 10 ], "title": { "text": "Quantity Demanded" }, "autorange": true }, "yaxis": { "range": [ 0.9333333333333333, 2.266666666666667 ], "title": { "text": "Price" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~vivek2305", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/86.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-11.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-06-05 20:06:09", "mapbox_access_tokens": null, "has_password": null, "username": "vivek2305", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
