Plots List
Plots
This endpoint handles manipulation of Plotly plot files.
Reference
Authorization
Any user with or without a Plotly account may view public plots. For private plots, see authentication.
Actions
list
Listing all public plots can be done via a GET request to this endpoint.
By default, plots will be listed in order of date created. The order_by
query parameter is accepted at this endpoint. Currently, only ordering by
views is supported. It is possible to filter the plots by quality
with min_quality or max_quality as query parameter.
Example:
// GET https://api.plotly.com/v2/plots/ ---> 200
// GET https://api.plotly.com/v2/plots/?order_by=-views ---> 200
// GET https://api.plotly.com/v2/plots/?min_quality=5 ---> 200
// GET https://api.plotly.com/v2/plots/?max_quality=5 ---> 200
feed
Listing all handpicked feed plots can be done via a GET request to this endpoint. By default, plots will be listed in a random order.
Example:
// GET https://api.plotly.com/v2/plots/feed ---> 200
create
You can create new plot resources here. The only required field is 'figure'. Currently, the figure is restricted to only contain references to grid data. That is, this will fail if raw data arrays are passed in. To create and manipulate underlying grids for plots, see the grids endpoint.
Example:
// This fails because a figure field is required.
// POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{}
// This fails because the figure has raw data
//POST https://api.plotly.com/v2/plots ---> 400 Bad Request
{
"figure": {"data": [{"y": ['this', 'is', 'raw', 'data']}]}
}
// This succeeds because the figure has src keys, not raw data.
//POST https://api.plotly.com/v2/plots ---> 200 OK
{
"figure": {"data": [{"ysrc": "sven:88:u8nd62"}]}
}
When creating a grid, you can optionally specify a source_fid to specify where a plot has come from:
- source_fid: the fid of a plot that was copied (and presumably edited) to produce this one
detail
There is a lot of meta information stored about plot files including filename, title, share_url, and content_url to name a few.
This information can only be reached with a GET to this endpoint.
Example:
// GET https://api.plotly.com/v2/plots/iheartgraphs:90
content
The contents of a plot can be downloaded via the content resource. The plot
content contains referenced grid/column data by default. If you wish to
return the raw grid/column data, the inline_data=true query must be included
in the request url. The Content-Type header will be appropriately set for the
response body.
Alternatively, you can set ?map_data=unreadable to append a mapping of
sources to data that belongs to grids which are unreadable for the
requestor. This is useful when you have read access to another users plot,
but that plot contains grid references which you don't have access to.
Examples:
// Returns referenced grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content ---> 200 OK
// Returns full grid/column data
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?inline_data=true ---> 200 OK
// Returns full grid/column data when requestor doesn't have permission
// to read the referenced grid.
// GET https://api.plotly.com/v2/plots/iheartgraphs:90/content?map_data=unreadable ---> 200 OK
GET /v2/plots?cursor=cj0xJnA9MjAyNS0wOS0wNysxMSUzQTMzJTNBNDIuMTAxMjgzJTJCMDAlM0EwMA%3D%3D&format=api
{ "next": "https://api.plotly.com/v2/plots?cursor=cD0yMDI1LTA5LTA3KzExJTNBNDYlM0ExNS42MTQxNzIlMkIwMCUzQTAw&format=api", "previous": "https://api.plotly.com/v2/plots?cursor=cj0xJnA9MjAyNS0wOS0wNysxNiUzQTM5JTNBMDMuNTkxODg5JTJCMDAlM0EwMA%3D%3D&format=api", "results": [ { "creation_time": "2025-09-07T16:39:03.591889Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~khalilhasnaoui11/1.embed", "fid": "khalilhasnaoui11:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/khalilhasnaoui11/1/9_R63JWOIXKAYWLIP0N9GH216C5PGD57.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/khalilhasnaoui11/1/2_4LQSMQZ27BZP5J0CAKU7RN8MC2WHSW.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/khalilhasnaoui11/1/8_3CZI6JUCN3QVTVZRF9JTKHNTEF26GS.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/khalilhasnaoui11/1/9_R63JWOIXKAYWLIP0N9GH216C5PGD57.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/khalilhasnaoui11:1", "plots": "https://api.plotly.com/v2/plots/khalilhasnaoui11:1", "parent": "https://api.plotly.com/v2/folders/home?user=khalilhasnaoui11" }, "owner": "khalilhasnaoui11", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~khalilhasnaoui11/1/", "world_readable": true, "date_modified": "2025-09-07T16:39:03.610Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~khalilhasnaoui11/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "x", "y": "y" } }, "mode": "lines", "type": "scatter", "xsrc": "khalilhasnaoui11:0:8588c4", "ysrc": "khalilhasnaoui11:0:c41af8" } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ -41.34340286, 77.39849854 ], "autorange": true, "showspikes": false }, "yaxis": { "type": "linear", "range": [ -247.85761813444444, 61.56952455444445 ], "autorange": true, "showspikes": false }, "autosize": true, "dragmode": "pan", "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" }, "hovermode": "closest" } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~khalilhasnaoui11", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/35.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-14.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-07 16:32:30", "mapbox_access_tokens": null, "has_password": null, "username": "khalilhasnaoui11", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-07T16:27:38.232144Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~Teofilius/3.embed", "fid": "Teofilius:3", "filename": "Plot 3", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/Teofilius:3/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/Teofilius:3/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/Teofilius/3/8_CO10E3WWBY448T1IDM7UF5K06LXWAH.png", "list-thumb": "https://api.plotly.com/v2/files/Teofilius:3/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/Teofilius:3", "plots": "https://api.plotly.com/v2/plots/Teofilius:3", "parent": "https://api.plotly.com/v2/folders/home?user=Teofilius" }, "owner": "Teofilius", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~Teofilius/3/", "world_readable": true, "date_modified": "2025-09-07T16:58:24.106Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~Teofilius/3/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "color": "rgb(0, 0, 0)", "shape": "linear" }, "meta": { "columnNames": { "x": "A", "y": "B", "error_y": { "array": "C" } } }, "mode": "lines", "type": "scatter", "xsrc": "Teofilius:2:772ddf", "ysrc": "Teofilius:2:5844af", "error_y": { "meta": { "columnNames": { "array": "C" } }, "type": "data", "color": "rgb(39, 57, 234)", "visible": true, "arraysrc": "Teofilius:2:ce9133", "symmetric": true } } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ -0.11111111111111112, 2.111111111111111 ], "title": { "text": "Carbon Concentration" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ -0.43166666666666675, 11.201666666666666 ], "title": { "text": "Average height (cm) +/- 1SD" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~Teofilius", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/17.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-1.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2024-09-22 15:33:17", "mapbox_access_tokens": null, "has_password": null, "username": "Teofilius", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-07T15:40:20.053758Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~dbrebner/1.embed", "fid": "dbrebner:1", "filename": "DNS Data - Nov 2024 RFP", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/dbrebner:1/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/dbrebner:1/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/dbrebner/1/8_0E3IP608UWBJK8M7541QC2ERTYLK2R.png", "list-thumb": "https://api.plotly.com/v2/files/dbrebner:1/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/dbrebner:1", "plots": "https://api.plotly.com/v2/plots/dbrebner:1", "parent": "https://api.plotly.com/v2/folders/home?user=dbrebner" }, "owner": "dbrebner", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~dbrebner/1/", "world_readable": true, "date_modified": "2025-09-07T15:40:20.065Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~dbrebner/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "x", "y": "y" } }, "mode": "lines", "type": "scatter", "xsrc": "dbrebner:0:0cacb3", "ysrc": "dbrebner:0:27bdb5" } ], "frames": [], "layout": { "title": { "text": "DNS Data Supplied in RFP - now imported for modelling" }, "xaxis": { "type": "date", "range": [ "2024-11-13 00:03:14", "2024-11-25 00:03:56" ], "title": { "text": "DNS Measurements over 12 days on November 2024" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 151036.89979928976, 2047927.4355411453 ], "title": { "text": "DNS QPS  (~ 900 data points defined)" }, "autorange": true }, "autosize": true } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~dbrebner", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/81.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-3.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-07 15:37:01", "mapbox_access_tokens": null, "has_password": null, "username": "dbrebner", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-07T15:26:52.987048Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~JHOAN/1.embed", "fid": "JHOAN:1", "filename": "Plot 1", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/JHOAN/1/9_MPGYJLXCKQIMV95M8NXSTN32C2HDL1.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/JHOAN/1/2_OGHMKT8QPS8RG1FQ21WLLKGFFQMCZX.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/JHOAN/1/8_3SVF28CGTDIEQWJ0LA8KA3TLJJYH0Z.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/JHOAN/1/9_MPGYJLXCKQIMV95M8NXSTN32C2HDL1.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/JHOAN:1", "plots": "https://api.plotly.com/v2/plots/JHOAN:1", "parent": "https://api.plotly.com/v2/folders/home?user=JHOAN" }, "owner": "JHOAN", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 2, "web_url": "https://chart-studio.plotly.com/~JHOAN/1/", "world_readable": true, "date_modified": "2025-09-07T15:26:53.002Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~JHOAN/1/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "temperatura", "y": "ph", "z": "%perdida" } }, "mode": "markers", "type": "contour", "xsrc": "JHOAN:0:8a1f24", "ysrc": "JHOAN:0:8e4074", "zsrc": "JHOAN:0:717b39", "contours": { "end": 10, "size": 10, "start": -80 }, "autocontour": true, "autocolorscale": true } ], "frames": [], "layout": { "title": { "text": "Click to enter Plot title" }, "xaxis": { "type": "linear", "range": [ 24, 26 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ 2.8, 3.43 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~JHOAN", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/98.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-7.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-07 15:04:17", "mapbox_access_tokens": null, "has_password": null, "username": "JHOAN", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-07T14:51:53.114796Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~senurii/17.embed", "fid": "senurii:17", "filename": "Plot 17", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/senurii/17/9_Q5HZKKT317S4LL3Y5XMOR21B496NOO.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/senurii/17/2_J6VKXWHOI1UWPILS76JBM85YKRF2VG.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/senurii/17/8_1B1NUVL1OE9DFE4N78ZBUL6ADUK6TH.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/senurii/17/9_Q5HZKKT317S4LL3Y5XMOR21B496NOO.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/senurii:17", "plots": "https://api.plotly.com/v2/plots/senurii:17", "parent": "https://api.plotly.com/v2/folders/home?user=senurii" }, "owner": "senurii", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~senurii/17/", "world_readable": true, "date_modified": "2025-09-07T14:51:53.131Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~senurii/17/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Accuracy", "y": "FLOPs", "z": "Params", "marker": { "size": "" } } }, "mode": "markers", "type": "scatter3d", "xsrc": "senurii:16:6166aa", "ysrc": "senurii:16:81cac8", "zsrc": "senurii:16:59c570", "marker": { "meta": { "columnNames": { "size": "Params" } }, "size": "6", "sizeref": 289.67703703703705, "sizemode": "area" } } ], "frames": [], "layout": { "scene": { "camera": { "up": { "x": 0, "y": 0, "z": 1 }, "eye": { "x": 1.247192953717789, "y": 1.7682246471040473, "z": 0.07342570102127059 }, "center": { "x": 0, "y": 0, "z": 0 }, "projection": { "type": "perspective" } }, "aspectmode": "auto", "aspectratio": { "x": 1, "y": 1, "z": 1 } }, "xaxis": { "type": "linear", "range": [ 78, 88.25 ], "autorange": true }, "yaxis": { "type": "linear", "range": [ 517428.6111111111, 590236.3888888889 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~senurii", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/26.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-07 06:53:14", "mapbox_access_tokens": null, "has_password": null, "username": "senurii", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-07T14:37:49.642082Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~senurii/15.embed", "fid": "senurii:15", "filename": "Radar Graph", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/senurii/15/9_ZBX9H5LAX5TFBKHXF07BVSSAI0U3WH.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/senurii/15/2_4MD7M3VA1GSNRDNHOX3PBT9YI6XEWW.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/senurii/15/8_7Z0TCS3XZOU004QBDGCM2C6WLZ8VYS.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/senurii/15/9_ZBX9H5LAX5TFBKHXF07BVSSAI0U3WH.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/senurii:15", "plots": "https://api.plotly.com/v2/plots/senurii:15", "parent": "https://api.plotly.com/v2/folders/home?user=senurii" }, "owner": "senurii", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~senurii/15/", "world_readable": true, "date_modified": "2025-09-07T14:37:49.653Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~senurii/15/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "r": "C", "theta": "B" } }, "mode": "markers+lines", "name": "Baseline CNN", "rsrc": "senurii:14:d935d7", "type": "scatterpolar", "subplot": "polar", "visible": true, "thetasrc": "senurii:14:e23ab4", "thetaunit": "degrees" }, { "meta": { "columnNames": { "r": "D", "theta": "B" } }, "name": "CNN-K", "rsrc": "senurii:14:869b54", "type": "scatterpolar", "thetasrc": "senurii:14:e23ab4" }, { "meta": { "columnNames": { "r": "E", "theta": "B" } }, "name": "CNN-SK", "rsrc": "senurii:14:1a0134", "type": "scatterpolar", "thetasrc": "senurii:14:e23ab4" }, { "meta": { "columnNames": { "r": "F", "theta": "B" } }, "name": "CNN-PSK", "rsrc": "senurii:14:ae203c", "type": "scatterpolar", "thetasrc": "senurii:14:e23ab4" } ], "frames": [], "layout": { "polar": { "radialaxis": { "type": "linear", "range": [ 0, 104.5480093676815 ], "autorange": true }, "angularaxis": { "type": "linear" } }, "xaxis": { "range": [ -1, 6 ], "autorange": true }, "yaxis": { "range": [ -1, 4 ], "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~senurii", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/26.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-07 06:53:14", "mapbox_access_tokens": null, "has_password": null, "username": "senurii", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-07T13:26:13.284852Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~senurii/13.embed", "fid": "senurii:13", "filename": "PCA Variants", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/senurii:13/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/senurii:13/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/senurii/13/8_CEQLB7MPPJ9JRK5OYEHGJND9CME430.png", "list-thumb": "https://api.plotly.com/v2/files/senurii:13/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/senurii:13", "plots": "https://api.plotly.com/v2/plots/senurii:13", "parent": "https://api.plotly.com/v2/folders/home?user=senurii" }, "owner": "senurii", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~senurii/13/", "world_readable": true, "date_modified": "2025-09-13T07:07:56.935Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~senurii/13/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "line": { "dash": "dot", "width": 1 }, "meta": { "columnNames": { "x": "Params", "y": "Accuracy", "marker": { "color": "Dataset" } } }, "mode": "markers+lines", "name": "CNN-SK", "type": "scatter", "xsrc": "senurii:10:ed910c", "ysrc": "senurii:10:eb8571", "marker": { "line": { "color": "rgb(26, 24, 24)", "width": 1 }, "meta": { "columnNames": { "color": "Dataset" } }, "size": 10, "cauto": false, "colorsrc": "senurii:10:052ea2", "colorscale": [ [ 0, "#9e0142" ], [ 0.1, "#d53e4f" ], [ 0.2, "#f46d43" ], [ 0.3, "#fdae61" ], [ 0.4, "#fee08b" ], [ 0.5, "#ffffbf" ], [ 0.6, "#e6f598" ], [ 0.7, "#abdda4" ], [ 0.8, "#66c2a5" ], [ 0.9, "#3288bd" ], [ 1, "#5e4fa2" ] ], "reversescale": false }, "autocolorscale": false }, { "line": { "dash": "dot", "color": "rgb(59, 207, 239)", "width": 1 }, "meta": { "columnNames": { "x": "Params", "y": "Accuracy", "marker": { "color": "Dataset" } } }, "mode": "markers+lines", "name": "CNN-PSK (without weights)", "type": "scatter", "xsrc": "senurii:11:6aef50", "ysrc": "senurii:11:da8d22", "marker": { "line": { "color": "rgb(15, 20, 19)", "width": 1 }, "meta": { "columnNames": { "color": "Dataset" } }, "size": 10, "symbol": "diamond", "colorsrc": "senurii:11:23d22d", "colorscale": [ [ 0, "#9e0142" ], [ 0.1, "#d53e4f" ], [ 0.2, "#f46d43" ], [ 0.3, "#fdae61" ], [ 0.4, "#fee08b" ], [ 0.5, "#ffffbf" ], [ 0.6, "#e6f598" ], [ 0.7, "#abdda4" ], [ 0.8, "#66c2a5" ], [ 0.9, "#3288bd" ], [ 1, "#5e4fa2" ] ] }, "stackgroup": null, "autocolorscale": false }, { "line": { "dash": "dot", "color": "rgb(13, 22, 20)", "width": 2 }, "meta": { "columnNames": { "x": "Params", "y": "Accuracy", "marker": { "color": "Dataset" } } }, "mode": "markers+lines", "name": "CNN-PSK (with weights)", "type": "scatter", "xsrc": "senurii:12:4788fe", "ysrc": "senurii:12:a4cf8a", "marker": { "line": { "width": 1 }, "meta": { "columnNames": { "color": "Dataset" } }, "size": 10, "symbol": "cross", "colorsrc": "senurii:12:4bedaa", "colorscale": [ [ 0, "#9e0142" ], [ 0.1, "#d53e4f" ], [ 0.2, "#f46d43" ], [ 0.3, "#fdae61" ], [ 0.4, "#fee08b" ], [ 0.5, "#ffffbf" ], [ 0.6, "#e6f598" ], [ 0.7, "#abdda4" ], [ 0.8, "#66c2a5" ], [ 0.9, "#3288bd" ], [ 1, "#5e4fa2" ] ] }, "stackgroup": null, "autocolorscale": false } ], "frames": [], "layout": { "xaxis": { "type": "linear", "dtick": 8, "range": [ 500064.3157894737, 592151.6842105263 ], "tick0": 0, "title": { "text": "<b>Parameter Count</b>" }, "domain": [ 0, 1 ], "mirror": "ticks", "nticks": 0, "showline": true, "tickmode": "auto", "autorange": true, "linecolor": "rgb(0, 0, 0)", "linewidth": 1 }, "yaxis": { "type": "linear", "range": [ 80.13546391752577, 100.50453608247423 ], "title": { "text": "<b>Accuracy %</b>" }, "domain": [ 0, 1 ], "mirror": "ticks", "showline": true, "autorange": false, "linecolor": "rgb(0, 0, 0)", "linewidth": 1 }, "legend": { "x": 1.02, "y": 0.9202453987730062 }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~senurii", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/26.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-07 06:53:14", "mapbox_access_tokens": null, "has_password": null, "username": "senurii", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-07T13:01:56.436837Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~senurii/9.embed", "fid": "senurii:9", "filename": "SSRP Comparison", "filetype": "plot", "img_url": "https://api.plotly.com/v2/files/senurii:9/image?image_name=list-thumb", "image_urls": { "default": "https://api.plotly.com/v2/files/senurii:9/image?image_name=default", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/senurii/9/8_KM47RQDP4PZ6BVHFGP96AVOUEUAFNO.png", "list-thumb": "https://api.plotly.com/v2/files/senurii:9/image?image_name=list-thumb" }, "api_urls": { "files": "https://api.plotly.com/v2/files/senurii:9", "plots": "https://api.plotly.com/v2/plots/senurii:9", "parent": "https://api.plotly.com/v2/folders/home?user=senurii" }, "owner": "senurii", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~senurii/9/", "world_readable": true, "date_modified": "2025-09-13T06:55:37.977Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~senurii/9/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "Dataset", "y": "Accuracy" } }, "mode": "markers", "name": "CNN-K", "type": "bar", "xsrc": "senurii:6:53ec42", "ysrc": "senurii:6:e67da4", "marker": { "color": "rgb(234, 91, 111)" }, "visible": true, "orientation": "v" }, { "meta": { "columnNames": { "x": "Dataset", "y": "Accuracy" } }, "name": "CNN-SK (SSRP)", "type": "bar", "xsrc": "senurii:7:55b8f8", "ysrc": "senurii:7:14c57e", "marker": { "color": "rgb(255, 203, 97)" }, "orientation": "v" }, { "meta": { "columnNames": { "x": "Dataset", "y": "Accuracy" } }, "name": "CNN-SK (SSRP-MS)", "type": "bar", "xsrc": "senurii:8:15d9fb", "ysrc": "senurii:8:6bc290", "marker": { "color": "rgb(147, 218, 151)" }, "orientation": "v" }, { "meta": { "columnNames": { "x": "Dataset", "y": "Accuracy" } }, "name": "CNN-SK (SSRP-T)", "type": "bar", "xsrc": "senurii:5:5ac752", "ysrc": "senurii:5:2290eb", "marker": { "color": "rgb(119, 190, 240)" }, "orientation": "v" } ], "frames": [], "layout": { "xaxis": { "type": "category", "dtick": 1, "range": [ -0.5, 3.5 ], "title": { "text": "<b>Datasets</b>" }, "mirror": "ticks", "tickson": "labels", "showgrid": true, "showline": true, "tickmode": "linear", "autorange": false, "linecolor": "rgb(102, 113, 128)" }, "yaxis": { "type": "linear", "dtick": 5, "range": [ 60, 100 ], "tick0": 0, "title": { "text": "<b>Accuracy %</b>" }, "mirror": "ticks", "showgrid": true, "showline": true, "tickmode": "linear", "autorange": false, "linecolor": "rgb(102, 113, 128)" }, "legend": { "x": 1.02, "y": 1 }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~senurii", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/26.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-2.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-07 06:53:14", "mapbox_access_tokens": null, "has_password": null, "username": "senurii", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-07T11:57:57.954298Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~NaserNikandish/33.embed", "fid": "NaserNikandish:33", "filename": "SAMPLE students_map_dashboard 3", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/NaserNikandish/33/9_CDO3IWX1EVJY1FNMS12WC3H2TFH5QJ.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/NaserNikandish/33/2_7KY2P0O20KH6SNWV04IP3UGA2DR1ET.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/NaserNikandish/33/8_RKX7VOM42T4NFGLFKRACBM68PAQF6L.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/NaserNikandish/33/9_CDO3IWX1EVJY1FNMS12WC3H2TFH5QJ.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/NaserNikandish:33", "plots": "https://api.plotly.com/v2/plots/NaserNikandish:33", "parent": "https://api.plotly.com/v2/folders/home?user=NaserNikandish" }, "owner": "NaserNikandish", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~NaserNikandish/33/", "world_readable": true, "date_modified": "2025-09-07T11:57:57.965Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~NaserNikandish/33/", "current_user_permission": "read", "is_theme": null, "is_template": null, "autosize": true, "caption": "", "figure": { "data": [ { "mode": "markers+text", "name": "States", "type": "scattergeo", "latsrc": "NaserNikandish:32:9f7758", "lonsrc": "NaserNikandish:32:5e2e7e", "marker": { "line": { "width": 0.5 }, "sizemin": 4, "sizeref": 0.1377551020408163, "sizesrc": "NaserNikandish:32:37b72a", "colorbar": { "title": { "text": "Students" } }, "colorsrc": "NaserNikandish:32:205b76", "sizemode": "area", "showscale": true, "colorscale": [ [ 0, "#ffe6e6" ], [ 0.5, "#ff4d4d" ], [ 1, "#800000" ] ] }, "metasrc": "NaserNikandish:32:fe2aba", "textsrc": "NaserNikandish:32:fb98b7", "textfont": { "size": 10 }, "textposition": "top center", "customdatasrc": "NaserNikandish:32:2c5361", "hovertemplate": "<b>%{text}</b><br>-----------------------------------<br> Avg GPA: %{customdata[0]:.2f}<br> Avg Yrs Exp: %{customdata[1]:.2f}<br> Female: %{customdata[2]:.2f}%<br>-----------------------------------<br>Students: %{customdata[9]}<br> BAAI: %{customdata[4]} | ISAI: %{customdata[5]} | MSM: %{customdata[6]} | MSF: %{customdata[7]} | FLEX MBA: %{customdata[8]}<br>-----------------------------------<br><b>Years to Complete (1–4):</b><br> 1y:%{customdata[10]} 2y:%{customdata[11]} 3y:%{customdata[12]} 4y:%{customdata[13]}<br> %{meta}<extra></extra>" }, { "name": "Top States", "type": "table", "cells": { "align": "left", "height": 22, "valuessrc": "NaserNikandish:32:602f07" }, "domain": { "x": [ 0.86, 0.995 ], "y": [ 0.02, 0.4 ] }, "header": { "fill": { "color": "#f2f2f2" }, "font": { "size": 11 }, "align": "left", "valuessrc": "NaserNikandish:32:427b50" }, "columnwidthsrc": "NaserNikandish:32:2a2e85" } ], "layout": { "geo": { "scope": "usa", "projection": { "type": "albers usa" }, "showsubunits": true, "showcountries": false }, "title": { "x": 0.5, "text": "<span style='font-size:20px'><b>(Fake Data) US Part-time Students</b></span><br><span style='font-size:16px'><b>Program:</b> <i>All</i></span><br><span style='font-size:14px'><b>Total:</b> <i>2000</i></span>", "xanchor": "center" }, "margin": { "b": 40, "l": 40, "r": 60, "t": 90 }, "template": { "data": { "bar": [ { "type": "bar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } }, "error_x": { "color": "#2a3f5f" }, "error_y": { "color": "#2a3f5f" } } ], "pie": [ { "type": "pie", "automargin": true } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "white", "linecolor": "white", "endlinecolor": "#2a3f5f", "minorgridcolor": "white", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatter": [ { "type": "scatter", "fillpattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "barpolar": [ { "type": "barpolar", "marker": { "line": { "color": "#E5ECF6", "width": 0.5 }, "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "histogram": [ { "type": "histogram", "marker": { "pattern": { "size": 10, "fillmode": "overlay", "solidity": 0.2 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "colorscale": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "#E5ECF6", "showlakes": true, "subunitcolor": "white" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "#E5ECF6", "radialaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "angularaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "yaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" }, "zaxis": { "ticks": "", "gridcolor": "white", "gridwidth": 2, "linecolor": "white", "zerolinecolor": "white", "showbackground": true, "backgroundcolor": "#E5ECF6" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "title": { "standoff": 15 }, "gridcolor": "white", "linecolor": "white", "automargin": true, "zerolinecolor": "white", "zerolinewidth": 2 }, "mapbox": { "style": "light" }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "baxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "caxis": { "ticks": "", "gridcolor": "white", "linecolor": "white" }, "bgcolor": "#E5ECF6" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#FFA15A", "#19d3f3", "#FF6692", "#B6E880", "#FF97FF", "#FECB52" ], "coloraxis": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ], "sequentialminus": [ [ 0.0, "#0d0887" ], [ 0.1111111111111111, "#46039f" ], [ 0.2222222222222222, "#7201a8" ], [ 0.3333333333333333, "#9c179e" ], [ 0.4444444444444444, "#bd3786" ], [ 0.5555555555555556, "#d8576b" ], [ 0.6666666666666666, "#ed7953" ], [ 0.7777777777777778, "#fb9f3a" ], [ 0.8888888888888888, "#fdca26" ], [ 1.0, "#f0f921" ] ] }, "hoverlabel": { "align": "left" }, "plot_bgcolor": "#E5ECF6", "paper_bgcolor": "white", "shapedefaults": { "line": { "color": "#2a3f5f" } }, "autotypenumbers": "strict", "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#2a3f5f", "arrowwidth": 1 } } }, "annotations": [ { "x": 0.02, "y": 1.19, "text": "<b>Program</b>", "xref": "paper", "yref": "paper", "showarrow": false } ], "updatemenus": [ { "x": 0.02, "y": 1.14, "pad": { "r": 6, "t": 6 }, "buttons": [ { "args": [ { "lat": [ [ 36.116203, 31.054487, 27.766279, 42.165726, 40.349457, 40.590752, 35.630066, 40.388783, 40.298904, 43.326618, 33.040619, 37.769337, 35.747845, 42.230171, 33.729759, 47.400902, 38.456085, 39.849426, 39.063946, 44.268543, 37.66814, 43.933907, 45.694454, 41.597782, 31.169546, 33.856892, 39.059811, 32.806671, 35.565342, 38.5266, 34.969704, 38.313515, 40.150032, 42.011539, 32.741646, 44.045876, 38.491226, 44.240459, 41.680893, 41.12537, 43.452492, 44.693947, 34.840515, 21.094318, 44.299782, 47.528912, 39.318523, 46.921925, 42.755966, 38.905985, 61.370716 ], null ], "lon": [ [ -119.681564, -97.563461, -81.686783, -74.948051, -88.986137, -77.209755, -79.806419, -82.764915, -74.521011, -84.536095, -83.643074, -78.169968, -86.692345, -71.530106, -111.431221, -121.490494, -92.288368, -86.258278, -76.802101, -89.616508, -84.670067, -120.55899, -93.900192, -72.755371, -91.867805, -80.945007, -105.311104, -86.79113, -96.928917, -96.726486, -92.373123, -117.055374, -111.862434, -93.210526, -89.678696, -72.710686, -80.954453, -114.478828, -71.51178, -98.268082, -71.563896, -69.381927, -106.248482, -157.498337, -99.438828, -99.784012, -75.507141, -110.454353, -107.30249, -77.033418, -152.404419 ], null ], "meta": [ [ "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮ ▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮ ▮▮▮▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮ ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ · ·" ], null ], "text": [ [ "CA", "TX", "FL", "NY", "IL", "PA", "NC", "OH", "NJ", "MI", "GA", "VA", "TN", "MA", "AZ", "WA", "MO", "IN", "MD", "WI", "KY", "OR", "MN", "CT", "LA", "SC", "CO", "AL", "OK", "KS", "AR", "NV", "UT", "IA", "MS", "VT", "WV", "ID", "RI", "NE", "NH", "ME", "NM", "HI", "SD", "ND", "DE", "MT", "WY", "DC", "AK" ], null ], "customdata": [ [ [ 3.41, 3.49, 47.69, 22.22, 77.0, 32.0, 49.0, 23.0, 35.0, 216.0, 0.0, 53.0, 116.0, 47.0 ], [ 3.42, 3.1, 47.19, 22.47, 56.0, 34.0, 35.0, 25.0, 28.0, 178.0, 0.0, 41.0, 94.0, 43.0 ], [ 3.4, 3.23, 45.89, 22.6, 43.0, 16.0, 41.0, 16.0, 30.0, 146.0, 0.0, 45.0, 76.0, 25.0 ], [ 3.44, 2.99, 38.84, 23.97, 33.0, 21.0, 31.0, 13.0, 23.0, 121.0, 0.0, 31.0, 67.0, 23.0 ], [ 3.45, 3.43, 34.02, 18.56, 26.0, 21.0, 17.0, 17.0, 16.0, 97.0, 0.0, 23.0, 52.0, 22.0 ], [ 3.44, 2.54, 53.09, 20.99, 21.0, 14.0, 26.0, 10.0, 10.0, 81.0, 0.0, 22.0, 44.0, 15.0 ], [ 3.38, 3.34, 47.06, 16.18, 21.0, 9.0, 20.0, 7.0, 11.0, 68.0, 0.0, 12.0, 35.0, 21.0 ], [ 3.43, 3.85, 44.78, 17.91, 27.0, 9.0, 12.0, 11.0, 8.0, 67.0, 0.0, 14.0, 39.0, 14.0 ], [ 3.38, 3.49, 48.48, 21.21, 20.0, 8.0, 18.0, 11.0, 9.0, 66.0, 0.0, 14.0, 31.0, 21.0 ], [ 3.42, 3.5, 46.88, 26.56, 20.0, 14.0, 9.0, 8.0, 13.0, 64.0, 0.0, 14.0, 38.0, 12.0 ], [ 3.45, 3.37, 45.0, 26.67, 18.0, 14.0, 14.0, 4.0, 10.0, 60.0, 0.0, 10.0, 32.0, 18.0 ], [ 3.47, 3.71, 37.74, 24.53, 17.0, 12.0, 12.0, 4.0, 8.0, 53.0, 0.0, 8.0, 31.0, 14.0 ], [ 3.5, 3.5, 39.22, 21.57, 21.0, 6.0, 13.0, 8.0, 3.0, 51.0, 0.0, 10.0, 30.0, 11.0 ], [ 3.38, 3.19, 48.0, 18.0, 18.0, 14.0, 8.0, 3.0, 7.0, 50.0, 0.0, 6.0, 35.0, 9.0 ], [ 3.45, 3.35, 33.33, 15.56, 14.0, 8.0, 4.0, 7.0, 12.0, 45.0, 0.0, 11.0, 21.0, 13.0 ], [ 3.45, 3.76, 38.64, 27.27, 15.0, 10.0, 8.0, 6.0, 5.0, 44.0, 0.0, 6.0, 23.0, 15.0 ], [ 3.38, 2.94, 45.24, 19.05, 15.0, 6.0, 8.0, 5.0, 8.0, 42.0, 0.0, 7.0, 26.0, 9.0 ], [ 3.42, 2.8, 33.33, 26.19, 13.0, 5.0, 9.0, 9.0, 6.0, 42.0, 0.0, 9.0, 24.0, 9.0 ], [ 3.35, 3.45, 41.03, 28.21, 8.0, 6.0, 13.0, 4.0, 8.0, 39.0, 0.0, 11.0, 20.0, 8.0 ], [ 3.44, 3.18, 38.24, 23.53, 16.0, 8.0, 2.0, 3.0, 5.0, 34.0, 0.0, 7.0, 24.0, 3.0 ], [ 3.45, 3.32, 38.71, 19.35, 16.0, 8.0, 5.0, 1.0, 1.0, 31.0, 0.0, 4.0, 21.0, 6.0 ], [ 3.4, 3.5, 51.61, 22.58, 11.0, 5.0, 7.0, 3.0, 5.0, 31.0, 0.0, 7.0, 19.0, 5.0 ], [ 3.36, 4.03, 41.38, 34.48, 15.0, 4.0, 6.0, 2.0, 2.0, 29.0, 0.0, 7.0, 18.0, 4.0 ], [ 3.42, 3.39, 44.83, 6.9, 8.0, 2.0, 7.0, 7.0, 5.0, 29.0, 0.0, 7.0, 15.0, 7.0 ], [ 3.45, 3.76, 34.62, 23.08, 7.0, 3.0, 6.0, 4.0, 6.0, 26.0, 0.0, 6.0, 18.0, 2.0 ], [ 3.41, 3.37, 56.0, 20.0, 3.0, 4.0, 10.0, 5.0, 3.0, 25.0, 0.0, 4.0, 16.0, 5.0 ], [ 3.41, 3.25, 47.83, 21.74, 6.0, 2.0, 7.0, 2.0, 6.0, 23.0, 0.0, 6.0, 12.0, 5.0 ], [ 3.44, 3.02, 43.48, 26.09, 8.0, 2.0, 4.0, 2.0, 7.0, 23.0, 0.0, 4.0, 12.0, 7.0 ], [ 3.45, 3.81, 21.05, 21.05, 6.0, 3.0, 3.0, 4.0, 3.0, 19.0, 0.0, 3.0, 14.0, 2.0 ], [ 3.33, 3.74, 42.11, 5.26, 6.0, 6.0, 5.0, 2.0, 0.0, 19.0, 0.0, 4.0, 10.0, 5.0 ], [ 3.38, 2.59, 58.82, 17.65, 4.0, 4.0, 5.0, 2.0, 2.0, 17.0, 0.0, 6.0, 7.0, 4.0 ], [ 3.48, 3.3, 47.06, 23.53, 8.0, 2.0, 3.0, 0.0, 4.0, 17.0, 0.0, 5.0, 9.0, 3.0 ], [ 3.61, 2.69, 37.5, 25.0, 6.0, 1.0, 4.0, 1.0, 4.0, 16.0, 0.0, 4.0, 9.0, 3.0 ], [ 3.34, 3.77, 37.5, 25.0, 4.0, 3.0, 3.0, 1.0, 5.0, 16.0, 0.0, 4.0, 7.0, 5.0 ], [ 3.44, 2.62, 61.54, 23.08, 3.0, 5.0, 1.0, 3.0, 1.0, 13.0, 0.0, 4.0, 5.0, 4.0 ], [ 3.4, 3.19, 90.91, 27.27, 4.0, 1.0, 4.0, 2.0, 0.0, 11.0, 0.0, 4.0, 5.0, 2.0 ], [ 3.48, 3.78, 70.0, 20.0, 3.0, 1.0, 3.0, 1.0, 2.0, 10.0, 0.0, 3.0, 4.0, 3.0 ], [ 3.43, 3.5, 80.0, 10.0, 1.0, 4.0, 1.0, 2.0, 2.0, 10.0, 0.0, 2.0, 5.0, 3.0 ], [ 3.3, 2.59, 22.22, 11.11, 2.0, 2.0, 3.0, 2.0, 0.0, 9.0, 0.0, 2.0, 5.0, 2.0 ], [ 3.35, 4.13, 44.44, 22.22, 1.0, 2.0, 2.0, 2.0, 2.0, 9.0, 0.0, 4.0, 4.0, 1.0 ], [ 3.5, 2.54, 37.5, 25.0, 3.0, 1.0, 3.0, 0.0, 1.0, 8.0, 0.0, 3.0, 3.0, 2.0 ], [ 3.29, 1.99, 25.0, 37.5, 1.0, 3.0, 1.0, 1.0, 2.0, 8.0, 0.0, 4.0, 2.0, 2.0 ], [ 3.35, 3.84, 42.86, 14.29, 4.0, 1.0, 2.0, 0.0, 0.0, 7.0, 0.0, 1.0, 5.0, 1.0 ], [ 3.5, 3.66, 50.0, 33.33, 1.0, 3.0, 1.0, 1.0, 0.0, 6.0, 0.0, 1.0, 1.0, 4.0 ], [ 3.48, 2.94, 40.0, 20.0, 2.0, 2.0, 1.0, 0.0, 0.0, 5.0, 0.0, 1.0, 3.0, 1.0 ], [ 3.53, 3.64, 80.0, 20.0, 2.0, 1.0, 0.0, 1.0, 1.0, 5.0, 0.0, 1.0, 4.0, 0.0 ], [ 3.34, 3.81, 100.0, 50.0, 1.0, 0.0, 2.0, 0.0, 1.0, 4.0, 0.0, 2.0, 2.0, 0.0 ], [ 3.58, 4.23, 50.0, 0.0, 0.0, 2.0, 1.0, 1.0, 0.0, 4.0, 0.0, 1.0, 3.0, 0.0 ], [ 3.29, 1.86, 33.33, 33.33, 1.0, 1.0, 0.0, 1.0, 0.0, 3.0, 0.0, 0.0, 3.0, 0.0 ], [ 3.09, 1.42, 0.0, 50.0, 1.0, 0.0, 0.0, 1.0, 0.0, 2.0, 0.0, 1.0, 0.0, 1.0 ], [ 2.99, 1.62, 0.0, 100.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ] ], null ], "marker.size": [ [ 216, 178, 146, 121, 97, 81, 68, 67, 66, 64, 60, 53, 51, 50, 45, 44, 42, 42, 39, 34, 31, 31, 29, 29, 26, 25, 23, 23, 19, 19, 17, 17, 16, 16, 13, 11, 10, 10, 9, 9, 8, 8, 7, 6, 5, 5, 4, 4, 3, 2, 1 ], null ], "cells.values": [ null, [ [ "1", "2", "3" ], [ "CA", "TX", "FL" ], [ 216, 178, 146 ] ] ], "marker.color": [ [ 216, 178, 146, 121, 97, 81, 68, 67, 66, 64, 60, 53, 51, 50, 45, 44, 42, 42, 39, 34, 31, 31, 29, 29, 26, 25, 23, 23, 19, 19, 17, 17, 16, 16, 13, 11, 10, 10, 9, 9, 8, 8, 7, 6, 5, 5, 4, 4, 3, 2, 1 ], null ], "marker.sizeref": [ 0.1377551020408163, null ] }, { "title": "<span style='font-size:20px'><b>(Fake Data) US Part-time Students</b></span><br><span style='font-size:16px'><b>Program:</b> <i>All</i></span><br><span style='font-size:14px'><b>Total:</b> <i>2000</i></span>" } ], "label": "All", "method": "update" }, { "args": [ { "lat": [ [ 36.116203, 31.054487, 27.766279, 42.165726, 40.388783, 40.349457, 40.590752, 35.747845, 35.630066, 40.298904, 43.326618, 42.230171, 33.040619, 37.769337, 37.66814, 44.268543, 47.400902, 38.456085, 45.694454, 33.729759, 39.849426, 43.933907, 41.597782, 32.806671, 38.313515, 39.063946, 31.169546, 35.565342, 40.150032, 38.5266, 39.059811, 44.045876, 34.840515, 42.011539, 34.969704, 38.491226, 33.856892, 32.741646, 43.452492, 41.680893, 44.299782, 47.528912, 41.12537, 44.693947, 44.240459, 21.094318, 39.318523, 38.905985, 42.755966 ], null ], "lon": [ [ -119.681564, -97.563461, -81.686783, -74.948051, -82.764915, -88.986137, -77.209755, -86.692345, -79.806419, -74.521011, -84.536095, -71.530106, -83.643074, -78.169968, -84.670067, -89.616508, -121.490494, -92.288368, -93.900192, -111.431221, -86.258278, -120.55899, -72.755371, -86.79113, -117.055374, -76.802101, -91.867805, -96.928917, -111.862434, -96.726486, -105.311104, -72.710686, -106.248482, -93.210526, -92.373123, -80.954453, -80.945007, -89.678696, -71.563896, -71.51178, -99.438828, -99.784012, -98.268082, -69.381927, -114.478828, -157.498337, -75.507141, -77.033418, -107.30249 ], null ], "meta": [ [ "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· · ▮▮▮▮▮▮ ▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ·", "· ▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮ ▮▮▮ ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ▮▮", "· · ▮▮▮▮▮▮ ▮▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ·", "· ▮▮▮▮▮▮ · ·", "· ▮▮▮▮▮▮ · ·", "· · · ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ·", "· · ▮▮▮▮▮▮ ·" ], null ], "text": [ [ "CA", "TX", "FL", "NY", "OH", "IL", "PA", "TN", "NC", "NJ", "MI", "MA", "GA", "VA", "KY", "WI", "WA", "MO", "MN", "AZ", "IN", "OR", "CT", "AL", "NV", "MD", "LA", "OK", "UT", "KS", "CO", "VT", "NM", "IA", "AR", "WV", "SC", "MS", "NH", "RI", "SD", "ND", "NE", "ME", "ID", "HI", "DE", "DC", "WY" ], null ], "customdata": [ [ [ 3.43, 3.64, 41.56, 24.68, 77.0, 0.0, 0.0, 0.0, 0.0, 77.0, 0.0, 18.0, 43.0, 16.0 ], [ 3.44, 3.02, 48.21, 25.0, 56.0, 0.0, 0.0, 0.0, 0.0, 56.0, 0.0, 11.0, 32.0, 13.0 ], [ 3.37, 3.39, 44.19, 23.26, 43.0, 0.0, 0.0, 0.0, 0.0, 43.0, 0.0, 16.0, 18.0, 9.0 ], [ 3.45, 2.62, 33.33, 27.27, 33.0, 0.0, 0.0, 0.0, 0.0, 33.0, 0.0, 10.0, 12.0, 11.0 ], [ 3.42, 3.95, 51.85, 22.22, 27.0, 0.0, 0.0, 0.0, 0.0, 27.0, 0.0, 7.0, 15.0, 5.0 ], [ 3.44, 4.22, 34.62, 19.23, 26.0, 0.0, 0.0, 0.0, 0.0, 26.0, 0.0, 4.0, 17.0, 5.0 ], [ 3.43, 2.18, 57.14, 9.52, 21.0, 0.0, 0.0, 0.0, 0.0, 21.0, 0.0, 6.0, 12.0, 3.0 ], [ 3.46, 3.52, 52.38, 23.81, 21.0, 0.0, 0.0, 0.0, 0.0, 21.0, 0.0, 3.0, 14.0, 4.0 ], [ 3.42, 3.06, 42.86, 19.05, 21.0, 0.0, 0.0, 0.0, 0.0, 21.0, 0.0, 3.0, 9.0, 9.0 ], [ 3.41, 3.03, 55.0, 25.0, 20.0, 0.0, 0.0, 0.0, 0.0, 20.0, 0.0, 5.0, 9.0, 6.0 ], [ 3.43, 3.28, 45.0, 30.0, 20.0, 0.0, 0.0, 0.0, 0.0, 20.0, 0.0, 4.0, 15.0, 1.0 ], [ 3.34, 3.13, 50.0, 22.22, 18.0, 0.0, 0.0, 0.0, 0.0, 18.0, 0.0, 4.0, 12.0, 2.0 ], [ 3.47, 3.68, 33.33, 33.33, 18.0, 0.0, 0.0, 0.0, 0.0, 18.0, 0.0, 4.0, 7.0, 7.0 ], [ 3.53, 4.03, 47.06, 17.65, 17.0, 0.0, 0.0, 0.0, 0.0, 17.0, 0.0, 3.0, 9.0, 5.0 ], [ 3.53, 3.14, 43.75, 31.25, 16.0, 0.0, 0.0, 0.0, 0.0, 16.0, 0.0, 1.0, 11.0, 4.0 ], [ 3.5, 3.38, 50.0, 25.0, 16.0, 0.0, 0.0, 0.0, 0.0, 16.0, 0.0, 2.0, 12.0, 2.0 ], [ 3.52, 4.39, 26.67, 40.0, 15.0, 0.0, 0.0, 0.0, 0.0, 15.0, 0.0, 3.0, 6.0, 6.0 ], [ 3.4, 3.27, 60.0, 20.0, 15.0, 0.0, 0.0, 0.0, 0.0, 15.0, 0.0, 2.0, 9.0, 4.0 ], [ 3.32, 4.02, 40.0, 46.67, 15.0, 0.0, 0.0, 0.0, 0.0, 15.0, 0.0, 4.0, 9.0, 2.0 ], [ 3.43, 3.53, 64.29, 14.29, 14.0, 0.0, 0.0, 0.0, 0.0, 14.0, 0.0, 5.0, 6.0, 3.0 ], [ 3.4, 2.47, 30.77, 38.46, 13.0, 0.0, 0.0, 0.0, 0.0, 13.0, 0.0, 0.0, 10.0, 3.0 ], [ 3.4, 4.46, 54.55, 36.36, 11.0, 0.0, 0.0, 0.0, 0.0, 11.0, 0.0, 4.0, 4.0, 3.0 ], [ 3.33, 3.1, 50.0, 12.5, 8.0, 0.0, 0.0, 0.0, 0.0, 8.0, 0.0, 1.0, 6.0, 1.0 ], [ 3.39, 3.12, 37.5, 37.5, 8.0, 0.0, 0.0, 0.0, 0.0, 8.0, 0.0, 1.0, 3.0, 4.0 ], [ 3.51, 2.99, 37.5, 12.5, 8.0, 0.0, 0.0, 0.0, 0.0, 8.0, 0.0, 2.0, 4.0, 2.0 ], [ 3.33, 2.98, 37.5, 25.0, 8.0, 0.0, 0.0, 0.0, 0.0, 8.0, 0.0, 1.0, 6.0, 1.0 ], [ 3.48, 4.18, 28.57, 42.86, 7.0, 0.0, 0.0, 0.0, 0.0, 7.0, 0.0, 2.0, 5.0, 0.0 ], [ 3.49, 3.85, 16.67, 16.67, 6.0, 0.0, 0.0, 0.0, 0.0, 6.0, 0.0, 1.0, 5.0, 0.0 ], [ 3.54, 2.25, 0.0, 33.33, 6.0, 0.0, 0.0, 0.0, 0.0, 6.0, 0.0, 2.0, 3.0, 1.0 ], [ 3.25, 3.06, 50.0, 0.0, 6.0, 0.0, 0.0, 0.0, 0.0, 6.0, 0.0, 1.0, 4.0, 1.0 ], [ 3.44, 3.85, 66.67, 16.67, 6.0, 0.0, 0.0, 0.0, 0.0, 6.0, 0.0, 1.0, 3.0, 2.0 ], [ 3.39, 2.99, 75.0, 25.0, 4.0, 0.0, 0.0, 0.0, 0.0, 4.0, 0.0, 1.0, 2.0, 1.0 ], [ 3.22, 3.6, 75.0, 25.0, 4.0, 0.0, 0.0, 0.0, 0.0, 4.0, 0.0, 0.0, 4.0, 0.0 ], [ 3.21, 3.09, 50.0, 25.0, 4.0, 0.0, 0.0, 0.0, 0.0, 4.0, 0.0, 1.0, 1.0, 2.0 ], [ 3.19, 4.11, 0.0, 0.0, 4.0, 0.0, 0.0, 0.0, 0.0, 4.0, 0.0, 0.0, 3.0, 1.0 ], [ 3.67, 2.32, 66.67, 0.0, 3.0, 0.0, 0.0, 0.0, 0.0, 3.0, 0.0, 0.0, 2.0, 1.0 ], [ 3.34, 1.05, 66.67, 33.33, 3.0, 0.0, 0.0, 0.0, 0.0, 3.0, 0.0, 1.0, 2.0, 0.0 ], [ 3.19, 3.5, 66.67, 0.0, 3.0, 0.0, 0.0, 0.0, 0.0, 3.0, 0.0, 2.0, 0.0, 1.0 ], [ 3.44, 3.45, 0.0, 0.0, 3.0, 0.0, 0.0, 0.0, 0.0, 3.0, 0.0, 1.0, 1.0, 1.0 ], [ 3.44, 2.9, 50.0, 0.0, 2.0, 0.0, 0.0, 0.0, 0.0, 2.0, 0.0, 0.0, 2.0, 0.0 ], [ 3.32, 2.7, 0.0, 50.0, 2.0, 0.0, 0.0, 0.0, 0.0, 2.0, 0.0, 0.0, 1.0, 1.0 ], [ 3.42, 5.26, 100.0, 0.0, 2.0, 0.0, 0.0, 0.0, 0.0, 2.0, 0.0, 0.0, 2.0, 0.0 ], [ 3.32, 3.09, 100.0, 0.0, 1.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ], [ 3.47, 2.13, 100.0, 100.0, 1.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ], [ 3.26, 4.59, 100.0, 0.0, 1.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ], [ 3.78, 4.0, 100.0, 0.0, 1.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0 ], [ 3.54, 4.94, 100.0, 0.0, 1.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.23, 1.38, 0.0, 100.0, 1.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ], [ 3.44, 3.72, 100.0, 0.0, 1.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ] ], null ], "marker.size": [ [ 77, 56, 43, 33, 27, 26, 21, 21, 21, 20, 20, 18, 18, 17, 16, 16, 15, 15, 15, 14, 13, 11, 8, 8, 8, 8, 7, 6, 6, 6, 6, 4, 4, 4, 4, 3, 3, 3, 3, 2, 2, 2, 1, 1, 1, 1, 1, 1, 1 ], null ], "cells.values": [ null, [ [ "1", "2", "3" ], [ "CA", "TX", "FL" ], [ 77, 56, 43 ] ] ], "marker.color": [ [ 77, 56, 43, 33, 27, 26, 21, 21, 21, 20, 20, 18, 18, 17, 16, 16, 15, 15, 15, 14, 13, 11, 8, 8, 8, 8, 7, 6, 6, 6, 6, 4, 4, 4, 4, 3, 3, 3, 3, 2, 2, 2, 1, 1, 1, 1, 1, 1, 1 ], null ], "marker.sizeref": [ 0.049107142857142856, null ] }, { "title": "<span style='font-size:20px'><b>(Fake Data) US Part-time Students</b></span><br><span style='font-size:16px'><b>Program:</b> <i>BAAI</i></span><br><span style='font-size:14px'><b>Total:</b> <i>637</i></span>" } ], "label": "BAAI", "method": "update" }, { "args": [ { "lat": [ [ 31.054487, 36.116203, 40.349457, 42.165726, 27.766279, 33.040619, 43.326618, 40.590752, 42.230171, 37.769337, 47.400902, 35.630066, 40.388783, 33.729759, 37.66814, 40.298904, 44.268543, 35.747845, 38.5266, 39.063946, 38.456085, 39.849426, 43.933907, 32.741646, 33.856892, 45.694454, 44.240459, 34.969704, 44.693947, 31.169546, 42.011539, 21.094318, 35.565342, 44.299782, 41.680893, 46.921925, 38.313515, 41.12537, 32.806671, 41.597782, 39.059811, 38.491226, 44.045876, 61.370716, 40.150032, 34.840515, 43.452492, 47.528912, 42.755966 ], null ], "lon": [ [ -97.563461, -119.681564, -88.986137, -74.948051, -81.686783, -83.643074, -84.536095, -77.209755, -71.530106, -78.169968, -121.490494, -79.806419, -82.764915, -111.431221, -84.670067, -74.521011, -89.616508, -86.692345, -96.726486, -76.802101, -92.288368, -86.258278, -120.55899, -89.678696, -80.945007, -93.900192, -114.478828, -92.373123, -69.381927, -91.867805, -93.210526, -157.498337, -96.928917, -99.438828, -71.51178, -110.454353, -117.055374, -98.268082, -86.79113, -72.755371, -105.311104, -80.954453, -72.710686, -152.404419, -111.862434, -106.248482, -71.563896, -99.784012, -107.30249 ], null ], "meta": [ [ "· ▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ▮▮▮▮", "· · ▮▮▮▮▮▮ ▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮▮▮▮ ▮ ▮▮▮▮", "· ▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮▮▮▮ ▮▮ ▮▮", "· · ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· · ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ▮▮", "· · ▮▮▮▮▮▮ ▮▮", "· ▮▮▮▮▮▮ ▮▮▮ ▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮ ·", "· · ▮▮▮▮▮▮ ▮▮▮", "· · ▮▮▮▮▮▮ ▮▮▮", "· ▮▮▮ · ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ·", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ·", "· ▮▮▮▮▮▮ · ·", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ·", "· · ▮▮▮▮▮▮ ·" ], null ], "text": [ [ "TX", "CA", "IL", "NY", "FL", "GA", "MI", "PA", "MA", "VA", "WA", "NC", "OH", "AZ", "KY", "NJ", "WI", "TN", "KS", "MD", "MO", "IN", "OR", "MS", "SC", "MN", "ID", "AR", "ME", "LA", "IA", "HI", "OK", "SD", "RI", "MT", "NV", "NE", "AL", "CT", "CO", "WV", "VT", "AK", "UT", "NM", "NH", "ND", "WY" ], null ], "customdata": [ [ [ 3.4, 2.78, 44.12, 26.47, 0.0, 34.0, 0.0, 0.0, 0.0, 34.0, 0.0, 8.0, 17.0, 9.0 ], [ 3.36, 3.59, 50.0, 21.88, 0.0, 32.0, 0.0, 0.0, 0.0, 32.0, 0.0, 8.0, 19.0, 5.0 ], [ 3.42, 2.75, 23.81, 14.29, 0.0, 21.0, 0.0, 0.0, 0.0, 21.0, 0.0, 4.0, 14.0, 3.0 ], [ 3.46, 3.43, 23.81, 19.05, 0.0, 21.0, 0.0, 0.0, 0.0, 21.0, 0.0, 6.0, 13.0, 2.0 ], [ 3.44, 2.84, 31.25, 25.0, 0.0, 16.0, 0.0, 0.0, 0.0, 16.0, 0.0, 5.0, 7.0, 4.0 ], [ 3.48, 3.66, 57.14, 21.43, 0.0, 14.0, 0.0, 0.0, 0.0, 14.0, 0.0, 2.0, 7.0, 5.0 ], [ 3.38, 4.47, 50.0, 35.71, 0.0, 14.0, 0.0, 0.0, 0.0, 14.0, 0.0, 3.0, 8.0, 3.0 ], [ 3.41, 2.61, 57.14, 21.43, 0.0, 14.0, 0.0, 0.0, 0.0, 14.0, 0.0, 2.0, 6.0, 6.0 ], [ 3.4, 3.25, 50.0, 21.43, 0.0, 14.0, 0.0, 0.0, 0.0, 14.0, 0.0, 0.0, 8.0, 6.0 ], [ 3.57, 3.91, 33.33, 41.67, 0.0, 12.0, 0.0, 0.0, 0.0, 12.0, 0.0, 0.0, 8.0, 4.0 ], [ 3.38, 3.63, 50.0, 20.0, 0.0, 10.0, 0.0, 0.0, 0.0, 10.0, 0.0, 2.0, 5.0, 3.0 ], [ 3.29, 4.3, 55.56, 0.0, 0.0, 9.0, 0.0, 0.0, 0.0, 9.0, 0.0, 3.0, 3.0, 3.0 ], [ 3.41, 4.35, 33.33, 11.11, 0.0, 9.0, 0.0, 0.0, 0.0, 9.0, 0.0, 0.0, 6.0, 3.0 ], [ 3.53, 3.1, 12.5, 0.0, 0.0, 8.0, 0.0, 0.0, 0.0, 8.0, 0.0, 1.0, 6.0, 1.0 ], [ 3.38, 4.37, 25.0, 12.5, 0.0, 8.0, 0.0, 0.0, 0.0, 8.0, 0.0, 2.0, 5.0, 1.0 ], [ 3.34, 3.09, 50.0, 25.0, 0.0, 8.0, 0.0, 0.0, 0.0, 8.0, 0.0, 4.0, 1.0, 3.0 ], [ 3.31, 3.31, 25.0, 25.0, 0.0, 8.0, 0.0, 0.0, 0.0, 8.0, 0.0, 1.0, 7.0, 0.0 ], [ 3.55, 5.14, 33.33, 16.67, 0.0, 6.0, 0.0, 0.0, 0.0, 6.0, 0.0, 2.0, 3.0, 1.0 ], [ 3.36, 3.99, 66.67, 16.67, 0.0, 6.0, 0.0, 0.0, 0.0, 6.0, 0.0, 2.0, 3.0, 1.0 ], [ 3.35, 2.43, 50.0, 16.67, 0.0, 6.0, 0.0, 0.0, 0.0, 6.0, 0.0, 1.0, 4.0, 1.0 ], [ 3.34, 2.72, 33.33, 16.67, 0.0, 6.0, 0.0, 0.0, 0.0, 6.0, 0.0, 1.0, 4.0, 1.0 ], [ 3.34, 1.0, 20.0, 0.0, 0.0, 5.0, 0.0, 0.0, 0.0, 5.0, 0.0, 3.0, 1.0, 1.0 ], [ 3.3, 3.79, 40.0, 20.0, 0.0, 5.0, 0.0, 0.0, 0.0, 5.0, 0.0, 0.0, 3.0, 2.0 ], [ 3.61, 1.86, 80.0, 40.0, 0.0, 5.0, 0.0, 0.0, 0.0, 5.0, 0.0, 1.0, 3.0, 1.0 ], [ 3.54, 3.75, 50.0, 50.0, 0.0, 4.0, 0.0, 0.0, 0.0, 4.0, 0.0, 0.0, 2.0, 2.0 ], [ 3.44, 5.74, 50.0, 0.0, 0.0, 4.0, 0.0, 0.0, 0.0, 4.0, 0.0, 0.0, 3.0, 1.0 ], [ 3.32, 3.75, 75.0, 0.0, 0.0, 4.0, 0.0, 0.0, 0.0, 4.0, 0.0, 0.0, 3.0, 1.0 ], [ 3.45, 1.8, 50.0, 25.0, 0.0, 4.0, 0.0, 0.0, 0.0, 4.0, 0.0, 2.0, 1.0, 1.0 ], [ 3.41, 3.6, 0.0, 66.67, 0.0, 3.0, 0.0, 0.0, 0.0, 3.0, 0.0, 2.0, 1.0, 0.0 ], [ 3.34, 3.04, 33.33, 33.33, 0.0, 3.0, 0.0, 0.0, 0.0, 3.0, 0.0, 0.0, 2.0, 1.0 ], [ 3.28, 5.67, 33.33, 0.0, 0.0, 3.0, 0.0, 0.0, 0.0, 3.0, 0.0, 0.0, 2.0, 1.0 ], [ 3.48, 4.92, 66.67, 33.33, 0.0, 3.0, 0.0, 0.0, 0.0, 3.0, 0.0, 1.0, 0.0, 2.0 ], [ 3.52, 1.78, 33.33, 0.0, 0.0, 3.0, 0.0, 0.0, 0.0, 3.0, 0.0, 1.0, 1.0, 1.0 ], [ 3.56, 3.96, 50.0, 0.0, 0.0, 2.0, 0.0, 0.0, 0.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.16, 2.42, 0.0, 50.0, 0.0, 2.0, 0.0, 0.0, 0.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.66, 2.86, 0.0, 0.0, 0.0, 2.0, 0.0, 0.0, 0.0, 2.0, 0.0, 0.0, 2.0, 0.0 ], [ 3.54, 1.71, 0.0, 0.0, 0.0, 2.0, 0.0, 0.0, 0.0, 2.0, 0.0, 0.0, 2.0, 0.0 ], [ 3.56, 4.27, 50.0, 0.0, 0.0, 2.0, 0.0, 0.0, 0.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.69, 5.58, 50.0, 50.0, 0.0, 2.0, 0.0, 0.0, 0.0, 2.0, 0.0, 0.0, 2.0, 0.0 ], [ 3.44, 4.56, 50.0, 0.0, 0.0, 2.0, 0.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 0.0 ], [ 3.37, 2.64, 50.0, 50.0, 0.0, 2.0, 0.0, 0.0, 0.0, 2.0, 0.0, 0.0, 2.0, 0.0 ], [ 3.34, 3.33, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.44, 2.54, 100.0, 100.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 2.99, 1.62, 0.0, 100.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ], [ 3.66, 3.1, 100.0, 100.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ], [ 3.68, 3.9, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.9, 3.54, 100.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.85, 1.1, 0.0, 100.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ], [ 3.27, 0.33, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ] ], null ], "marker.size": [ [ 34, 32, 21, 21, 16, 14, 14, 14, 14, 12, 10, 9, 9, 8, 8, 8, 8, 6, 6, 6, 6, 5, 5, 5, 4, 4, 4, 4, 3, 3, 3, 3, 3, 2, 2, 2, 2, 2, 2, 2, 2, 1, 1, 1, 1, 1, 1, 1, 1 ], null ], "cells.values": [ null, [ [ "1", "2", "3" ], [ "TX", "CA", "IL" ], [ 34, 32, 21 ] ] ], "marker.color": [ [ 34, 32, 21, 21, 16, 14, 14, 14, 14, 12, 10, 9, 9, 8, 8, 8, 8, 6, 6, 6, 6, 5, 5, 5, 4, 4, 4, 4, 3, 3, 3, 3, 3, 2, 2, 2, 2, 2, 2, 2, 2, 1, 1, 1, 1, 1, 1, 1, 1 ], null ], "marker.sizeref": [ 0.021683673469387755, null ] }, { "title": "<span style='font-size:20px'><b>(Fake Data) US Part-time Students</b></span><br><span style='font-size:16px'><b>Program:</b> <i>ISAI</i></span><br><span style='font-size:14px'><b>Total:</b> <i>346</i></span>" } ], "label": "ISAI", "method": "update" }, { "args": [ { "lat": [ [ 36.116203, 27.766279, 31.054487, 42.165726, 40.590752, 35.630066, 40.298904, 40.349457, 33.040619, 39.063946, 35.747845, 37.769337, 40.388783, 33.856892, 39.849426, 43.326618, 38.456085, 47.400902, 42.230171, 43.933907, 41.597782, 39.059811, 31.169546, 45.694454, 34.969704, 37.66814, 38.5266, 40.150032, 44.045876, 33.729759, 32.806671, 35.565342, 41.680893, 38.491226, 38.313515, 43.452492, 42.011539, 34.840515, 41.12537, 39.318523, 44.268543, 44.299782, 46.921925, 44.693947, 44.240459, 21.094318, 32.741646 ], null ], "lon": [ [ -119.681564, -81.686783, -97.563461, -74.948051, -77.209755, -79.806419, -74.521011, -88.986137, -83.643074, -76.802101, -86.692345, -78.169968, -82.764915, -80.945007, -86.258278, -84.536095, -92.288368, -121.490494, -71.530106, -120.55899, -72.755371, -105.311104, -91.867805, -93.900192, -92.373123, -84.670067, -96.726486, -111.862434, -72.710686, -111.431221, -86.79113, -96.928917, -71.51178, -80.954453, -117.055374, -71.563896, -93.210526, -106.248482, -98.268082, -75.507141, -89.616508, -99.438828, -110.454353, -69.381927, -114.478828, -157.498337, -89.678696 ], null ], "meta": [ [ "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮ ▮▮▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· · ▮▮▮▮▮▮ ▮▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮ ▮▮▮▮▮▮ ·", "· ▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮", "· · ▮▮▮▮▮▮ ·", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ·", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮ ▮▮▮", "· · ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮ · ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ · ·", "· ▮▮▮▮▮▮ · ▮▮▮", "· ▮▮▮▮▮▮ · ▮▮▮", "· ▮▮▮▮▮▮ · ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ·", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·" ], null ], "text": [ [ "CA", "FL", "TX", "NY", "PA", "NC", "NJ", "IL", "GA", "MD", "TN", "VA", "OH", "SC", "IN", "MI", "MO", "WA", "MA", "OR", "CT", "CO", "LA", "MN", "AR", "KY", "KS", "UT", "VT", "AZ", "AL", "OK", "RI", "WV", "NV", "NH", "IA", "NM", "NE", "DE", "WI", "SD", "MT", "ME", "ID", "HI", "MS" ], null ], "customdata": [ [ [ 3.45, 3.62, 53.06, 20.41, 0.0, 0.0, 49.0, 0.0, 0.0, 49.0, 0.0, 14.0, 23.0, 12.0 ], [ 3.36, 3.4, 48.78, 24.39, 0.0, 0.0, 41.0, 0.0, 0.0, 41.0, 0.0, 11.0, 24.0, 6.0 ], [ 3.44, 2.94, 42.86, 20.0, 0.0, 0.0, 35.0, 0.0, 0.0, 35.0, 0.0, 10.0, 17.0, 8.0 ], [ 3.44, 2.97, 41.94, 19.35, 0.0, 0.0, 31.0, 0.0, 0.0, 31.0, 0.0, 8.0, 15.0, 8.0 ], [ 3.47, 3.05, 61.54, 26.92, 0.0, 0.0, 26.0, 0.0, 0.0, 26.0, 0.0, 10.0, 13.0, 3.0 ], [ 3.42, 3.49, 30.0, 25.0, 0.0, 0.0, 20.0, 0.0, 0.0, 20.0, 0.0, 3.0, 13.0, 4.0 ], [ 3.37, 3.0, 38.89, 16.67, 0.0, 0.0, 18.0, 0.0, 0.0, 18.0, 0.0, 3.0, 9.0, 6.0 ], [ 3.44, 3.36, 58.82, 17.65, 0.0, 0.0, 17.0, 0.0, 0.0, 17.0, 0.0, 7.0, 7.0, 3.0 ], [ 3.49, 2.79, 28.57, 28.57, 0.0, 0.0, 14.0, 0.0, 0.0, 14.0, 0.0, 3.0, 8.0, 3.0 ], [ 3.31, 4.21, 38.46, 23.08, 0.0, 0.0, 13.0, 0.0, 0.0, 13.0, 0.0, 6.0, 4.0, 3.0 ], [ 3.55, 3.48, 38.46, 23.08, 0.0, 0.0, 13.0, 0.0, 0.0, 13.0, 0.0, 4.0, 6.0, 3.0 ], [ 3.35, 4.47, 16.67, 8.33, 0.0, 0.0, 12.0, 0.0, 0.0, 12.0, 0.0, 2.0, 8.0, 2.0 ], [ 3.42, 2.87, 33.33, 25.0, 0.0, 0.0, 12.0, 0.0, 0.0, 12.0, 0.0, 2.0, 8.0, 2.0 ], [ 3.45, 4.04, 50.0, 20.0, 0.0, 0.0, 10.0, 0.0, 0.0, 10.0, 0.0, 0.0, 7.0, 3.0 ], [ 3.4, 3.18, 33.33, 11.11, 0.0, 0.0, 9.0, 0.0, 0.0, 9.0, 0.0, 3.0, 4.0, 2.0 ], [ 3.54, 4.27, 44.44, 33.33, 0.0, 0.0, 9.0, 0.0, 0.0, 9.0, 0.0, 2.0, 5.0, 2.0 ], [ 3.42, 2.41, 12.5, 12.5, 0.0, 0.0, 8.0, 0.0, 0.0, 8.0, 0.0, 1.0, 5.0, 2.0 ], [ 3.52, 2.69, 37.5, 37.5, 0.0, 0.0, 8.0, 0.0, 0.0, 8.0, 0.0, 1.0, 4.0, 3.0 ], [ 3.47, 3.82, 37.5, 12.5, 0.0, 0.0, 8.0, 0.0, 0.0, 8.0, 0.0, 2.0, 6.0, 0.0 ], [ 3.47, 2.74, 42.86, 28.57, 0.0, 0.0, 7.0, 0.0, 0.0, 7.0, 0.0, 1.0, 6.0, 0.0 ], [ 3.48, 3.23, 0.0, 14.29, 0.0, 0.0, 7.0, 0.0, 0.0, 7.0, 0.0, 3.0, 3.0, 1.0 ], [ 3.45, 3.33, 42.86, 28.57, 0.0, 0.0, 7.0, 0.0, 0.0, 7.0, 0.0, 3.0, 3.0, 1.0 ], [ 3.44, 3.38, 33.33, 16.67, 0.0, 0.0, 6.0, 0.0, 0.0, 6.0, 0.0, 0.0, 6.0, 0.0 ], [ 3.46, 4.57, 33.33, 33.33, 0.0, 0.0, 6.0, 0.0, 0.0, 6.0, 0.0, 1.0, 4.0, 1.0 ], [ 3.3, 2.79, 100.0, 40.0, 0.0, 0.0, 5.0, 0.0, 0.0, 5.0, 0.0, 1.0, 3.0, 1.0 ], [ 3.33, 2.68, 40.0, 0.0, 0.0, 0.0, 5.0, 0.0, 0.0, 5.0, 0.0, 1.0, 4.0, 0.0 ], [ 3.43, 4.49, 20.0, 0.0, 0.0, 0.0, 5.0, 0.0, 0.0, 5.0, 0.0, 1.0, 2.0, 2.0 ], [ 3.65, 3.35, 0.0, 0.0, 0.0, 0.0, 4.0, 0.0, 0.0, 4.0, 0.0, 1.0, 2.0, 1.0 ], [ 3.35, 2.07, 100.0, 25.0, 0.0, 0.0, 4.0, 0.0, 0.0, 4.0, 0.0, 2.0, 1.0, 1.0 ], [ 3.4, 3.22, 0.0, 0.0, 0.0, 0.0, 4.0, 0.0, 0.0, 4.0, 0.0, 0.0, 2.0, 2.0 ], [ 3.31, 4.65, 50.0, 25.0, 0.0, 0.0, 4.0, 0.0, 0.0, 4.0, 0.0, 3.0, 1.0, 0.0 ], [ 3.49, 6.37, 33.33, 0.0, 0.0, 0.0, 3.0, 0.0, 0.0, 3.0, 0.0, 0.0, 3.0, 0.0 ], [ 3.24, 1.77, 0.0, 0.0, 0.0, 0.0, 3.0, 0.0, 0.0, 3.0, 0.0, 0.0, 1.0, 2.0 ], [ 3.33, 4.92, 100.0, 33.33, 0.0, 0.0, 3.0, 0.0, 0.0, 3.0, 0.0, 1.0, 0.0, 2.0 ], [ 3.27, 4.2, 66.67, 100.0, 0.0, 0.0, 3.0, 0.0, 0.0, 3.0, 0.0, 3.0, 0.0, 0.0 ], [ 3.38, 1.26, 66.67, 66.67, 0.0, 0.0, 3.0, 0.0, 0.0, 3.0, 0.0, 2.0, 0.0, 1.0 ], [ 3.46, 1.93, 66.67, 33.33, 0.0, 0.0, 3.0, 0.0, 0.0, 3.0, 0.0, 2.0, 0.0, 1.0 ], [ 3.43, 4.28, 0.0, 0.0, 0.0, 0.0, 2.0, 0.0, 0.0, 2.0, 0.0, 1.0, 0.0, 1.0 ], [ 3.07, 6.34, 50.0, 50.0, 0.0, 0.0, 2.0, 0.0, 0.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.15, 3.72, 100.0, 100.0, 0.0, 0.0, 2.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 0.0 ], [ 3.48, 3.68, 50.0, 50.0, 0.0, 0.0, 2.0, 0.0, 0.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.63, 1.37, 100.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.51, 5.22, 100.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ], [ 3.31, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.56, 1.65, 100.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.53, 1.31, 0.0, 100.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.34, 3.18, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ] ], null ], "marker.size": [ [ 49, 41, 35, 31, 26, 20, 18, 17, 14, 13, 13, 12, 12, 10, 9, 9, 8, 8, 8, 7, 7, 7, 6, 6, 5, 5, 5, 4, 4, 4, 4, 3, 3, 3, 3, 3, 3, 2, 2, 2, 2, 1, 1, 1, 1, 1, 1 ], null ], "cells.values": [ null, [ [ "1", "2", "3" ], [ "CA", "FL", "TX" ], [ 49, 41, 35 ] ] ], "marker.color": [ [ 49, 41, 35, 31, 26, 20, 18, 17, 14, 13, 13, 12, 12, 10, 9, 9, 8, 8, 8, 7, 7, 7, 6, 6, 5, 5, 5, 4, 4, 4, 4, 3, 3, 3, 3, 3, 3, 2, 2, 2, 2, 1, 1, 1, 1, 1, 1 ], null ], "marker.sizeref": [ 0.03125, null ] }, { "title": "<span style='font-size:20px'><b>(Fake Data) US Part-time Students</b></span><br><span style='font-size:16px'><b>Program:</b> <i>MSM</i></span><br><span style='font-size:14px'><b>Total:</b> <i>449</i></span>" } ], "label": "MSM", "method": "update" }, { "args": [ { "lat": [ [ 31.054487, 36.116203, 40.349457, 27.766279, 42.165726, 40.388783, 40.298904, 40.590752, 39.849426, 43.326618, 35.747845, 41.597782, 33.729759, 35.630066, 47.400902, 38.456085, 33.856892, 35.565342, 37.769337, 39.063946, 31.169546, 33.040619, 44.268543, 43.933907, 32.741646, 42.230171, 44.045876, 41.680893, 32.806671, 41.12537, 34.969704, 45.694454, 38.5266, 44.240459, 39.059811, 47.528912, 46.921925, 44.693947, 37.66814, 40.150032, 42.011539, 21.094318, 38.905985, 38.491226, 42.755966 ], null ], "lon": [ [ -97.563461, -119.681564, -88.986137, -81.686783, -74.948051, -82.764915, -74.521011, -77.209755, -86.258278, -84.536095, -86.692345, -72.755371, -111.431221, -79.806419, -121.490494, -92.288368, -80.945007, -96.928917, -78.169968, -76.802101, -91.867805, -83.643074, -89.616508, -120.55899, -89.678696, -71.530106, -72.710686, -71.51178, -86.79113, -98.268082, -92.373123, -93.900192, -96.726486, -114.478828, -105.311104, -99.784012, -110.454353, -69.381927, -84.670067, -111.862434, -93.210526, -157.498337, -77.033418, -80.954453, -107.30249 ], null ], "meta": [ [ "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮ ▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· · ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· · ▮▮▮▮▮▮ ▮", "· ▮▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮ ▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮ ▮▮▮", "· ▮▮▮ ▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ · ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· · · ▮▮▮▮▮▮", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ·", "· · · ▮▮▮▮▮▮", "· · · ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ · ·", "· · ▮▮▮▮▮▮ ·" ], null ], "text": [ [ "TX", "CA", "IL", "FL", "NY", "OH", "NJ", "PA", "IN", "MI", "TN", "CT", "AZ", "NC", "WA", "MO", "SC", "OK", "VA", "MD", "LA", "GA", "WI", "OR", "MS", "MA", "VT", "RI", "AL", "NE", "AR", "MN", "KS", "ID", "CO", "ND", "MT", "ME", "KY", "UT", "IA", "HI", "DC", "WV", "WY" ], null ], "customdata": [ [ [ 3.4, 3.18, 52.0, 24.0, 0.0, 0.0, 0.0, 25.0, 0.0, 25.0, 0.0, 9.0, 9.0, 7.0 ], [ 3.33, 3.32, 39.13, 13.04, 0.0, 0.0, 0.0, 23.0, 0.0, 23.0, 0.0, 7.0, 9.0, 7.0 ], [ 3.41, 3.61, 35.29, 23.53, 0.0, 0.0, 0.0, 17.0, 0.0, 17.0, 0.0, 2.0, 7.0, 8.0 ], [ 3.45, 2.83, 37.5, 25.0, 0.0, 0.0, 0.0, 16.0, 0.0, 16.0, 0.0, 7.0, 8.0, 1.0 ], [ 3.44, 3.23, 53.85, 7.69, 0.0, 0.0, 0.0, 13.0, 0.0, 13.0, 0.0, 3.0, 9.0, 1.0 ], [ 3.49, 3.98, 36.36, 0.0, 0.0, 0.0, 0.0, 11.0, 0.0, 11.0, 0.0, 2.0, 7.0, 2.0 ], [ 3.34, 4.54, 36.36, 27.27, 0.0, 0.0, 0.0, 11.0, 0.0, 11.0, 0.0, 2.0, 8.0, 1.0 ], [ 3.46, 2.6, 50.0, 40.0, 0.0, 0.0, 0.0, 10.0, 0.0, 10.0, 0.0, 3.0, 6.0, 1.0 ], [ 3.51, 3.47, 44.44, 22.22, 0.0, 0.0, 0.0, 9.0, 0.0, 9.0, 0.0, 2.0, 5.0, 2.0 ], [ 3.48, 3.28, 37.5, 12.5, 0.0, 0.0, 0.0, 8.0, 0.0, 8.0, 0.0, 2.0, 5.0, 1.0 ], [ 3.44, 2.82, 12.5, 25.0, 0.0, 0.0, 0.0, 8.0, 0.0, 8.0, 0.0, 1.0, 6.0, 1.0 ], [ 3.43, 3.56, 85.71, 0.0, 0.0, 0.0, 0.0, 7.0, 0.0, 7.0, 0.0, 0.0, 5.0, 2.0 ], [ 3.42, 2.68, 28.57, 14.29, 0.0, 0.0, 0.0, 7.0, 0.0, 7.0, 0.0, 1.0, 3.0, 3.0 ], [ 3.25, 2.65, 57.14, 0.0, 0.0, 0.0, 0.0, 7.0, 0.0, 7.0, 0.0, 2.0, 3.0, 2.0 ], [ 3.26, 3.37, 33.33, 0.0, 0.0, 0.0, 0.0, 6.0, 0.0, 6.0, 0.0, 0.0, 5.0, 1.0 ], [ 3.31, 3.44, 20.0, 20.0, 0.0, 0.0, 0.0, 5.0, 0.0, 5.0, 0.0, 2.0, 3.0, 0.0 ], [ 3.29, 2.3, 60.0, 0.0, 0.0, 0.0, 0.0, 5.0, 0.0, 5.0, 0.0, 2.0, 3.0, 0.0 ], [ 3.53, 3.45, 0.0, 50.0, 0.0, 0.0, 0.0, 4.0, 0.0, 4.0, 0.0, 1.0, 3.0, 0.0 ], [ 3.46, 1.18, 25.0, 50.0, 0.0, 0.0, 0.0, 4.0, 0.0, 4.0, 0.0, 2.0, 2.0, 0.0 ], [ 3.17, 4.15, 25.0, 50.0, 0.0, 0.0, 0.0, 4.0, 0.0, 4.0, 0.0, 1.0, 1.0, 2.0 ], [ 3.62, 4.33, 50.0, 0.0, 0.0, 0.0, 0.0, 4.0, 0.0, 4.0, 0.0, 2.0, 1.0, 1.0 ], [ 3.44, 3.26, 75.0, 25.0, 0.0, 0.0, 0.0, 4.0, 0.0, 4.0, 0.0, 1.0, 1.0, 2.0 ], [ 3.68, 2.37, 66.67, 0.0, 0.0, 0.0, 0.0, 3.0, 0.0, 3.0, 0.0, 1.0, 2.0, 0.0 ], [ 3.44, 2.24, 66.67, 0.0, 0.0, 0.0, 0.0, 3.0, 0.0, 3.0, 0.0, 1.0, 2.0, 0.0 ], [ 3.46, 2.21, 33.33, 0.0, 0.0, 0.0, 0.0, 3.0, 0.0, 3.0, 0.0, 1.0, 1.0, 1.0 ], [ 3.41, 2.85, 66.67, 33.33, 0.0, 0.0, 0.0, 3.0, 0.0, 3.0, 0.0, 0.0, 3.0, 0.0 ], [ 3.48, 6.15, 100.0, 0.0, 0.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.38, 3.66, 50.0, 0.0, 0.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.37, 1.74, 100.0, 0.0, 0.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 0.0, 1.0, 1.0 ], [ 3.64, 4.46, 0.0, 50.0, 0.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 0.0, 1.0, 1.0 ], [ 3.5, 1.96, 100.0, 0.0, 0.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 1.0, 0.0, 1.0 ], [ 3.14, 1.03, 50.0, 50.0, 0.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.22, 3.2, 0.0, 0.0, 0.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 0.0, 1.0, 1.0 ], [ 3.66, 3.06, 100.0, 50.0, 0.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.27, 2.82, 0.0, 50.0, 0.0, 0.0, 0.0, 2.0, 0.0, 2.0, 0.0, 0.0, 1.0, 1.0 ], [ 3.59, 3.41, 100.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.52, 5.96, 100.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.5, 0.93, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0 ], [ 3.08, 2.59, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.77, 2.47, 100.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.76, 5.75, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ], [ 3.25, 1.85, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0 ], [ 2.95, 1.46, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0 ], [ 3.51, 5.78, 100.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0 ], [ 3.15, 1.53, 0.0, 100.0, 0.0, 0.0, 0.0, 1.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0 ] ], null ], "marker.size": [ [ 25, 23, 17, 16, 13, 11, 11, 10, 9, 8, 8, 7, 7, 7, 6, 5, 5, 4, 4, 4, 4, 4, 3, 3, 3, 3, 2, 2, 2, 2, 2, 2, 2, 2, 2, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1 ], null ], "cells.values": [ null, [ [ "1", "2", "3" ], [ "TX", "CA", "IL" ], [ 25, 23, 17 ] ] ], "marker.color": [ [ 25, 23, 17, 16, 13, 11, 11, 10, 9, 8, 8, 7, 7, 7, 6, 5, 5, 4, 4, 4, 4, 4, 3, 3, 3, 3, 2, 2, 2, 2, 2, 2, 2, 2, 2, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1 ], null ], "marker.sizeref": [ 0.01594387755102041, null ] }, { "title": "<span style='font-size:20px'><b>(Fake Data) US Part-time Students</b></span><br><span style='font-size:16px'><b>Program:</b> <i>MSF</i></span><br><span style='font-size:14px'><b>Total:</b> <i>248</i></span>" } ], "label": "MSF", "method": "update" }, { "args": [ { "lat": [ [ 36.116203, 27.766279, 31.054487, 42.165726, 40.349457, 43.326618, 33.729759, 35.630066, 40.590752, 33.040619, 40.298904, 38.456085, 39.063946, 37.769337, 40.388783, 32.806671, 42.230171, 31.169546, 39.059811, 39.849426, 44.268543, 47.400902, 41.597782, 43.933907, 42.011539, 40.150032, 38.313515, 35.565342, 35.747845, 33.856892, 44.240459, 44.693947, 41.12537, 34.969704, 45.694454, 38.491226, 39.318523, 43.452492, 47.528912, 37.66814, 32.741646 ], null ], "lon": [ [ -119.681564, -81.686783, -97.563461, -74.948051, -88.986137, -84.536095, -111.431221, -79.806419, -77.209755, -83.643074, -74.521011, -92.288368, -76.802101, -78.169968, -82.764915, -86.79113, -71.530106, -91.867805, -105.311104, -86.258278, -89.616508, -121.490494, -72.755371, -120.55899, -93.210526, -111.862434, -117.055374, -96.928917, -86.692345, -80.945007, -114.478828, -69.381927, -98.268082, -92.373123, -93.900192, -80.954453, -75.507141, -71.563896, -99.784012, -84.670067, -89.678696 ], null ], "meta": [ [ "· ▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· · ▮▮▮▮▮▮ ▮", "· · ▮▮▮▮ ▮▮▮▮▮▮", "· ▮ ▮▮▮▮▮▮ ▮▮", "· ▮▮ ▮▮▮▮▮▮ ▮", "· ▮ ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮▮", "· · ▮▮▮▮▮▮ ▮▮", "· · ▮▮▮▮▮▮ ▮", "· ▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮ ▮▮▮▮▮▮ ▮▮", "· ▮ ▮▮▮▮▮▮ ▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ▮▮▮", "· · ▮▮▮▮▮▮ ▮▮▮▮", "· ▮▮ ▮▮ ▮▮▮▮▮▮", "· ▮ ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ▮", "· · ▮▮▮▮▮▮ ▮▮", "· · ▮▮▮▮▮▮ ▮▮", "· · ▮▮▮▮▮▮ ▮▮▮", "· · ▮▮▮ ▮▮▮▮▮▮", "· ▮▮▮ ▮▮▮▮▮▮ ·", "· · · ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ · ▮▮▮▮▮▮", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ · ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· ▮▮▮▮▮▮ ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· · ▮▮▮▮▮▮ ·", "· · · ▮▮▮▮▮▮", "· · · ▮▮▮▮▮▮" ], null ], "text": [ [ "CA", "FL", "TX", "NY", "IL", "MI", "AZ", "NC", "PA", "GA", "NJ", "MO", "MD", "VA", "OH", "AL", "MA", "LA", "CO", "IN", "WI", "WA", "CT", "OR", "IA", "UT", "NV", "OK", "TN", "SC", "ID", "ME", "NE", "AR", "MN", "WV", "DE", "NH", "ND", "KY", "MS" ], null ], "customdata": [ [ [ 3.42, 2.99, 57.14, 25.71, 0.0, 0.0, 0.0, 0.0, 35.0, 35.0, 0.0, 6.0, 22.0, 7.0 ], [ 3.42, 3.18, 56.67, 16.67, 0.0, 0.0, 0.0, 0.0, 30.0, 30.0, 0.0, 6.0, 19.0, 5.0 ], [ 3.37, 3.77, 50.0, 14.29, 0.0, 0.0, 0.0, 0.0, 28.0, 28.0, 0.0, 3.0, 19.0, 6.0 ], [ 3.41, 3.03, 47.83, 39.13, 0.0, 0.0, 0.0, 0.0, 23.0, 23.0, 0.0, 4.0, 18.0, 1.0 ], [ 3.58, 2.93, 18.75, 18.75, 0.0, 0.0, 0.0, 0.0, 16.0, 16.0, 0.0, 6.0, 7.0, 3.0 ], [ 3.34, 2.4, 53.85, 15.38, 0.0, 0.0, 0.0, 0.0, 13.0, 13.0, 0.0, 3.0, 5.0, 5.0 ], [ 3.47, 3.75, 25.0, 33.33, 0.0, 0.0, 0.0, 0.0, 12.0, 12.0, 0.0, 4.0, 4.0, 4.0 ], [ 3.38, 3.28, 72.73, 18.18, 0.0, 0.0, 0.0, 0.0, 11.0, 11.0, 0.0, 1.0, 7.0, 3.0 ], [ 3.44, 1.8, 20.0, 10.0, 0.0, 0.0, 0.0, 0.0, 10.0, 10.0, 0.0, 1.0, 7.0, 2.0 ], [ 3.31, 3.29, 60.0, 20.0, 0.0, 0.0, 0.0, 0.0, 10.0, 10.0, 0.0, 0.0, 9.0, 1.0 ], [ 3.44, 4.57, 66.67, 11.11, 0.0, 0.0, 0.0, 0.0, 9.0, 9.0, 0.0, 0.0, 4.0, 5.0 ], [ 3.38, 2.71, 75.0, 25.0, 0.0, 0.0, 0.0, 0.0, 8.0, 8.0, 0.0, 1.0, 5.0, 2.0 ], [ 3.51, 3.1, 50.0, 37.5, 0.0, 0.0, 0.0, 0.0, 8.0, 8.0, 0.0, 2.0, 5.0, 1.0 ], [ 3.36, 2.84, 62.5, 25.0, 0.0, 0.0, 0.0, 0.0, 8.0, 8.0, 0.0, 1.0, 4.0, 3.0 ], [ 3.39, 4.22, 62.5, 25.0, 0.0, 0.0, 0.0, 0.0, 8.0, 8.0, 0.0, 3.0, 3.0, 2.0 ], [ 3.51, 1.61, 28.57, 14.29, 0.0, 0.0, 0.0, 0.0, 7.0, 7.0, 0.0, 0.0, 5.0, 2.0 ], [ 3.3, 2.65, 42.86, 0.0, 0.0, 0.0, 0.0, 0.0, 7.0, 7.0, 0.0, 0.0, 6.0, 1.0 ], [ 3.35, 3.63, 33.33, 16.67, 0.0, 0.0, 0.0, 0.0, 6.0, 6.0, 0.0, 2.0, 4.0, 0.0 ], [ 3.41, 2.9, 50.0, 0.0, 0.0, 0.0, 0.0, 0.0, 6.0, 6.0, 0.0, 2.0, 3.0, 1.0 ], [ 3.42, 3.45, 33.33, 50.0, 0.0, 0.0, 0.0, 0.0, 6.0, 6.0, 0.0, 1.0, 4.0, 1.0 ], [ 3.26, 2.6, 0.0, 20.0, 0.0, 0.0, 0.0, 0.0, 5.0, 5.0, 0.0, 2.0, 2.0, 1.0 ], [ 3.52, 4.34, 60.0, 20.0, 0.0, 0.0, 0.0, 0.0, 5.0, 5.0, 0.0, 0.0, 3.0, 2.0 ], [ 3.45, 3.37, 40.0, 0.0, 0.0, 0.0, 0.0, 0.0, 5.0, 5.0, 0.0, 1.0, 1.0, 3.0 ], [ 3.36, 2.95, 60.0, 0.0, 0.0, 0.0, 0.0, 0.0, 5.0, 5.0, 0.0, 1.0, 4.0, 0.0 ], [ 3.33, 3.87, 20.0, 40.0, 0.0, 0.0, 0.0, 0.0, 5.0, 5.0, 0.0, 0.0, 4.0, 1.0 ], [ 3.64, 2.62, 100.0, 25.0, 0.0, 0.0, 0.0, 0.0, 4.0, 4.0, 0.0, 0.0, 3.0, 1.0 ], [ 3.56, 4.03, 75.0, 0.0, 0.0, 0.0, 0.0, 0.0, 4.0, 4.0, 0.0, 0.0, 3.0, 1.0 ], [ 3.16, 3.67, 33.33, 33.33, 0.0, 0.0, 0.0, 0.0, 3.0, 3.0, 0.0, 0.0, 2.0, 1.0 ], [ 3.59, 2.04, 33.33, 0.0, 0.0, 0.0, 0.0, 0.0, 3.0, 3.0, 0.0, 0.0, 1.0, 2.0 ], [ 3.4, 4.72, 66.67, 0.0, 0.0, 0.0, 0.0, 0.0, 3.0, 3.0, 0.0, 1.0, 2.0, 0.0 ], [ 3.44, 3.82, 50.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.0, 2.0, 0.0, 0.0, 0.0, 2.0 ], [ 2.92, 1.04, 50.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.0, 2.0, 0.0, 1.0, 0.0, 1.0 ], [ 3.14, 2.0, 50.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.72, 1.27, 50.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.0, 2.0, 0.0, 2.0, 0.0, 0.0 ], [ 3.4, 2.02, 50.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.5, 3.5, 50.0, 50.0, 0.0, 0.0, 0.0, 0.0, 2.0, 2.0, 0.0, 1.0, 1.0, 0.0 ], [ 3.5, 2.86, 100.0, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.64, 2.71, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.34, 3.17, 100.0, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0, 1.0, 0.0, 0.0, 1.0, 0.0 ], [ 3.63, 1.7, 100.0, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0, 1.0, 0.0, 0.0, 0.0, 1.0 ], [ 3.43, 4.47, 100.0, 100.0, 0.0, 0.0, 0.0, 0.0, 1.0, 1.0, 0.0, 0.0, 0.0, 1.0 ] ], null ], "marker.size": [ [ 35, 30, 28, 23, 16, 13, 12, 11, 10, 10, 9, 8, 8, 8, 8, 7, 7, 6, 6, 6, 5, 5, 5, 5, 5, 4, 4, 3, 3, 3, 2, 2, 2, 2, 2, 2, 1, 1, 1, 1, 1 ], null ], "cells.values": [ null, [ [ "1", "2", "3" ], [ "CA", "FL", "TX" ], [ 35, 30, 28 ] ] ], "marker.color": [ [ 35, 30, 28, 23, 16, 13, 12, 11, 10, 10, 9, 8, 8, 8, 8, 7, 7, 6, 6, 6, 5, 5, 5, 5, 5, 4, 4, 3, 3, 3, 2, 2, 2, 2, 2, 2, 1, 1, 1, 1, 1 ], null ], "marker.sizeref": [ 0.022321428571428572, null ] }, { "title": "<span style='font-size:20px'><b>(Fake Data) US Part-time Students</b></span><br><span style='font-size:16px'><b>Program:</b> <i>FLEX MBA</i></span><br><span style='font-size:14px'><b>Total:</b> <i>320</i></span>" } ], "label": "FLEX MBA", "method": "update" } ], "xanchor": "left", "yanchor": "top", "direction": "down" } ] } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~NaserNikandish", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/68.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-5.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-06 22:23:30", "mapbox_access_tokens": null, "has_password": null, "username": "NaserNikandish", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } }, { "creation_time": "2025-09-07T11:46:15.614172Z", "comments": { "results": [], "count": 0 }, "parented": true, "embed_url": "https://chart-studio.plotly.com/~virgopotterhead/5.embed", "fid": "virgopotterhead:5", "filename": "Plot 5", "filetype": "plot", "img_url": "https://storage.googleapis.com/plotly-prod-images/virgopotterhead/5/9_8JA6PLQRUTBM1YI6W2S6HGU6NZNY1H.png", "image_urls": { "default": "https://storage.googleapis.com/plotly-prod-images/virgopotterhead/5/2_2K8RWF6N7ZQ4X3LEMMX3STF2WG2YBZ.png", "block-thumb": "https://storage.googleapis.com/plotly-prod-images/virgopotterhead/5/8_EANDUQITLKHZF1WTFI6Y488EELZB69.png", "list-thumb": "https://storage.googleapis.com/plotly-prod-images/virgopotterhead/5/9_8JA6PLQRUTBM1YI6W2S6HGU6NZNY1H.png" }, "api_urls": { "files": "https://api.plotly.com/v2/files/virgopotterhead:5", "plots": "https://api.plotly.com/v2/plots/virgopotterhead:5", "parent": "https://api.plotly.com/v2/folders/home?user=virgopotterhead" }, "owner": "virgopotterhead", "parent": -1, "preview": "", "referencers": [], "references": [], "title": "", "views": 1, "web_url": "https://chart-studio.plotly.com/~virgopotterhead/5/", "world_readable": true, "date_modified": "2025-09-07T11:48:25.976Z", "stars": { "results": [], "count": 0 }, "collaborators": { "results": [], "count": 0 }, "subfolder_count": null, "refresh_interval": null, "organize_view_url": "https://chart-studio.plotly.com/~virgopotterhead/5/", "current_user_permission": "read", "is_theme": null, "is_template": false, "autosize": true, "caption": "", "figure": { "data": [ { "meta": { "columnNames": { "x": "B", "y": "A" } }, "mode": "lines", "type": "scatter", "xsrc": "virgopotterhead:4:03e6e8", "ysrc": "virgopotterhead:4:308f96" } ], "frames": [], "layout": { "xaxis": { "type": "linear", "range": [ 1, 3 ], "title": { "text": "Number of cups in the stack" }, "autorange": true }, "yaxis": { "type": "linear", "range": [ 0.2922222222222222, 0.4477777777777778 ], "title": { "text": "Average rate of cooling of the water per minute" }, "autorange": true }, "autosize": true, "template": { "data": { "bar": [ { "type": "bar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "table": [ { "type": "table", "cells": { "fill": { "color": "#EBF0F8" }, "line": { "color": "white" } }, "header": { "fill": { "color": "#C8D4E3" }, "line": { "color": "white" } } } ], "carpet": [ { "type": "carpet", "aaxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" }, "baxis": { "gridcolor": "#C8D4E3", "linecolor": "#C8D4E3", "endlinecolor": "#2a3f5f", "minorgridcolor": "#C8D4E3", "startlinecolor": "#2a3f5f" } } ], "mesh3d": [ { "type": "mesh3d", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "contour": [ { "type": "contour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "heatmap": [ { "type": "heatmap", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatter": [ { "type": "scatter", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "surface": [ { "type": "surface", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "heatmapgl": [ { "type": "heatmapgl", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "histogram": [ { "type": "histogram", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "parcoords": [ { "line": { "colorbar": { "ticks": "", "outlinewidth": 0 } }, "type": "parcoords" } ], "scatter3d": [ { "type": "scatter3d", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattergl": [ { "type": "scattergl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "choropleth": [ { "type": "choropleth", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattergeo": [ { "type": "scattergeo", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2d": [ { "type": "histogram2d", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ], "scatterpolar": [ { "type": "scatterpolar", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "contourcarpet": [ { "type": "contourcarpet", "colorbar": { "ticks": "", "outlinewidth": 0 } } ], "scattercarpet": [ { "type": "scattercarpet", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scattermapbox": [ { "type": "scattermapbox", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterpolargl": [ { "type": "scatterpolargl", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "scatterternary": [ { "type": "scatterternary", "marker": { "colorbar": { "ticks": "", "outlinewidth": 0 } } } ], "histogram2dcontour": [ { "type": "histogram2dcontour", "colorbar": { "ticks": "", "outlinewidth": 0 }, "autocolorscale": true } ] }, "layout": { "geo": { "bgcolor": "white", "showland": true, "lakecolor": "white", "landcolor": "white", "showlakes": true, "subunitcolor": "#C8D4E3" }, "font": { "color": "#2a3f5f" }, "polar": { "bgcolor": "white", "radialaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" }, "angularaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8" } }, "scene": { "xaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "yaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" }, "zaxis": { "ticks": "", "gridcolor": "#DFE8F3", "gridwidth": 2, "linecolor": "#EBF0F8", "zerolinecolor": "#EBF0F8", "showbackground": true, "backgroundcolor": "white" } }, "title": { "x": 0.05 }, "xaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "yaxis": { "ticks": "", "gridcolor": "#EBF0F8", "linecolor": "#EBF0F8", "automargin": true, "zerolinecolor": "#EBF0F8", "zerolinewidth": 2 }, "ternary": { "aaxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "baxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "caxis": { "ticks": "", "gridcolor": "#DFE8F3", "linecolor": "#A2B1C6" }, "bgcolor": "white" }, "colorway": [ "#636efa", "#EF553B", "#00cc96", "#ab63fa", "#19d3f3", "#e763fa", "#fecb52", "#ffa15a", "#ff6692", "#b6e880" ], "hovermode": "closest", "colorscale": { "diverging": [ [ 0, "#8e0152" ], [ 0.1, "#c51b7d" ], [ 0.2, "#de77ae" ], [ 0.3, "#f1b6da" ], [ 0.4, "#fde0ef" ], [ 0.5, "#f7f7f7" ], [ 0.6, "#e6f5d0" ], [ 0.7, "#b8e186" ], [ 0.8, "#7fbc41" ], [ 0.9, "#4d9221" ], [ 1, "#276419" ] ], "sequential": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ], "sequentialminus": [ [ 0, "#0508b8" ], [ 0.0893854748603352, "#1910d8" ], [ 0.1787709497206704, "#3c19f0" ], [ 0.2681564245810056, "#6b1cfb" ], [ 0.3575418994413408, "#981cfd" ], [ 0.44692737430167595, "#bf1cfd" ], [ 0.5363128491620112, "#dd2bfd" ], [ 0.6256983240223464, "#f246fe" ], [ 0.7150837988826816, "#fc67fd" ], [ 0.8044692737430168, "#fe88fc" ], [ 0.8938547486033519, "#fea5fd" ], [ 0.9832402234636871, "#febefe" ], [ 1, "#fec3fe" ] ] }, "plot_bgcolor": "white", "paper_bgcolor": "white", "shapedefaults": { "line": { "width": 0 }, "opacity": 0.4, "fillcolor": "#506784" }, "annotationdefaults": { "arrowhead": 0, "arrowcolor": "#506784", "arrowwidth": 1 } }, "themeRef": "PLOTLY_WHITE" } } }, "height": null, "width": null, "user": { "profile_url": "https://chart-studio.plotly.com/~virgopotterhead", "avatar_url": "https://storage.googleapis.com/plotly-prod-profiles/22.jpg", "background_url": "https://storage.googleapis.com/plotly-prod-profiles/bg-8.jpg", "bio": "", "nickname": "", "website": "", "stream_tokens": null, "feature_set_id": null, "csrf_token": null, "date_joined": "2025-09-07 11:30:11", "mapbox_access_tokens": null, "has_password": null, "username": "virgopotterhead", "email": null, "is_active": null, "readonly": null, "is_dash_creator": null, "dash_created_count": null, "is_chart_creator": null, "charts_created_count": null } } ] }
